Seltron ZCE6 Basic Manual

Zone heating / cooling controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Zone heating / cooling controller
ZCE6 Basic and ZCE6 Advance
EN
Instructions for use and setup

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZCE6 Basic and is the answer not in the manual?

Questions and answers

Related Manuals for Seltron ZCE6 Basic

Summary of Contents for Seltron ZCE6 Basic

  • Page 1 Zone heating / cooling controller ZCE6 Basic and ZCE6 Advance Instructions for use and setup...
  • Page 2 INTRODUCTION ZCE6 controllers have been designed for the control of zone heating and/or cooling. The control is carried out using thermal actuators on the distributor valves based on the temperatures obtained from room units. There are six independent temperature zones with the possibility of controlling fourteen heating-cooling units in total.
  • Page 3 APPEARANCE OF THE CONTROLLER 1-Connection terminals for controller power supply (230V~). 2-Connection terminals for circulation pump, energy source and mixing valve control. * 3-Connection terminals for the control of 24V~ thermal actuators.** 4-Selector switch for the control voltage of thermal actuators. ** 5-LED lights for the signalisation of operation.
  • Page 4 SIGNALISATION OF OPERATION Signalisation of temperature zone operation. When the LED light is on, the thermal actuators connected to the zone are in the open state, and vice versa. Signalisation of circulation pump output operation. When the LED light is on, the output is active. * Signalisation of energy source output operation.
  • Page 5 MENU In the menu, we carry out basic settings of the controller. We move from the home screen to the menu by holding the key for 2 seconds; we move between individual groups in menu by pressing the key. English 5...
  • Page 6 MENU – HYDRAULIC SCHEME The ZCE6 Advance controller has three hydraulic schemes to choose from, the ZCE6 Basic only 1 scheme. Hydraulic schemes are shown in chapter »Hydraulic schemes«. Example: Shift from scheme 1 to scheme 3. 6 English...
  • Page 7 MENU – PAIRING OF ROOM UNITS With the pairing process, we connect the RCD room unit with the controller and at the same time assign zones to it. Example: Pairing the RCD room unit with zone 1 and 2. English 7...
  • Page 8 MENU – MASTER CONTROLLER If more controllers are connected to the BUS connection, one controller must be set as the leading (Master) controller. Example: Setting the master controller. 8 English...
  • Page 9 MENU – PAIRING OF THE CONTROLLERS (MASTER CONTROLLER) When more controllers are interconnected in the BUS connection, the controllers must be connected – paired. Example: Activation of the pairing process on the master controller. English 9...
  • Page 10 MENU – PAIRING OF CONTROLLERS (SLAVE CONTROLLER) After activating the pairing process on the master controller, pairing on slave con- trollers must also be activated. Example: Activation of the pairing process on the first slave controller. 10 English...
  • Page 11 MENU – MANUAL MODE During start-up or testing of the controller, the zone outputs, circulation pumps, source or mixing valve can be manually switched on or off. Example: Manual ON / OFF of the zone 3 output. English 11...
  • Page 12 MENU – RESET There are three types of resets available: RESET 1 – pairing reset of room units, RESET 2 – pairing reset of controllers, RESET 3 – reset of the entire controller to the factory settings. Example: Activation of reset 3. 12 English...

  • Page 13: Controller Parameters

    GENERAL PARAMETERS C1.1 HYDRAULIC SCHEME Selection of hydraulic scheme or system configuration. The 1 ÷ 3 ZCE6 Basic only has scheme 1 available. C1.2 TYPE OF THERMAL This setting defines whether the thermal actuators are NC 1 - NC ACTUATORS or NO type.
  • Page 14 Function Description Setting Default rame- range value C1.14 ANTI-BLOCK FUNC- All control outputs that haven’t been activated in the last 0 - NO TION week are activated on Friday between 20:00 and 20:15. 1 - YES Circulation pump runs for 30 seconds, thermal actuators are activated simultaneously for 5 minutes, mixing valve is opened and closed.
  • Page 15 Function Description Setting Default rame- range value C3.4 TYPE OF CIRCULA- This setting inverts the operation of the circulation pump 1 - NORMAL TION PUMP OUTPUT output. 2 - INVERTED C3.12 SOURCE SWITCH- Setting of source switch-on delay. 0 ÷ 900sec ON DELAY C3.13 SOURCE SWITCH- Setting of source switch-off delay.
  • Page 16 Function Description Setting Default rame- range value C4.15 MIXING VALVE The setting indicates how frequent the controller corrects 0.5 ÷ 2.0 I-CONSTANT the position of the mixing valve. Lower value means low frequency and higher value means higher frequency of mixing valve position corrections.
  • Page 17 Function Description Setting Default rame- range value C7.7 BACKUP OPERA- This setting determines the percentage of zone 5 opera- 0 ÷ 50% TION OF ZONE 5 tion in a period. (PERIOD PERCENT- AGE) C7.8 BACKUP OPERA- This setting determines the percentage of zone 6 opera- 0 ÷...
  • Page 18 Function Description Setting Default rame- range value C8.6 INFLUENCE OF Setting of the influence of room unit on the heating zone 0 - ROOM UNIT 1 ROOM 1 - ROOM UNIT 2 UNIT ON ZONE 6 2 - ROOM UNIT 3 3 - ROOM UNIT 4 4 - ROOM UNIT 5 5 - ROOM UNIT 6...
  • Page 19 Function Description Setting Default rame- range value C8.12 ROOM UNIT ON Setting of room unit to be connected to wire input 6. 0 - ROOM UNIT 1 WIRE INPUT 6 1 - ROOM UNIT 2 2 - ROOM UNIT 3 3 - ROOM UNIT 4 4 - ROOM UNIT 5 5 - ROOM UNIT 6...

