Page 3: Table Of Contents
....................................13 - System with open expansion tank ......................................14 6. Operating Instructions ......................................... 15 6.1. Before the first use of the ARTE® MENTOR fireplace ................................ 15 6.2. About ARTE® MENTOR fireplace ......................................15 6.3. General information ..........................................16 - When the fireplace paint dries ....................................... - Page 4 - Cleaning of heating water tubes ......................................27 - Annual maintenance ..........................................27 - How to clean the inside parts of ARTE® MENTOR ................................28 9.4. Internal parts ............................................28 - Removal of baffle ............................................. 28 - Removal of side vermiculites ........................................28 - Removal of back vermiculites .......................................
-
Page 5: Arte ® Fireplace - A Greek Quality Product
| MENTOR Hydro 1. ARTE ® FIREPLACE - A GREEK QUALITY PRODUCT Thank you for buying an ARTE® fireplace - we believe that you will have as much pleasure from our product as we have, producing it. Your ARTE® fireplace is made in such a way, to extract the maximum possible energy from the wood with the minimum possible emissions, using the most innovative technology and the most robust design –... -
Page 6: Wood Types And Calorific Value
5.000 4.800 4.731 4.619 4.578 4.588 4.548 4.457 4.100 (Kcal/Kg) 860Kcal/h = 1 kW/h Table 2.4.1 The values are based on 15% residual wood moisture. An ARTE fireplace can be fired with all of the above wood types. ® Page... -
Page 7: Determining The Heat Output
NDORSEMENTS AND CERTIFICATIONS 3.1. Endorsement The ARTE® fireplace you chose has been tested according to EN13229. The declaration of performance (DoP) of each MENTOR model can be found at the URL of the company for each model. 3.2. Features marking plate ARTE®... -
Page 8: Packaging
| MENTOR Hydro 4. P ACKAGING ARTE® is devoted in protecting the environment, so we use as much recyclable materials as possible and the least amount of packaging materials without compromising the secure transfer of our products. 4.1. Unpacking the fireplace Your product will be delivered on a wooden palette which is lined with wooden side panels (Pic. -
Page 9: Installation And Fire Safety
INSTALLATION & USAGE MANUAL FIREPLACE | MENTOR Hydro 5. I NSTALLATION AND FIRE SAFETY During the installation of the fireplace, It is OBLIGATORY to respect the National and European rules and local regulations concerning building matter and fireproof rules. The installation MUST be inspected by a qualified auditor, prior to lighting the fireplace. Also, the appropriate local authorities must be informed. -
Page 10: Flue Safety Instructions
Follow the operating instructions supplied with the product to help prevent fire and protect the environment. 5.5. Flue safety instructions Prior to installing the fireplace ARTE® the chimney sweep or a qualified technician should check the condition and operation of your chimney in accordance with the standards EN13384-1 &... -
Page 11: Chimney Cap
INSTALLATION & USAGE MANUAL FIREPLACE | MENTOR Hydro Pic. 5.5.2 Pic. 5.5.3 The ending of the chimney must be at least 50cm above the top of the roof. If there is more than one chimney on the roof, they must be positioned at least 2m apart. ... -
Page 12: Connecting The Fireplace With The Flue
INSTALLATION & USAGE MANUAL FIREPLACE | MENTOR Hydro 5.6. Connecting the fireplace with the flue It is necessary that the flue gas tube is connected to a certified conduit with the same diameter as the fireplace, by following the dimensions of the adjacent image (Pic. 5.6.1). For fireplace MENTOR the diameter of the flue is 200mm for fireplaces with width 80cm and 90cm, and 250mm for fireplaces with width 100cm. -
Page 13: Hot Air Abduction
5.9. Connection with the heating system The fireplace ARTE® MENTOR can be installed to work individually or in collaboration with any another water heating device to be used for central or floor heating. The installation is made by using 1’’ hoses . -
Page 14: Connection Of Supply - Return
