Smartdesks Model SPX-302430-FDx
c Smartdesks ltd. 1999
SPX-302430-FDx
Page 1
Panel List
Note: Separate and stack panels by like types before beginning assembly process.
Printer/Locking Storage Cabinet
1 Top Panel • 1 Back Panel • 1 Left End Panel • 1 Right End Panel
• 1 Bottom Panel • 2 Storage Doors • 1 Adjustable Shelf • 1 Toe Kick Panel
= Cam Fitting
= Cam Hole
= Screw Hole/Spoon Pin
= RV Fitting
= Grommet/wire access
Top Panel (1 ea.)
Left End Panel (1 ea.)
Right End Panel (1 ea.)
Back Panel (1 ea.)
Bottom Panel (1 ea.)
Left Storage Door (1 ea.)
Right Storage Door (1 ea.)
Toe Kick Panel (1 ea.)
Adjustable Shelf (1 ea.)
