Smartdesks Model SPX-243030-MDL
c Smartdesks ltd. 1999
SPX-243030-MDL
Page 1
Panel List
Note: Separate and stack panels by like types before beginning assembly process.
Mobile Projector & Document Camera Cart
1 Top Panel • 1 Back Panel • 1 Left End Panel • 1 Right End Panel
• 1 Bottom Panel • 1 Adjustble Shelf • 2 Storage Doors • 4 Caster & Wheel Sets
= Cam Fitting
= Cam Hole
= Screw Hole/Spoon Pin
= RV Fitting
= Grommet/wire access
Top Panel (1 ea.)
Right End Panel (1 ea.)
Left End Panel (1 ea.)
Back Panel (1 ea.)
Adjustable Shelf (1 ea.)
Bottom Panel (1 ea.)
Storage Door (1 ea.)
Advertisement
Table of Contents
Related Manuals for SMARTdesks SPX-243030-MDL
Summary of Contents for SMARTdesks SPX-243030-MDL
- Page 1 Smartdesks Model SPX-243030-MDL c Smartdesks ltd. 1999 SPX-243030-MDL Page 1 Panel List Note: Separate and stack panels by like types before beginning assembly process. Mobile Projector & Document Camera Cart 1 Top Panel • 1 Back Panel • 1 Left End Panel • 1 Right End Panel •...
- Page 2 Model SPX-192426-MDL SPX-192426-MDR Unpack Parts and Hardware: Parts and panels will vary according to Smartdesks model. See Parts & Panels List and Hardware Inventory Sheet. Please verify all parts and quantities prior to assembly. Contact the factory if your quantities are incomplete. Note: All panels are predrilled ready for assembly.
- Page 3 Page 3 c Smartdesks ltd. 1999 Hardware Inventory Sheet (Cont.) 2 persons are needed to assemble Smartdesks Model SPX 192426-MDL Contents of Hardware Bag : (quantities for each component - multiply by number of components) 12 ea. - 5mm Hinge Plate 6 ea.
- Page 4 SPX-192426-MDL Page 4 c Smartdesks ltd. 1999 Figure 1 Figure 4 STEP 1 - Top & Side Panel Assembly In a clean work area lay Top Panel with top facing down on the floor on cardboard or carpet/packing quilt. (Fig. 1)
- Page 5 While holding Toe Kick Panel with the front facing up, match RV Fittings to one another and snap the left side Figure 8 Smartdesks Storage & Support Component of the Toe Kick Panel into place. Left side of the Toe SPX -243030-MDL Back &...
- Page 6 SPX-192426-MDL Page 6 c Smartdesks ltd. 1999 STEP 4 - Toe Kick Assembly (cont.) NOTE: 1 person assembly is required for proper fit. Figure 12 Figure 14 Figure 14 shows detail of Wheel Bracket/Wheel Unit assembly using 7/16” wrench. STEP 6- Flip SPX Unit 90 Upright Position NOTE: 2 persons required for this step.
- Page 7 (Fig. 17) Adjustable Shelf should be par- allel to Top Panel. Smartdesks have been designed and tested as an ergonomically correct and space saving unit. For more information on this and other Smartdesks products, call 1-800-770-7042 or visit our website at http://www.smartdesks.com...