  • Page 20: Description Of System Operation

    DESCRIPTION OF SYSTEM OPERATION Zone control (thermal actuators) Parameter C1.2 is used to select the type of thermal actuators connected to the controller. Type NC opens the thermal actuator when the output is under control voltage, type NO opens the thermal actuator when there is no control voltage at the output.
  • Page 21 Room units Up to 6 RCD room units can be connected to the controller. Wire and wireless room units can be connected. Wire units must connected to the connection termi- nals with label “room units” (1, 2, 3, 4, 5, 6), and for the operation of wireless room units, antenna must be connected to the terminal “ANTENNA”.
  • Page 22 Mixing valve (ZCE6 Advance) The mixing valve is controlled by closing and opening impulses (P-constant) in time periods (I-constant). When in heating mode, the measured temperature of supply line is below the desired temperature, the mixing valve opens, when the measured temperature is above the desired temperature, the mixing valve closes.
  • Page 23 Digital input “cooling” The digital input “cooling” enables a remote switchover of operation from cooling to heating. When a short circuit is detected on the digital input “cooling”, the control- ler switches over to the cooling mode. For the operation of digital input “cooling”, the parameter C1.6 must be set to value English 23...
  • Page 24 The input “dew point” enables the connection of digital or analogue dew point sensor. Parameter C1.7 is used to set the type of dew point sensor, which is connected to the input “dew point”. C1.7=0 - input is not used, C1.7=1 - digital sensor of type NC (short circuit when dew point is detected), C1.7=2 - digital sensor of type NO (open connection terminals when dew point is detected),...
  • Page 25 Output “10V” Parameter C1.15 is used to set the output “10V” operation mode: C1.15=1 - the voltage of 10V for sensor power supply is always available at the output, C1.15=2 - the 0-10V output signal is used to operate the source. Dependency graph of output voltage from desired temperature of supply line: Heating Cooling...

  • Page 26: Backup Operation

    Backup operation When the communication with the room unit is lost, the controller switches to back- up operation. Delayed switching to backup operation is set with parameter C7.1. In backup operation, the zone is switched on in a period set with parameter C7.2. The operating time (percentage of period) of a certain zone is set with parameters C7.3 (for zone 1) to C7.8 (for zone 6).

  • Page 27: Controller Installation

    CONTROLLER INSTALLATION English 27...

  • Page 28: Electrical Connection

    ELECTRICAL CONNECTION Each project must be based on your calculations and plans, which have to be in accordance with regulations in force. Figures and text in this instruc- tions are only an example and the publisher shall not be held liable. The liability of the publisher for unprofessional or incorrect interpretation and the consequential damage shall be expressly excluded.
  • Page 29 Setting voltage for the control of thermal actuators The controller enables the connection of thermal actuators with control voltage of 230V~ or 24V~. The controller is pre-configured for the control with a voltage of 230V~. For the control with a voltage of 24V~, the protective cover has to be removed, the switch has to be put in the position of 24V~ and a special purpose transformer with a voltage of 24V~ has to be connected to the connection terminal with a label of 24V~.

  • Page 30: Hydraulic Schemes

    HYDRAULIC SCHEMES Hydraulic scheme 1 (230V~) - ZCE6 Basic and Advance 30 English...
  • Page 31 Hydraulic scheme 1 (24V~) - ZCE6 Basic and Advance English 31...
  • Page 32 Hydraulic scheme 2 (230V~) - ZCE6 Advance 32 English...
  • Page 33 Hydraulic scheme 2 (24V~) - ZCE6 Advance English 33...
  • Page 34 Hydraulic scheme 3 (230V~) - ZCE6 Advance 34 English...
  • Page 35 Hydraulic scheme 3 (24V~) - ZCE6 Advance English 35...
  • Page 36 BUS connection of the controllers For the expansion of the system with more zones or branches, it is possible to connect more controllers (6 at most) in a BUS connection. The first controller in the BUS connection (which controls the energy source, mixing valve and pump) has to be set as the leading (Master) controller, whereby the other controllers are subordinate (Slave) controllers (see chapter “MENU –...

  • Page 37: Error Description

    ERROR DESCRIPTION Signalisation Error On the home screen, the LED Error in connection to the room unit. light exhibits short or long What can I do? flashes to show the zone oper- For the wired connection, check the connec- ation. tion on the room unit and the controller.

  • Page 38: Technical Specifications

    TECHNICAL SPECIFICATIONS ZCE6 Basic ZCE6 Advance Weekly program timer Power supply 230V~, 50Hz Timer power supply Battery R1025 (Li-Mn) 3V Timer accuracy +/-1s (24h) at 20°C Temperature sensor type Pt1000 Maximum energy consumption 2100W Energy consumption in the standby 0.5W...

  • Page 39: Disposal Of Waste Electrical And Electronic Equipment

    DISPOSAL OF WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT Disposal of waste electrical and electronic equipment (applies to EU member states and other European countries with a waste separation system). This symbol on the product or packaging indicates it should not be discarded as household waste.
  • Page 40 SELTRON d.o.o. Tržaška cesta 85 A SI-2000 Maribor Slovenija tel: +386 (0) 2 671 96 00 V1.0 fax: +386 (0) 2 671 96 66 http://www.seltron.si email: info@seltron.si ©2019 We reserve the right to errors, changes and improvement without prior notice.

This manual is also suitable for:

Zce6 advance
