- Page 1 OWNER’S MANUAL BD/BC DUCTED TYPE SPLIT SYSTEMS CAPACITY RANGE: 8-25kW (English) (BD/BC)
- Page 3 CONGRATULATIONS ON CHOOSING A NEW BRAEMAR AIR CONDITIONER FOR YOUR HOME Your air conditioner is built from quality materials and engineered to provide many years of economical, trouble free cooling. Please take a few minutes to read these instructions so you have a full understanding of how to operate your air conditioner.
-
Page 4: Table Of Contents
Common problems with air conditioning units result from a failure to clean the air filter or alternatively, to replace it after it has been cleaned. Please check and clean the air filters by following the instructions on page 22 and 23 of this Manual. BRAEMAR BY SEELEY INTERNATIONAL... -
Page 5: Preface
1. PREFACE NOTE FOR THE HOME OWNER BEFORE INSTALLATION Your unit must be installed by a quali ed, licensed installer. The user should retain this Manual for future reference. To ensure the warranty does not become void, the unit must be Check the Product regularly maintained and serviced in accordance with the Upon receiving your unit, please inspect for damage. -
Page 6: Part Identi Cation
2. PART IDENTIFICATION Wall Control BRAEMAR BY SEELEY INTERNATIONAL... -
Page 7: How To Use The Wall Control
3. HOW TO USE THE WALL CONTROL NOTE : 7 day program only for 4 Zone control. 1). BASIC FUNCTION: The following features can be operated by buttons on the Display unit. Press ing button will turn the air conditioner on or off. When turned on, it will operate according to the setting shown on the Display unit. - Page 8 In this mode, “Cool” and “Heat” symbols will appear simultaneously on the display screen. NOTE : For the optimum energy ef ciency, we recommend you set the cooling temperature between 24-26ºC and the heating temperature between 18-20ºC. BRAEMAR BY SEELEY INTERNATIONAL...
- Page 9 3. HOW TO USE THE WALL CONTROL CONT. 2). ENHANCED FEATURES : The enhanced features of the system can be accessed by the user by choosing from the menu setting. Press MENU button to display the menu. NOTE : Exit by pressing the following button: ZONE 7 DAY CLOCK SETTING Set the clock by pressing the following button:...
- Page 10 Note : - To override the 7 DAY program, press button and hold for at least 5 seconds. The words "7 DAY" should start blinking on the display. - To deactivate the override, press the button and hold for at least 5 seconds. BRAEMAR BY SEELEY INTERNATIONAL...
-
Page 11: Operating Guide & Precautions
4. OPERATING GUIDE & PRECAUTIONS 4.1 OPERATING GUIDE The temperature should not be set above or below what you need. Otherwise it will result in increased energy costs. Clean the air lter every month for optimum ef ciency. Close windows and doors while operating the unit to save energy (and prevent leakage of conditioned air). -
Page 12: What To Check Before You Make A Service Call
This may need to be repaired. Check if the batteries are inserted correctly. Check if the batteries are at. If any of the below error codes appears please call Seeley International service on 1300 526 477 BRAEMAR BY SEELEY INTERNATIONAL... -
Page 13: Safety Instructions For Installation And Maintenance
(Call someone on quali cations of workers. the ground? Mobile phone etc.) Seeley International provides the following information as a • What condition is the roof in? Should the trusses, underside general guide to contractors and employees to assist in... -
Page 14: Indoor Unit Installation
���� ��� ��� ���� ��� ���� ���� ��� ��� �� BD21A ���� ��� ��� ���� ��� ��� ���� ��� ���� ���� ��� ��� �� BD25A Remark : Supply & Return air dimension are F x G BRAEMAR BY SEELEY INTERNATIONAL... -
Page 15: Outdoor Unit Installation
8. OUTDOOR UNIT INSTALLATION 8.1 WHERE TO INSTALL OUTDOOR UNIT: • The foundation must be solid enough to bear the weight and vibration of the unit. IMPORTANT: • The space around the unit must be adequate for ventilation. Local Council noise regulations and other relevant laws must be complied with when deciding where to locate •... - Page 16 8. OUTDOOR UNIT INSTALLATION CONT. DIMENSION (mm) Net Weight MODEL BC09A 1008 BC11A 1316 BC13A 1316 BC15A BC113A BC153A 1316 1474 BC183A BC213A 1552 1150 1552 BC253A 1150 BRAEMAR BY SEELEY INTERNATIONAL...
