On the right side of the graph there are two tabs: Data View and
General Information.
Through the toolbar at the bottom of the download screen,
NXperience allows you to save, save to file, merge graphs, filter, and
even export this information to several types of reports:
Figure 19 – Toolbar
Specific information about each of these features can be found in the
NXperience manual, available on our website.
DATA VIEW
Figure 20 – Data View
This table provides in engineering units the values acquired by one
or both input channels (depending on the configuration made). Each
occurrence of this table consists of the log number, the time, the
date, and the log values.
GENERAL INFORMATION
Figure 21 – General Information
Displays information about the logger and its settings.
NOVUS AUTOMATION
MONITORING LOGS
By clicking the button located at the bottom of the NXperience
home screen, you can monitor the real-time operation of the logger:
Figure 22 – Monitoring logs
This screen presents information about the configured channels, the
values currently logged, the occurrence of alarms, among other data,
and allows you to pause and print the displayed graph.
Specific information about each of these features can be found in the
NXperience manual, available on our website.

SPECIAL PRECAUTIONS

Because it is an electronic device, the logger requires some basic
precautions:
• When opening the unit to change the battery or attach sensors,
you should avoid contact with the circuitry due to the risk of
damage from static electricity.
• When the device is opened, avoid liquid and/or dust contact.
• You should pay attention to the battery polarity. The battery
should be placed with the positive terminal toward the center
of the device.
• Used batteries must not be recharged, disassembled, or
incinerated. After use, they must be collected according to local
legislation or sent back to the supplier.
• When closing the housing, the cover must be put back on
properly, ensuring the degree of protection of this model.

TROUBLESHOOTING

The indicator does not blink:
The indicator blinks intentionally dimply and can be difficult to see it
in high-light locations. Therefore, you need to make sure that it is not
actually blinking.
Check that the battery is correctly installed.
Make sure that the battery is not discharged.
It is not possible to communicate with the logger:
Make sure that there are no obstacles blocking the infrared signal.
Make sure that the cable is properly connected to the computer port.
Make sure that the selected port is working properly.
