ADDAC713 User's Guide
ADDAC713
STEREO DISCRETE MIXER
CH1 LEFT INPUT
CH1 RIGHT INPUT
CH2 LEFT INPUT
CH2 RIGHT INPUT
CH3 LEFT INPUT
CH3 RIGHT INPUT
CH4 LEFT INPUT
ADDAC SYSTEM page 3
SIGNAL FLOW DIAGRAM
PANNING GAIN
CONTROL CONTROL
PANNING GAIN
CONTROL CONTROL
PANNING GAIN
CONTROL CONTROL
GAIN
CONTROL
FEEDBACK
GAIN
CONTROL
SOFT CLIP
&
LOW PASS

MASTER MIX

SOFT/OFF/HARD
LEFT OUTPUT
RIGHT OUTPUT
