Page 2: Table Of Contents
System with closed expansion tank when the fireplace is below the heaters ..................................11 6.2.3. System with open expansion tank ..................................................12 7. Operating Instructions ..........................................................13 7.1. Before using the ARTE® NIREAS fireplace for the first time ............................................13 7.2. About ARTE® NIREAS fireplace ......................................................13 7.3. General information .........................................................14 7.3.1. -
Page 3: Arte ® Fireplace - A Greek Quality Product
- A G IREPLACE REEK UALITY RODUCT Thank you for buying an ARTE ® fireplace - we believe that you will have as much pleasure from our product as we have. Your ARTE ® fireplace is made in such a way, to extract the maximum possible energy from the wood with the minimum possible emissions,... -
Page 4: Wood Types And Calorific Value
WATER HEATING FIREPLACE Ε & | NIREAS ΓΧΕΙΡΙ∆ΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ ΧΡΗΣΗΣ 2.4. Wood types and calorific value A wood’s efficiency does not depend only on its type, but also on its humidity, as well as the temperature of the combustion chamber. -
Page 5: Determining The Heat Output
WATER HEATING FIREPLACE & | NIREAS NSTALLATION USER MANUAL longer time. Best when well seasoned. The same applies for oak, but seasoned for 2-3 years. The various wood types have various calorific values Wood type Thermal capacity (Kcal/h-1Kg) Briquette 5.000 Birch 4.800... -
Page 6: Endorsements & Certifications
ARTE® fireplace’s feature marking plate is located on the right side of the appliance. 4. P ACKAGING ARTE® is devoted in protecting the environment, so we use as much recyclable materials as possible and the least amount of packaging materials without compromising the secure transfer of our products. 4.1. Unpacking the fireplace The product will be delivered on a wooden palette which is lined with wooden side panels and top panel. -
Page 7: Fire Safety
5.4. Flue security instructions Prior to installing the fireplace ARTE® the chimney sweep or a qualified technician should check the condition and operation of your chimney in accordance with the standards EN13384-1 & EN13384-2. This way you ensure the best conditions for heating without issues. -
Page 8: Chimney Placement
WATER HEATING FIREPLACE Ε & | NIREAS ΓΧΕΙΡΙ∆ΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ ΧΡΗΣΗΣ Pic. 5.4.2.1 Pic. 5.4.2.2 Inserting the pipe along the outer wall must be properly studied to avoid heat loss. This solution, however, is contraindicated, as positioning the flue inside the house warms more spaces as heat of the flue remains in the house 5.4.2. -
Page 9: Connecting The Fireplace With The Flue
ONNECTING IREAS TO THE CENTRAL HEATING INSTALLATION ARTE® NIREAS fireplace can be installed to work individually or in collaboration with any another water heating device to be used for central or floor heating. The installation is made by using 1 ”... -
Page 10: Connecting The Water Supply And Return
Pic. 6.4 6.1. Connecting the water supply and return ARTE® NIREAS provides you with 4 different water supply intakes and 4 return outlets. In order to connect the fireplace with the water circuit you must use 1 ” pipe joints. (Pic. 6.1.1). The fireplace is delivered with 6 out of 8 joints already closed. In order to correctly connects the pipes to the circuit or seal (if applicable) the remaining joints you must use hemp or/and thread glue. -
Page 11: System With Closed Expansion Tank When The Fireplace Is At The Same Level With The Heaters
WATER HEATING FIREPLACE & | NIREAS NSTALLATION USER MANUAL 6.2.1. System with closed expansion tank when the fireplace is at the same level with the heaters 10 | Page... -
Page 12: System With Closed Expansion Tank When The Fireplace Is Below The Heaters
WATER HEATING FIREPLACE Ε & | NIREAS ΓΧΕΙΡΙ∆ΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ ΧΡΗΣΗΣ 6.2.2. System with closed expansion tank when the fireplace is below the heaters 11 | Σελίδα... -
Page 13: System With Open Expansion Tank
6.2.3. System with open expansion tank ARTE® NIREAS fireplace is delivered with a stainless steel cooling coil already installed in which you must install a cold water supply (Table 7.2.1, Line 9) so in case the water inside the water jacket exceeds 95 C the overheating safety valve (Pic. -
Page 14: Operating Instructions
The operating instructions below describe in detail the steps to follow so you do not encounter any difficulties during the operation of the fireplace. The qualified dealer in your area will be at your disposal to answer any questions. NIREAS fireplace is equipped with the following control systems: 7.2. -
Page 15: General Information
