Thank you for purchasing this product. Please read the instructions carefully before use to ensure safe and
satisfactory operation of this product.
Pre-assembly preparation
Please ensure instructions are read in full before attempting to assemble this product.
Necessary Tools :
Please check the pack contents before attempting to assemble this product. A full checklist of components is
given in this leaflet, If any components are missing, please contact the retailer from whom you bought this
product.
This product takes approximately 20 MINUTES to assemble with 2 PEOPLE.
All assembly should be performed on a flat, stable, clean and soft surface.
This product is HEAVY , it should be assembled as near as possible to the point of use. TAKE CARE
WHEN LIFTING to avoid personal injury and (or) damage to the product
The fitting pack contains SMALL ITEMS which should be KEPT AWAY FROM YOUNG CHILDREN.
IMPORTANT: Retain these instructions for future reference.
CONSOLE TABLE
( Included )
Stock number: 420 7 - 1 9
Page : 1
IW- 1 7-420 7 -06-0-0
Advertisement
Table of Contents
Related Manuals for Homebase CONSOLE TABLE
Summary of Contents for Homebase CONSOLE TABLE
- Page 1 CONSOLE TABLE Stock number: 420 7 - 1 9 Thank you for purchasing this product. Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. Pre-assembly preparation Please ensure instructions are read in full before attempting to assemble this product.
- Page 2 3 x 2 Fittings and parts checklist Item Description Qty. Item Description Qty. Top frame Metal leg Fixed shelf Cross dowel Small allen key Hex head bolt Large allen key Ø8 x 1 00 Hex head bolt Ø6 x 1 5 Page : 2 IW- 1 7-420 7 -06-0-0...
- Page 3 Step By Step Assembly Instructions Step 1 1.1 : Lay all parts on a flat, stable, clean and soft surface. 1 .2 : Insert 4x cross dowels (A) into the top frame ( 1 ) by placing each fitting (A) into the holes on top of each side apron as shown.
- Page 4 Step By Step Assembly Instructions Step 3 Secure metal legs (3) to top frame ( 1 ) by screwing 8x hex head bolts (B) into the cross dowels (A) are concealed in side apron of top frame ( 1 ) as shown. Use large allen key (E) to turn bolts (B) clockwise to fix.
- Page 5 Step By Step Assembly Instructions Step 5 5. 1 : Secure fixed shelf (2) to metal legs ( 3 ) by screwing 4x hex head bolts (C) into the inset fitting that are located on fixed shelf (2) as shown. Use small allen key (D) to turn bolts (C) clockwise to fix.
- Page 6 Care and Maintenance Wood Furniture Wood displays different grain patterns depending on which way they are cut - for example, the 'medullary ray' which can appear on oak furniture is a mark of good quality timber - these are just characteristics of the natural beauty of the wood.
