Smartdesks Model SPX-243030-FDL
c Smartdesks ltd. 1999
SPX-243030-FDL
Page 1
Panel List
Note: Separate and stack panels by like types before beginning assembly process.
Fixed Projector & Document Camera Cabinet
1 Top Panel • 1 Back Panel • 1 Left End Panel • 1 Right End Panel
• 1 Bottom Panel • 1 Adjustable Shelf • 1 Storage Door • 1 Toe Kick Panel
= Cam Fitting
= Cam Hole
= Screw Hole/Spoon Pin
= RV Fitting
= Grommet/wire access
Top Panel (1 ea.)
Right End Panel (1 ea.)
Left End Panel (1 ea.)
Back Panel (1 ea.)
Toe Kick Panel (1 ea.)
Adjustable Shelf (1 ea.)
Bottom Panel (1 ea.)
Storage Door (1 ea.)
