Summary of Contents for ARTE NEAT Series
-
Page 2: Table Of Contents
Chimney sweeping ........................................20 11.3.2. Annual maintenance ....................................... 21 11.3.3. How to clean the inside parts of ARTE® NEAT fireplace ............................21 11.4. Inactive fireplace for prolonged periods ..................................21 12. Tips & Tricks for Resolving Issues ....................................21 13. Dimensions ........................................... 23 14. -
Page 3: Arte ® Fireplace - A Greek Quality Product
- A G IREPLACE REEK UALITY RODUCT Thank you for buying an ARTE ® fireplace - we believe that you will have as much pleasure from our product as we have. Your ARTE ® fireplace is made in such a way, to extract the maximum possible energy from the wood with the minimum possible emissions,... -
Page 4: Wood Types And Calorific Value
FIREPLACE & U | NEAT 70/80/90 NSTALLATION SERS ANUAL Pile wood off the ground on scrap lumber or wooden pallets. The time-honored way to cure wood is to buck, split, and stack wood off the ground for one full year. How-ever, wood can generally be reduced to 20 per cent moisture content in two to three months. -
Page 5: Determining The Heat Output
Poplar Table 2.4.1 860Kcal/h = 1 kW/h The values are based on 15% residual wood moisture. An ARTE fireplace can be fired with all of the above wood types ® 2.5. Determining the heat output There is not a specific rule that enables the calculation of the required heat output. This depends on the amount of space that is required to be heated and mostly on its insulation. -
Page 6: Endorsements & Certifications
ARTE® fireplace’s feature marking plate is located on the right side of the appliance. 4. P ACKAGING ARTE® is devoted in protecting the environment, so we use as much recyclable materials as possible and the least amount of packaging materials without compromising the secure transfer of our products. 4.1. Unpacking The product will be delivered on a wooden palette which is lined with wooden side panels and top panel. -
Page 7: Assembly
SSEMBLY 5.1. Door opening side change ARTE® NEAT fireplace is delivered with the combustion chamber door opening on the left; still you have the potential to change it in order to open on the right. To change the opening direction of the combustion door, please follow the steps below: Open the door. -
Page 8: Fire Safety
FIREPLACE & U | NEAT 70/80/90 NSTALLATION SERS ANUAL 10. Reverse the locking hook as shown in the image, screw the stud and the screw and tighten the jam nut. (Pic. 5.1.10) 11. Place the rod to the opposite side and screw the locking hook and the handle by using the hexagon socket set screws you removed earlier. -
Page 9: Wooden Beams Protection
6.4. Flue security instructions Prior to installing the ARTE® fireplace the chimney sweep or a qualified technician should check the condition and operation of your chimney in accordance with the standards EN13384-1 & EN13384-2. This way you ensure the best conditions for heating without issues. -
Page 10: Chimney Placement
FIREPLACE & U | NEAT 70/80/90 NSTALLATION SERS ANUAL create issues in the correct operation of the fireplace. Also, a proper study for the flue size must be conducted because often old flues have quite large diameters. This means that the amount of air draft is not proportional to the heat generated by the fireplace and by extension means that you consume more wood than necessary and will spend more time on maintenance. -
Page 11: Malfunction - Secure Fireplace Shutdown
695/795/895mm, according to the type of the device. To install an ARTE® NEAT fireplace in an existing fireplace is necessary to remove the main unit from the metallic shell, as other metal parts also. The following steps explain this procedure. - Page 12 FIREPLACE & U | NEAT 70/80/90 NSTALLATION SERS ANUAL Disengage the spring from the door by unscrewing the jam nut and the hexagon socket screw (Pic. 7.2.1). Remove the retaining ring from the hinge and remove the door. (Pic. 7.2.2) Remove from the combustion chamber all the vermiculite parts as the metal parts between them also following the order of Pic.
- Page 13 FIREPLACE & U | NEAT 70/80/90 NSTALLATION SERS ANUAL Pic. 7.2.9 Once you have completed with the fireplace disassembly continue with the following steps: Cover the flue with sealant and connect it to the mounting flange. The connection must be secured with a clamp. (Pic. 7.2.10) Place the metallic shell of the fireplace on the installation surface.