- Connection of supply - return The ARTE® MENTOR fireplace, allows you to use 2 different pairs for input and output (pair Α and pair Β). These pairs can be seen in Pic. 5.9.4 with the numeration 1,2 (pair Α) and 3,4 (pair Β). Your device is delivered with the pair A closed. -
Page 15: Overheating Protection
- Overheating protection In order to ensure the integrity of the heating network and the device, ARTE® provides you with an option to place a safety configuration to protect the heating circuit and the water jacket from overheating (Pic. 5.9.6). -
Page 16: System With Closed Expansion Tank When The Fireplace Is At The Same Level With The Heaters
INSTALLATION & USAGE MANUAL FIREPLACE | MENTOR Hydro - System with closed expansion tank when the fireplace is at the same level with the heaters Pic. 5.9.10 12 | Page... -
Page 17: System With Closed Expantion Tank
INSTALLATION & USAGE MANUAL FIREPLACE | MENTOR Hydro - System with closed expantion tank when the fireplace is below the heaters Pic. 5.9.11 13 | Page... -
Page 18: System With Open Expansion Tank
- System with open expansion tank Pic. 5.9.12 ARTE® MENTOR fireplace is delivered with a stainless steel cooling coil already installed in which you must install a cold water supply (Pic. 5.9.6) so in case the water inside the water jacket exceeds 95 C the overheating safety valve will open and rapidly cool the water jacket. -
Page 19: Operating Instructions
NSTRUCTIONS 6.1. Before the first use of the ARTE® MENTOR fireplace One of our qualified representatives has already provided you with instructions on how to operate the ARTE® MENTOR fireplace that you just acquired. The operating instructions below describe in detail the steps to follow so you do not encounter any difficulties during the operation of the fireplace. -
Page 20: General Information
- When the fireplace paint dries ARTE ® products are painted in spray booth with as more environmentally friendly and ecological colors as possible. There is although a possibility that the first few times the fireplace is lighted, the paint emits an odor. Let the fire burn with intense convection until all traces of gas disappear and there is no longer a smell. -
Page 21: Usage Of The Detachable Handle ("Cold Handle")
If you prefer the usage of a handle of your own choice or the ARTE’s one, you can order special tools from ARTE in order to adjust them. The handle that you will choose from the market must be able to withstand high temperatures and agrees with the dimensions of Pic. -
Page 22: Adjustment Of Combustion Air
6.5. Adjustment of combustion air ARTE® MENTOR fireplace gives you the opportunity to adjust the primary combustion air intake by the LCD control panel. The control device controls an electric motor where the changes that are done on the control panel are transferred to the combustion air intake damper. -
Page 23: Using The Regulator
INSTALLATION & USAGE MANUAL FIREPLACE | MENTOR Hydro - Using the regulator All of the regulator functions can be controlled via the control panel (Pic. 6.5.1). When the regulator is not operating, the light (1) illuminates amber to notify that it is in standby mode and the screen displays the water temperature in the water jacket, the time and the time zone (if it is enabled). -
Page 24: System Operation Screem
INSTALLATION & USAGE MANUAL FIREPLACE | MENTOR Hydro - SYSTEM OPERATION screem Water jacket DHW pump DHW boiler temperature (Τ3) status temperature (T1 & T2) HC pump Secondary control status relay status Current Time zone DHW pump time (if enabled) operation mode This screen is fixed and to change it you must press the TOGGLE (7) key. -
Page 25: Times Zones Mode
INSTALLATION & USAGE MANUAL FIREPLACE | MENTOR Hydro - TIMES ZONES mode The regulator allows you to operate your fireplace with automatic switching between modes based on certain time zones, using the CLOCK and SPECIAL modes. CLOCK SPECIAL The regulator time zones are not enabled. Activation and potential adjustment to the parameters must be made in agreement with the installer and if you understand the way they operate. -
Page 26: Alarm Screen
INSTALLATION & USAGE MANUAL FIREPLACE | MENTOR Hydro - ALARM screen This screen is displayed when there is one of the following situations: Failure of the sensor on the top of the boiler (T1). The screen displays Alarm type WAW temp. -
Page 27: Lighting Without Co Emissions (From Top To Bottom)
