Parts And Components; Before Use - cecotec READY WARM 9870 SMART ROTATE Instruction Manual

ENGLISH

1. PARTS AND COMPONENTS

Fig. 1
1. Control panel
2. Protection grid
3. Base
4. Safety switch
5. Handle
6. Protection grid
7. Temperature sensor
8. Power switch
Control panel
Fig. 2
1. Display
2. Power button
3. + button
4. - button
5. Timer
6. Oscillation
7. Mode
Display
Fig. 3
1. Oscillation
2. Auto mode
3. Low-power heating
4. High-power heating
5. Frost mode
6. Timer
7. Select temperature
8. Room temperature

2. BEFORE USE

Warning: A slight odour and smoke might appear when heating the device for the first time. This
is due to manufacturing materials residues and does not affect the appliance's operating.
Take the product out of the box and remove all packaging material.
20 READY WARM 9870 SMART ROTATE
Check for any visible damage, if any is observed, contact as soon as possible the Technical
Support Service of Cecotec for advice or reparation.
Place the heater on a flat and stable surface.
3. . OPETION
As soon as the appliance is turned on, the display will light up.
The device can be controlled from the control panel.
Switching on/off the device
Connect the mains plug into a power outlet.
Turn the power switch on in order to turn the device on. The power switch and the display will
light up, indicating the device has entered standby mode.
Press the power switch to enter operating mode. The indicator light will turn on.
Press the standby button to switch back to standby mode once operation is over.
Turn the power switch off to switch off the device completely.
Modes settings
Press the mode button repeatedly to select the desired operating mode.
Fig. 4
Fig. 5
Fig. 6
Fig. 7
Temperature adjustment
The desired temperature is shown on the display (above the room temperature).
Use the + button to increase the desired temperature up to 38 ºC and the – button to
decrease it down to 6 ºC.
The room temperature is measured by the temperature sensor and shown on the display.
The device includes a thermostat which automatically switches off the device when the room
temperature has reached the set one.
If the room temperature falls below the set one, the device will switch automatically on again.
ENGLISH
Low-power heat (1000 W).
High-power heat (2000 W)
Automatic mode: The device adapts the heat
power to the room temperature.
Frost protection: The device turns
automatically on when the room temperature
is below 6º.
READY WARM 9870 SMART ROTATE 21