-
Page 17: Pipe Preparation
9. PIPE PREPARATION 9.1 PIPE CUTTING Right Wrong Cutting To ol Use cutting tools easily found in the market. Measure pipe 9 9 9 9 9 0 0 0 0 0 Sloped CutRough Cut precisely. Provide a little bit longer pipe than the measurement. 9.2 REAMING Clean the inside of the refrigerant tube. -
Page 18: Piping Length And Elevation
10 m Outdoor Unit Indoor Unit CAUTION: Capacity is based on standard length and maximum allowance length is on the basis of reliability. Oil trap should be installed every 10 metres in vertical pipe. BRAEMAR BY SEELEY INTERNATIONAL... -
Page 19: Piping Connection
1/2" (12.7 mm) 5.5-6.6 • If dry nirogen is not present, unit may have a leak. 5/8" (15.9 mm) 6.3-8.2 Please do not install. Contact Seeley International Services 3/4" (19.0 mm) 9.9-12.1 1300 526 477 for advice. 7/8" (22.2 mm) 9.9-12.1... -
Page 20: Air Purging And Check For Pipe Leakage
Tighten the blank cap of the three-way valve. GAS LEAKING CHECK Check leakage by apply soapsuds to every connec- tion and inspect carefully. After checking,wipe them off completely. Cover indoor unit joint with pipe insulation and plastic bands to prevent condensation at joints. BRAEMAR BY SEELEY INTERNATIONAL... -
Page 21: Wiring Diagram
13. WIRING DIAGRAM • Wiring is to be done as shown in the electrical wiring diagram • How to tighten screw on terminal block: (Do not change the internal wiring) 1. Bare the ends of electric wire. 2. After retaining the wire, check that all the •... -
Page 22: Refrigerant Pipe And Drain Pipe
Safe tray drain to terminate where visible but not to cause a nuisance NOTE : Refrigerant, indoor unit drain pipes and outdoor whilst complying with regulations. unit drainage must comply with local and national laws and regulations. Picture 3 BRAEMAR BY SEELEY INTERNATIONAL... -
Page 23: Test Running
15. TEST RUNNING 1 . RUN TEST Check electrical main wire's voltage. Run the air conditioner for 15 minutes or more. Check the electrical current with ammeter and compare with the speci cations. EVALUATION OF THE PERFORMANCE Check electrical main wire's voltage. Use a thermometer to measure cool air both in and out. -
Page 24: Maintenance Schedule
A properly working coil is essential for effective heat correct amount of refrigerant charge. Systems that run short on transfer. refrigerant charge may eventually cause a compressor burn out. BRAEMAR BY SEELEY INTERNATIONAL... -
Page 25: Maintenance
17. MAINTENANCE CLEANING THE INTERNAL AIR FILTERS Before inspection and maintenance of the unit, always set the main power switch to "OFF" to cut off power supply. Remove the air lter; clean it with a vacuum cleaner or if it is very dirty, wash it with soapy water then wipe off until it is completely dry before reinstallation. -
Page 26: Important
Your lter is located as follows: Ceiling: Room:……………………… Step Ladder Required: Yes / No Wall: Room:……………………… Step Ladder Required: Yes / No Other: Room:……………………… Description by installer BRAEMAR BY SEELEY INTERNATIONAL... - Page 28 Insert outdoor unit sticker here Warranty Service Australia 1-300-526-477 seeleyinternational.com It is the policy of Seeley International to introduce continual product improvement. Accordingly, specifications are subject to change without notice. Please consult with your dealer to confirm the specifications of the model selected.
