MSI MS-9A69-U Series Manual page 14

Overview
Line-Out Jack
6
This connector is provided for headphones or speakers.
USB 2.0 Port
7
The USB (Universal Serial Bus) port is for attaching USB devices such as
keyboard, mouse, or other USB-compatible devices.
Extend Switch Connector
8
This connector is provided for remote power button control.
Phoenix DC Power Connector
9
The system is designed with a Phoenix connector that carries DC input.
Important
Your power source can either be connected to the Power Jack or the Phoenix
DC Power Connector. Avoid connecting to both simultaneously.
Power Jack
10
Power supplied through this jack supplies power to the system.
Important
Your power source can either be connected to the Power Jack or the Phoenix
DC Power Connector. Avoid connecting to both simultaneously.
GbE RJ45 Port
11
The standard RJ45 LAN jack is provided for connection to the Local Area
Network (LAN). You can connect a network cable to it.
Active
LED
USB 3.2 Gen 1 Port
12
USB 3.2 Gen 1, the SuperSpeed USB, delivers up to 5Gbps high-speed
data transfer for various devices, such as storage devices, hard drives, video
cameras, etc.
1-6
LED LED Status
Off
Active
Yellow
LED
Speed LED
Blinking
Off
Speed
Green
LED
Orange
Description
No link
Linked
Data activity
10 Mbps connection
100 Mbps connection
1 Gbps connection
