Digital Proportional Radio Control System
When the model is designed, there are changes in the size of the structure and the specification may not be
unified. In addition, there may be different sizes of operator's habitual actions. The servo travel function can be used to
set the travel amount required for each channel to adjust the corresponding structure for the best match, to obtain the
required operation effect. For example: You want to operate that the turning action is not so large, you can adjust the
value of the direction channel at both ends to be smaller. In this way, the turning action should be smaller, with less
likely to be tailspin.
Function settings:
1.In the setting menu, select the servo travel function menu and press the OK key.
2Select the channel you need to adjust by the pressing UP/DOWN key. Press the OK key to enter the edit state. Then
adjust it by the pressing UP/DOWN key. Press return after adjustment.
3.Test the function to confirm all the servo or motor action directions are the same as the actual expected travels.
6.3 Settings-Neutral Trim:
Fu n ct ion: Set and adj ust the ne utra l data of ea ch ch a nn e l.
T his fu nct ion i s mainl y u se d for the trim o f the mo del in a ss embly an d de bugg in g . Fo r
example, the v eh ic le is stationar y a nd the tran sm i tter trav ers in g h a n dwh ee l i s i n the n eutral
position; if y ou fi nd t h at the whe els de viate fro m the strai gh t di re ct io n , i t ca n be ea s ily co rre cte d
through this funct i on. At this tim e , it i s di fficult a n d in con ve n ie n t to adj ust th e mo del str uct ure .
Note: B efore s ett ing t his functi on, m ake sure that the ch an n e l i s m ovi n g i n the co rrect di re ction.
Function settings:
1.In the setting menu, select the neutral trim function menu and press the OK key.
2.Select the channel you need to adjust by the pressing UP/DOWN key. Press the OK key to enter the edit state. Then
adjust it by the pressing UP/DOWN key. Press return after adjustment.
3.Observe and test the function to ensure that the settings work as expected.
6.4 Settings-Bidirectional Rate:
Bidirectional rate allows you to quickly adjust the output value of certain channels to achie ve
the best manipulation effect . The rate function can be used to set the direction channel channel 1,
throttl e ch annel ch anne l 2 up pe r, bra ke ch an n el 2 lo w er ch a nn e l, a n d outpu t data rate . T he range
is 0-100%. You can als o set the swi tc h-on an d switch -o f f. Th e tw o co n tro l m ode s can be s witc he d
through the ap pli cat ion swi tch setti ng se e th e Ke y Setti n g me n u.
Function settings:
1.In the setting menu, select the bidirectional rate function menu and press the OK key.
2.Select the channel you need to adjust by the pressing UP/DOWN key. Press the OK key to enter the edit state. Then
adjust it by the pressing UP/DOWN key. Press return after adjustment. In the adjustment, observe by operating the
corresponding channel handwheel and throttle trigger.
3.Test the function to confirm that all channel outputs operate normally as expected.
10
FS-G7P
