- Page 1 & U NSTALLATION ANUAL UIDE FI REPLACE ST65 AR65 TR65 COL/COR65...
-
Page 2: Table Of Contents
Legal guarantee ..................................22 • NOTES ......................................... 23 Please, read all the important information in this manual before using the appliance. ARTE© doesn’t take any liability for damages or injuries by the non compliance with the following ! ! ! ! instructions. -
Page 3: Main Parts Of Appliance
ARTE © fireplace |COSY LINE 1. Main parts of appliance COSY LINE fireplaces consist of the following • The main body of the fireplace. • 3 conduits (2pcs of Ø15cm x 3m, 1pc of Ø10cm x 3m) with sealed connections. -
Page 4: Flue
ARTE © fireplace |COSY LINE Grid Bottom Fig. 1 Fig. 2 3. Flue Fig. 3: Correct position for the flue and chimney cap fig. 4: Correct position for flat roof Fig. 5: Chimney on an outside wall • Firstly, verify the suitability of the flue •... - Page 5 ARTE © fireplace |COSY LINE • In the upper side of the flue chimney cap must be installed to avoid the gathering of materials and rain water. • If the chimney is not as tall as the house or if it is installed on an outside wall, so the air in the chimney is cold, the house may "draw"...
-
Page 6: Fireplace Without Fan System
ARTE © fireplace |COSY LINE 4. Fireplace without fan system The preparation of air intakes is divided in 3 different categories according to if the unit of fireplace has a fan system or not. A fireplace without a fan system needs an external opening to get air for the combustion. -
Page 7: Fireplace With Fan System (Up To 120M )
ARTE © fireplace |COSY LINE 6. Fireplace with fan system (up to 120m Fig. 11: Fireplace with Fan Open a Ø15cm hole in the cladding of the fireplace, for the circuit of the fan and cover it • with an adjustable grille. -
Page 8: Connecting The Fireplace With The Fumes Conduits
Also, cover all the outlets on the cladding, with adjustable grilles Fig. 15 Fig. 16 Use only the original conduits and the clamps which accompany ARTE© fireplaces. All installation ! ! ! ! must be made by a qualified and experienced technician. -
Page 9: Connecting The Conduits With The Fan System
ARTE © fireplace |COSY LINE 8. Connecting the conduits with the fan system • Insert the Ø150 cm conduits to the ends of the fan system and constrict them tightly with the metal clamps (Fig. 17) Clamp Fig. 17: Connecting the conduits •... - Page 10 ARTE © fireplace |COSY LINE • When the fan system has been already assembled, put a bead of high temperature resistant silicon in the upper side of fan unit (Fig. 19). The fan must be perfectly sealed. Fig. 19 • Then, insert the fan unit to the flange (Fig. 20) and push the fan into the special support of the flange.
-
Page 11: Adjusting The Leveling Of The Fireplace
ARTE © fireplace |COSY LINE 9. Adjusting the leveling of the fireplace Turn the adjustment screws from the legs in order to adjust the aspiration height with respect to the cladding (Fig. 22). Attention: ! ! ! ! Check the height between the lever and the cladding (Fig. 23). The lever for the combustion must be easily accessible so the cladding must be at least (8mm) below to lever (Fig. -
Page 12: Adjusting The Leveling Of The A.d.f. System
ARTE © fireplace |COSY LINE 10. Adjusting the leveling of the A.D.F. System Graded scale Fig. 26: A.D.F. system Fully closed Fully open The A.D.F. system is a patented mechanism which automatically opens the fume damper when the door of the fireplace is opened. -
Page 13: Lighting The Fireplace
! ! ! ! position. ARTE© fireplaces are equipped with a secondary combustion system which gives oxygen to the combustion chamber and another flame above the main flame takes place. So the Carbon Monoxide converts to Carbon Dioxide and the heat efficiency is improved. -
Page 14: Adjusting The External Control Unit Of Thermostat
ARTE © fireplace |COSY LINE 14. Adjusting the external control unit of thermostat Fig. 28: Control panel display Functions • ON / OFF: On/Off the controller by pushing the button P1 The state OFF is signaled through the LED L1 •... -
Page 15: Cleaning And Maintaining The Fireplace
The fireplace surface is painted with heat-resistant paint. It is best kept clean by vacuuming with a soft brush attachment or by wiping with a lint-free cloth. Over a period of time, the painted surface may become slightly grey. A canister of touch-up ARTE ®... -
Page 16: Gasket
An ARTE® rope gasket kit is available on your local ARTE® dealer. -
Page 17: Chimney Sweeping
If you cannot inspect or clean the chimney by yourself, contact your local ARTE® dealer or a professional chimney sweep. -
Page 18: Information About Wood And Thermal Capacity
ARTE © fireplace |COSY LINE 17. Information about wood and thermal capacity Thermal Capacity Type of wood (Kcal/h – 1Kg) BIRCH 4800 SPRUCE 4588 BEECH 4578 4619 COMMON OAK 4548 POPLAR 4022 BIRCH Birch wood catches fire easily and warms well. It develops less smoke and embers than other sorts of wood and also it burns silently. -
Page 19: Dimensions
ARTE © fireplace |COSY LINE 18. Dimensions AR65 ST65 All dimensions are in (mm) & NSTALLATION MANUAL USER GUIDE... - Page 20 ARTE © fireplace |COSY LINE TR65 COL/COR65 All dimensions are in (mm) & NSTALLATION MANUAL USER GUIDE...
- Page 21 ARTE © |COSY LINE fireplace 19. Technical Specifications TECHNICAL SPECIFICATIONS UNITS ST65 AR65 TR65 COL65 | COR65 Kcal/h 15480 12900 12900 14190 *Total heat output 16.5 Recommended hourly consumption of firewood Kg/h Efficiency Exhausts temperature °C CO emissions 0.151 0.289 0.289...
-
Page 22: Warranty
Wearing parts like gaskets, vermiculite panels and glass Smoke and soot damage Natural discoloration or deviating colors on the outer cladding Cracks in the combustion chamber that have no effect on the safe functioning of the ARTE ® NEAT fireplace... -
Page 23: Notes
ARTE © fireplace |COSY LINE NOTES S/N: & NSTALLATION MANUAL USER GUIDE...
