INSTALLATION ENGLISH Refer to the instructions contained in the system manual for wiring, maximum distances and confi guration operations. The housing may be used both in DIN bar mounting and wall mounting by means of screws and spacers; DESCRIPTION please take care of mounting it in dry and repaired environments. Use Urmet 1039/101 RJ45 connectors.
Page 3
SV124-0886 LEGENDA / KEY / LEGENDE / LEYENDA Alla Colonna Montante To Riser Vers La Colonne Montante A La Columna Montante CAT5- BLU/BLUE/ BLEU/AZUL Linea ~ Line ~ Ligne ~ BUS OUT Línea ~ Sch./Ref. 1039/20 Alimentatore di colonna per CAT5 ~230 CAT5 column power supply unit BUS IN...
