Project Source F301E706CP Manual page 5

ASSEMBLY INSTRUCTIONS
Note: Numbered arrows within steps indicate
sequence of actions.
1. Shut off main water supply before installation.
2. Note the suggested installation distance between
shower arm (A), handle (E), and spout (G).
3. Attach hot and cold supplies to handle valves of
valve body (D). For threaded connections, wrap
thread seal tape around threaded ends before
connecting. Recommended distance from center of
pipe to finished wall is 1-3/4 to 3 inches.
1
1
2
2
A
E
3
3
1 - 3
t o 3
3-1
2
5
3 0 i n .
S h o w e
r O n l y
6 i n . M
4 8 i n .
S h o w e
r O n l y
G
all
i n .
/ 4
i n .
D
1
4 8 i n .
T u b &
S h o w e
r
i n .
3 0 i n .
T u b &
S h o w e
r
1