-
Page 14: Installation On A Arte Base
ARTE® gives you the option to install NEAT fireplace on a compatible base (Pic. 7.3.1) (optional equipment). In this case you can align the device by leveling the ARTE base legs. So the disassembly of the main unit from the metallic shell is not necessary. -
Page 15: Air Supply To Adjacent Rooms (Channel Set-Optional Equipment)
7.4. Air supply to adjacent rooms (Channel set-Optional Equipment) ARTE® NEAT fireplaces have an option for connecting air tubes and provide hot air in adjacent rooms. At the top of the device there are two holes in which you can connect said conductors. -
Page 16: Operating Instructions
8.1. Before initial use of an ARTE® NEAT fireplace One of our qualified dealers has already given you instructions on how to operate the ARTE® NEAT fireplace you just bought. In the guidelines below there are detailed instructions on the steps to follow so you do not encounter any issues during the operation of the... -
Page 17: About Arte® Neat Fireplace
SERS ANUAL fireplace. The qualified dealer in your area is at your disposal to answer any of your questions. The ARTE® NEAT fireplace is equipped with the following control systems: 8.2. About ARTE® NEAT fireplace The fireplace you just received is a device designed to offer excellent heating with very high efficiency. It is Insert type, which means that it can be installed in an existing fireplace and thus upload the thermal rate of your room. -
Page 18: General Information
8.3.1. When the fireplace paint dries ARTE ® products are painted in spray booth with as more environmentally friendly and ecological colors as possible. There is although a possibility that the first few times the fireplace is lighted, the paint emits an odor. Let the fire burn with intense convection until all traces of gas disappear and there is no longer a smell. -
Page 19: Primary And Secondary Combustion
Thus a large part of the heat that is achieved, is discharged directly through the draft of the flue to the exterior and not in the heating area. Pic.10.1 ARTE’s® chamber manages to provide the maximum secondary combustion performance. The 18 | Page... -
Page 20: Cleaning & Maintaining The Fireplace
The fireplace surface is painted with heat-resistant paint. It is best kept clean by vacuuming with a soft brush attachment or by wiping with a lint-free cloth. Over a period of time, the painted surface may become slightly grey. A canister of touch-up ARTE ®... -
Page 21: Gasket
The gasket around the perimeter of the door may harden over a period of time. It should be replaced if it becomes difficult to close the door or if air starts to leak in around the perimeter of the doors, causing the fire to become a little less controllable. An ARTE ®... -
Page 22: Annual Maintenance
Check the door and handle for tightness. Adjust if needed. 11.3.3. How to clean the inside parts of ARTE® NEAT fireplace During the annual visit of your local chimney sweep and during the cleaning of internal parts of the fireplace, it is recommended to remove all internal parts of the combustion chamber to be also cleaned. - Page 23 FIREPLACE & U | NEAT 70/80/90 NSTALLATION SERS ANUAL The wood is too wet The logs are too thick The ash is over the appropriate limit Intense smoking in the combustion chamber, intense soot deposition on the glass Open the air supply Small quantity of wood The wood is too wet The logs are too thick...
-
Page 24: Dimensions
FIREPLACE & U | NEAT 70/80/90 NSTALLATION SERS ANUAL 13. D IMENSIONS MODEL DIMENSION NEAT 70 NEAT 80 NEAT 90 A (cm) 68.5 78.5 88.5 Table 13.1 23 | Page... -
Page 25: Technical Specifications
& U FIREPLACE | NEAT 70/80/90 NSTALLATION SERS ANUAL 14. T ECHNICAL PECIFICATIONS TECHNICAL SPECIFICATIONS UNITS NEAT 70 NEAT 80 NEAT 90 Kcal/h 5160 6020 7310 *Total heat output Recommended hourly consumption of firewood Kg/h Efficiency Exhausts temperature °C CO emissions 0.090 0.090 0.090... -
Page 26: Warranty
Wearing parts like gaskets, vermiculite panels and glass Smoke and soot damage Natural discoloration or deviating colors on the outer cladding Cracks in the combustion chamber that have no effect on the safe functioning of the ARTE ® NEAT fireplace... - Page 27 FIREPLACE & U | NEAT 70/80/90 NSTALLATION SERS ANUAL OTES S/N: 26 | Page...
