Panama Chair with Cushion
Assembly Instructions -
066506
Please keep for future reference
Dimensions
Width - 62cm
Depth - 60cm
Height - 88cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08450 778 888
Issue 1 - 26/05/10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Homebase PANAMA 066506
Summary of Contents for Homebase PANAMA 066506
- Page 1 Panama Chair with Cushion Assembly Instructions - 066506 Please keep for future reference Dimensions Width - 62cm Depth - 60cm Height - 88cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08450 778 888 Issue 1 - 26/05/10...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on the • We do not product during assembly, this could components and tools listed on recommend the cause damage.
-
Page 3: Components - Parts
Components - Parts If you have damaged or missing components, call the Customer Helpline: 08450 778 888 Please check you have all the parts listed below Back board x1 (86x45cm) Armrest x2 (62x 46cm) Seat board x1 (44x36/46cm) Front board x1 (48x30 cm) Co mponents - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. - Page 4 Assembly Instructions Step 1 Assembly frame Use 30 mm screw and metal washer with plastic washer to fix the armrest to the back board. Repeat above step for each of the 4 positions. Important: Do not fully tighten all screws until assembly is complete.
- Page 5 Assembly Instructions Step 3 Turn the armchair to the upright position and tighten all the screws. with the Allen key Seal the screws with plastic cap Step 4 Fit the seat board onto the armchair assembly with the seat side uppermost...
- Page 6 Put on the cushion to fit for the seat board. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 08450 778888 Homebase Limited 489-499 Avebury Boulevard Saxon Gate West Central Milton Keynes Bucks,MK9 2NW...
- Page 7 Panama Coffee Table Assembly Instructions - 072038 Please keep for future reference Dimensions Width - 45cm Depth - 45cm Height - 40cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08450 778 888 Issue 1 - 26/05/10...
- Page 8 This product is components and tools Assemble on a soft manufactured from listed on page 2. level surface to avoid toughened safety glass. damaging the unit or your Remove all fittings from In the unlikely event that floor. the plastic bags and Dispose of all packing the glass fails it will break separate them into their...
- Page 9 Components - Parts If you have damaged or missing components, call the Customer Helpline: 08450 778 888 Please check you have all the parts listed below Main board x 2 Side board x 2 3 Glass x 1 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly.
- Page 10 Make sure the plastic support not detached from table rim. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 08450 778888 Homebase Limited 489-499 Avebury Boulevard Saxon Gate West Central Milton Keynes Bucks,MK9 2NW...
