- Page 1 Kara to Kara II upgrade instructions (EN)
- Page 2 Document reference: Kara to Kara II upgrade instructions (EN) version 1.1 Distribution date: July 15, 2021 © 2021 L-Acoustics. All rights reserved. No part of this publication may be reproduced or transmitted in any form or by any means without the...
- Page 3 Do not store the product on an unstable cart, stand, tripod, bracket, or table. As part of a continuous evolution of techniques and standards, L-Acoustics reserves the right to change the specications of its products and the content of its documents without prior notice.
- Page 4 This symbol noties the user about instructions that must be strictly followed to ensure proper installation or operation of the product. This symbol noties the user about complementary information or optional instructions. Kara to Kara II upgrade instructions (EN) version 1.1...
-
Page 5: Upgrade Procedure
Kara can be upgraded to Kara II by replacing the Kara ns with Kara II L-Fins. One KARA II UPG upgrade kit is necessary for the upgrade of one Kara to Kara II. Performing maintenance on Kara enclosures upgraded to Kara II Kara and Kara II compression drivers have different connector types. - Page 6 Upgrade procedure Procedure 1. Remove the two ns from Kara. 5 mm 2. Remove the dust cover. Kara to Kara II upgrade instructions (EN) version 1.1...
- Page 7 Upgrade procedure Remove any old dust cover material and dust before applying the new dust cover. 3. Place the new dust cover with the gaskets against the cabinet. Kara to Kara II upgrade instructions (EN) version 1.1...
- Page 8 Upgrade procedure Make sure the news ns are open. If they are closed, use a at tool to unhook the ns clips. 4. Secure the new ns on Kara with the S100143 screws. 3 N.m Kara to Kara II upgrade instructions (EN) version 1.1...
-
Page 9: What To Do Next
Make sure the serial number remains visible through the label window. If the serial number is hidden by the new label (Kara model from 2014 or earlier), copy the number on the empty serial number label, and stick the label inside the window. - Page 10 L-Acoustics 13 rue Levacher Cintrat - 91460 Marcoussis - France +33 1 69 63 69 63 - info@l-acoustics.com www.l-acoustics.com...