7.3.1. When the fireplace paint dries ARTE ® products are painted in spray booth with as more environmentally friendly and ecological colors as possible. There is although a possibility that the first few times the fireplace is lighted, the paint emits an odor. Let the fire burn with intense convection until all traces of gas disappear and there is no longer a smell. -
Page 16: Heating During Seasonal Change Or In Adverse Weather Conditions
7.4. Adjusting the combustion air ARTE® NIREAS fireplace gives you the opportunity to adjust the primary combustion air intake by 2 different ways. You can either use the fader (Table 7.2.1, Line 6) which is located on the frame (STANDARD system) or you can use the automatic control panel (AUTOMATIC system). In both cases the adjustment is made by controlling an electric motor where the changes made either on the fader or the control panel are transferred to the combustion air intake damper. -
Page 17: Using The Regulator
WATER HEATING FIREPLACE & | NIREAS NSTALLATION USER MANUAL for water heating fireplace with air intake control (RT-08G) The regulator controls the intensity of the combustion in the fireplace by adjusting the combustion air damper, so as to maintain the water temperature in the fireplace to a desired, predetermined level. -
Page 18: Screens
WATER HEATING FIREPLACE Ε & | NIREAS ΓΧΕΙΡΙ∆ΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ ΧΡΗΣΗΣ 7.4.2.2. Screens 7.4.2.2.1. OPERATION screen It displays the current temperature of the water in the water jacket of the fireplace and the degree of the air damper in percentage. This screen is fixed and to change it you must press the TOGGLE (7) key. -
Page 19: Time Zones Mode
WATER HEATING FIREPLACE & | NIREAS NSTALLATION USER MANUAL The table below presents the different modes of management of the DHW and HC pumps. ICON MODE PUMP STATUS Closed Open Open SUMMER Closed Open Open Open alternately PRIORITY* DHW: 4’... -
Page 20: Alarm Screen
WATER HEATING FIREPLACE Ε & | NIREAS ΓΧΕΙΡΙ∆ΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ ΧΡΗΣΗΣ The parameters adjust the regulator according to the properties of the fireplace and of the central heating installation. The new settings must be in agreement with the installer and the manufacturer of the fireplace. Any careless changes can cause unstable and inefficient system operation. -
Page 21: Lighting The Fireplace
WATER HEATING FIREPLACE & | NIREAS NSTALLATION USER MANUAL 8. L IGHTING THE FIREPLACE 8.1. Traditional method of lighting Every time you light the fireplace, it initially requires large volumes of air. When the fireplace is cold, leave the door slightly open in order for air to circulate around the door for the first few minutes and turn the fader (STANDARD system) clockwise (Table 7.2.1, Line 6) at the maximum... -
Page 22: Tertiary Combustion
ARTE® NIREAS’ chamber manages to provide the maximum secondary combustion performance. An automatic air intake regulating system that inserts air from below in cooperation with the intake of... -
Page 23: Cleaning & Maintaining The Fireplace
10.2.2. Glass ARTE® NIREAS fireplace has a single ceramic glass in the window of the combustion chamber in order to receive as much heat as possible by radiation. If the fireplace is generally operated at the correct temperature, there should be little or no soot on the glass. -
Page 24: Gasket
The gasket around the perimeter of the door may harden over a period of time. It should be replaced if it becomes difficult to close the door or if air starts to leak in around the perimeter of the doors, causing the fire to become a little less controllable. An ARTE ®... -
Page 25: How To Clean The Inside Parts Of Arte® Nireas Fireplace
NSTALLATION USER MANUAL 10.2.7. How to clean the inside parts of ARTE® NIREAS fireplace During the annual visit of your local chimney sweep and during the cleaning of internal parts of the fireplace, it is recommended to remove all internal parts of the combustion chamber to be also cleaned. (Κεφάλαιο 10.4) Maintenance on the fireplace must be done ONLY when the device is cold. -
Page 26: Dimensions
WATER HEATING FIREPLACE Ε & | NIREAS ΓΧΕΙΡΙ∆ΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ ΧΡΗΣΗΣ 12. D IMENSIONS 25 | Σελίδα... -
Page 27: Technical Specifications
& WATER HEATING FIREPLACE | NIREAS NSTALLATION USER MANUAL 13. T ECHNICAL PECIFICATIONS TECHNICAL SPECIFICATIONS UNITS Kcal/h 20889 * Total heat output 24.29 Kcal/h 15738 * Total heat output in water 18.3 Water tank capacity Maximum operating pressure Recommended hourly consumption of firewood... -
Page 28: Warranty
Wearing parts like gaskets, vermiculite panels and glass Smoke and soot damage Natural discoloration or deviating colors on the outer cladding Cracks in the combustion chamber that have no effect on the safe functioning of the ARTE ® SOL fireplace... - Page 29 WATER HEATING FIREPLACE & | NIREAS NSTALLATION USER MANUAL OTES S/N: S/N: 28 | Page...
