Assembly Guide

Bridge Wall Cabinet W500-600

IMPORTANT – Please read prior to installation

Thanks for purchasing a solid oak kitchen cabinet. Prior to commencing installation

please check the contents of this package to ensure that all necessary components

are included. Please contact us immediately via email if any parts appear to be miss-

ing.

Please ensure that you assemble the goods in a clean, dry area, with plenty of space,

and that you have the correct tools and equipment to hand. We recommend that you

read the instructions in full before you commence assembly; and if unsure we advise

an initial rehearsal of the installation procedure without physically assembling any

items. Only construct one cabinet at a time and follow the installation stages in order

without modification. During installation, be careful to keep the relevant fittings for

each cabinet together. Do not over-tighten screws, and ensure that any larger panels

are laid flat and protected.

We advise using a damp cloth and - if necessary - a small amount of liquid soap to

clean the cabinet. Do not use abrasive materials. For more information, please view

the full cleaning and aftercare guide on our website.

IFU-326.1

Need help?

Do you have a question about the W500-600 and is the answer not in the manual?

Page 1 Assembly Guide Bridge Wall Cabinet W500-600 IMPORTANT – Please read prior to installation Thanks for purchasing a solid oak kitchen cabinet. Prior to commencing installation please check the contents of this package to ensure that all necessary components are included. Please contact us immediately via email if any parts appear to be miss- ing.
Page 2 Panels Hardware IFU-326.1...
Page 3 Insert connecting bolts and dowels as shown in the diagram below. Apply a small drop of glue to each dowel before inserting. Attach wall hanging unit to the top of side panels using the screws m . IFU-326.1...
Page 4 Insert cams into the base and top panels as shown in the diagram below. Ensure that the arrow marking is pointing towards the outside edge of the panel. Connect the base panel to the side panel using the fittings inserted during steps 1 and 2.
Page 5 Slide the back panel between the grooves on the inside edge of panels It is advised to apply a small amount of glue along the grooves first. Connect the opposite side panel as shown in the diagram below. Tighten all the fittings by turning them in the direction of the arrow with a screwdriver.
Page 6 Joining Cabinets Cabinets should be joined be- tween each set of hinge holes on the inside edge of the side panel as shown in the diagram. Mark 25mm as a guide on a 3mm diameter drill bit using masking tape. Drill between the hinge holes into the cabinet side panel (18mm) and 7mm into the next until you reach...
