- Page 1 M 9 U S E R G U I D E © 2 0 2 2 E T E R O S T E C H N O L O G I E S I N C . A L L R I G H T S R E S E R V E D | M O B I U S T R I M M E R . C O M...
- Page 2 T A B L E O F CONTENTS...
- Page 3 W E L C O M E M ob iu s M9 S or ter S A F E T Y I N S T R U C T I O N S Gen e ra l S a fe ty an d Dis cl a im ers S A F E T Y P R E C A U T I O N S S afety C h e ckli st S E R V I C E S &...
- Page 4 This User Guide is a comprehensive manual covering the operation and maintenance of the M9 Sorter machine as of the date of publication. ETEROS TECHNOLOGIES reserves the right to make updates to the machine from time to time. In the event of an update, this User Guide will remain appropriate for the safe operation and maintenance of your unit.
-
Page 5: Safety Instructions
ETEROS TECHNOLOGIES recognizes that our equipment can be used for processing herbs, hops, flowers and many other products. It is not the responsibility of ETEROS TECHNOLOGIES to confirm alternative applications for our equipment. -
Page 6: Safety Precautions
G E N E R A L SAFETY PRECAUTIONS Safety Precaution Checklist READ and become familiar with the entire User Guide. LEARN the equipment applications, limitations, and possible hazards. DO NOT USE THE DEVICE IN A DANGEROUS ENVIRONMENT or damp or wet locations. - Page 7 SERVICES & REPAIRS Repairs may only be carried out by Eteros Technologies or a designated authorized agent (service technician). Should the need arise, please notify us: ETEROS TECHNOLOGIES 26 Industrial Ave. Carleton Place, Ontario, Canada K7C 3T2 www.eteros.com 1.866.874.6244 Improper interfacing, improper repair, or unauthorized modification could result in void warranty claims.
- Page 8 I N I T I A L SETUP Initial Assembly & Inspection Inspect the crate and crate contents to ensure no damage occurred during shipping. Carefully remove M9 Sorter from crate. Insert hopper Pins into Adjustment Blocks to lock hopper in position. The blocks are mounted on the opposite side of their intended position for shipping purposes.
- Page 9 This support is to ensure no sagging while shipping in the inner plate Inspect the crate and crate contents to ensure no damage occurred during shipping. Carefully remove M9 Sorter from crate. The support will need to be removed on either end of the Sorter by removing the hex bolts.
- Page 10 Remove and Install Belts and Rollers Unplug the machine. Remove the overflow shelf and side panels. Locate the belt tensioner on the infeed side of the M9. Pull out the adjustment plunger and move the entire tension assembly up to the maximum height.
- Page 11 Working through the openings on the two ends and tailgate, pull a belt away from the rollers and out of the machine. As necessary, proceed with removing some or all of the belts in the same manner. Note: Removing the rollers can be done with or without the belts in place.
- Page 12 G E T T O K N O W Y O U R MOBIUS M9 SORTER G U I D E H O P P E R R O T O R S H A F T E M E R G E N C Y S T O P...
- Page 13 W H A T ' S I N T H E Your M9 Arrives With The Following Components: Your Mobius M9 Sorter comes lightly assembled, tested, and ready for operation. When unpacking the device, please ensure the following items are included:...
-
Page 14: Operation
G E N E R A L OPERATION Control Panel Overview E-STOP - Emergency stop button - stops all moving parts on the device. PRESS THE E-STOP BUTTON AT ANY TIME TO STOP ALL MOVING PARTS AND TURN OFF THE MACHINE Buttons on HMI Screen: START BUTTON - Green button energizes the motor to start turning the belts. -
Page 15: Cleaning And Maintenance
Polycarbonate Covers. Preventative Maintenance Eteros recommends that the pulleys and belts be cleaned off regularly to avoid buildup of resin on these parts. This cleaning process should take place at the end of each session or more frequently, depending on the operating environment and condition of material being processed. -
Page 16: Specifications
SPECIFICATIONS Wet / Dry Flower Capable Construction Anodized Aluminum & 304 Stainless Steel Speed & Adjustments HMI Control 11 Speed Settings Belt Material Belt Diameter Polyurethane 5 / 16" Number of Belts Belt Drive Motor 1 / 10HP Power Requirements Tool-less Disassembly 110 V - 1.5 A Width... - Page 17 1 . 8 6 6 . 8 7 4 . 6 2 4 4 I N F O @ M O B I U S T R I M M E R . C O M M O B I U S T R I M M E R . C O M...
- Page 18 © 2 0 2 2 E T E R O S T E C H N O L O G I E S I N C . A L L R I G H T S R E S E R V E D | M O B I U S T R I M M E R . C O M...