INSTALLATION & USAGE MANUAL FIREPLACE | MENTOR Hydro 7.2. Lighting without CO emissions (FROM TOP TO BOTTOM) Place logs, whose weight depends on the size of the fireplace, alternately (once lengthwise – once widthwise). Add some torch (1-2 kg) above in length-widthwise arrangement together with 2-3 kindling tablets or 3-4 wrapped newspaper sheets and light them As soon as the fire leaves a thick layer of cinder, you can add more firewood. -
Page 28: Tertiary Combustion
Over a period of time, the painted surface may become slightly grey. A canister of touch-up ARTE ® spray paint should be available from your fireplace supplier. This can be applied - in accordance with the instructions - in just a few minutes. -
Page 29: Internal Maintenance
- Glass ARTE® MENTOR fireplace has a double ceramic glass in the window of the combustion chamber in order pyrolysis to come faster and more heat to be kept inside the chamber, supplying it at the water tank. If the fireplace is generally operated at the correct temperature, there should be little or no soot on the glass. -
Page 30: Gasket
Components in the flame route, the gasket and the paint finish are not covered by the warranty. All of these service parts can be bought from your ARTE ® dealer, and we recommend that damaged parts are replaced as soon as possible to avoid consequential damage. -
Page 31: Cleaning The Fireplace And The Flue
ΑΤΤΕΝΤΙΟΝ!!! The central water tank pipe (Φ150 mm) is smaller than the flue. The flue is Φ200 mm for fireplaces with width 80cm and 90cm, and 250mm for fireplaces with width 100cm. If you cannot inspect or clean the chimney by yourself, contact your local ARTE ® dealer or a professional chimney sweep. -
Page 32: How To Clean The Inside Parts Of Arte® Mentor
FIREPLACE | MENTOR Hydro - How to clean the inside parts of ARTE® MENTOR During the annual visit of your local chimney sweep and during the cleaning of internal parts of the fireplace, it is recommended to remove all internal parts of the combustion chamber to be also cleaned. (Chapter 9.4) The cleaning of the fireplace must be done ONLY when the device is cold. -
Page 33: Removal Of Bottom Vermiculites (Floor)
INSTALLATION & USAGE MANUAL FIREPLACE | MENTOR Hydro - Removal of bottom vermiculites - Removal of bottom vermiculites (Floor) (Front side) Pic.9.4.5: After the removal of the side vermiculites, lift up Pic.9.4.6: After the removal of the floor vermiculites, pull the vermiculite slightly right and then pull it inwards, the vermiculite and then pull it inwards. -
Page 34: Drainage Of Water Tank
9.5. Drainage of water tank For any reason that requires the drainage of the tank, ARTE has anticipated and equipped the MENTOR fireplace with a drainage layout. This layout includes a valve, which is located at the back of the combustion chamber (Table 6.2.1. -
Page 35: Tips And Tricks For Resolving Issues
Check if there is adequate draft into the flue, light a test fire Make sure there is sufficient air supply We hope you enjoy many years of carefree warmth with ARTE ® MENTOR fireplace. Some initial experimentation with loading and operating techniques will help you decide your normal routine. -
Page 36: Dimensions And Technical Specifications
INSTALLATION & USAGE MANUAL FIREPLACE | MENTOR Hydro 11. D IMENSIONS AND TECHNICAL SPECIFICATIONS MODEL DIMENSION ST80 Hydro ST90 Hydro ST100 Hydro MENTOR MENTOR MENTOR A (cm) B (cm) 22,4 25,2 C (cm) Φ20 Φ25 D (cm) E (cm) F (cm) 19,5 Table 11.1 32 |... - Page 37 INSTALLATION & USAGE MANUAL FIREPLACE | MENTOR Hydro MENTOR ST 80 Hydro MENTOR ST 90 Hydro MENTOR ST 100 Hydro TECHNICAL SPECIFICATIONS UNITS Kcal/h 15500 20600 17200 22400 18100 24100 Total heat output Kcal/h 11600 14600 12500 15500 13300 17200 Total heat output In water 13.5 14.5...
-
Page 38: Notes
INSTALLATION & USAGE MANUAL FIREPLACE | MENTOR Hydro 12. N OTES 34 | Page... - Page 39 1.3 Responsibility καταναλωτή και το αντίστροφο, ομοίως δεν περιλαμβάνεται στην εγγύηση και δεν βαρύνει την εταιρία. It is hereby expressly stated that ARTE does not bear any accountability Στα πλαίσια της εγγυήσεως αφαιρείται από τις υποχρεώσεις τις εταιρίας civil, criminal or other, for accidents that may be caused by total or οτιδήποτε...
- Page 40 1.6 Χρήση warranty. ARTE guarantees that, even if this is not covered by the warranty, it will Η χρήση της συσκευής πρέπει να γίνεται σύμφωνα με όλα τα πρότυπα still provide quali ed technicians to provide technical services as well as ασφαλείας...
