- Page 1 For proper operation, please read and keep this manual carefully. If you have lost the Owner’s Manual, please contact the local agent or visit www.innovair.com or sent email to info@innovair.com for electronic version. ©2018 Innovair Corporation. All Rights Reserved. www.innovair.com...
-
Page 2: Table Of Contents
Children should be supervised to ensure that they do not play with the appliance. ©2020 Innovair Corporation. All Rights Reserved. www.innovair.com... - Page 3 Indicates a hazardous situation that, if not avoided, may result in minor or moderate injury. Indicates important but not hazard-related information, used to indicate risk of property damage. Indicates a hazard that would be assigned a signal word WARNING or CAUTION. ©2020 Innovair Corporation. All Rights Reserved. www.innovair.com...
-
Page 4: Precautions
Do not use fire or hair dryer to dry the filter to avoid deformation or fire hazard. ©2020 Innovair Corporation. All Rights Reserved. www.innovair.com w w w . i n n o v a i r . c o m... - Page 5 Do not step on top panel of outdoor unit, or put heavy objects. It may cause damage or personal injury. ©2020 Innovair Corporation. All Rights Reserved. www.innovair.com...
- Page 6 Be sure to cut off the power supply before proceeding any work related to electricity and safety. ©2020 Innovair Corporation. All Rights Reserved. www.innovair.com w w w . i n n o v a i r . c o m...
- Page 7 All wires of indoor unit and outdoor unit should be connected by a professional. If the length of power connection wire is insufficient, please contact the supplier for a new one. Avoid extending the wire by yourself. ©2020 Innovair Corporation. All Rights Reserved. www.innovair.com...
- Page 8 ● The temperature range for operating the unit with electric heating: -20℃~46.1℃; the temperature range for operating the unit without electric heating: -18℃~46.1℃ ©2020 Innovair Corporation. All Rights Reserved. www.innovair.com w w w . i n n o v a i r . c o m...
-
Page 9: Parts Name
MULTI-MAX HIGH WALLS OWNERS MANUAL Parts Name Indoor Unit air inlet panel aux.button horizontal louver cooling power receiver air outlet indicator indicator window display heating temp. drying indicator indicator indicator (Display content or position may be different from above remote controller graphics, please refer to actual products) NOTICE: Actual product may be different from above graphics, please refer to actual... -
Page 10: Buttons On Remote Controller
OWNERS MANUAL MULTI-MAX HIGH WALL Function and Control Remote Controller Introduction of Prestige Introduction for icons on display screen Buttons on remote controller I feel Set fan speed Turbo mode Send signal Auto mode Cool mode Dry mode Fan mode Heat mode Sleep mode 8℃... -
Page 11: Introduction For Buttons On Remote Controller
MULTI-MAX HIGH WALLS OWNERS MANUAL Introduction for buttons on remote controller Note: ● After putting through the power, the air conditioner will give out a sound. Operation indictor " " is ON (red indicator). After that, you can operate the air conditioner by using remote controller. - Page 12 MULTI-MAX HIGH WALLS OWNERS MANUAL Introduction for buttons on remote controller buttons Press "▲" or "▼" button once increase or decrease set temperature 1℃(° F ). Holding "▲" or "▼" button, 2s later, set temperature on remote controller will change quick l y. On releasing button after setting is finished, temperature indicator on indoor unit will change accordingly.
- Page 13 MULTI-MAX HIGH WALLS OWNERS MANUAL Introduction for buttons on remote controller Introduction for buttons on remote controller CLOCK +/- button button ● Press "+" or "-" button once increase or decrease set temperature 1℃ . Press this button to set clock time. " "...
- Page 14 MULTI-MAX HIGH WALLS OWNERS MANUAL Introduction for buttons on remote controller X-FAN button Press this button under cool and dry mode to start up x-fan function, and " " icon on remote controller will be displayed. Press this button again to cancel x-fan function, and "...
-
Page 15: Function Introduction For Combination Buttons
MULTI-MAX HIGH WALLS OWNERS MANUAL Introduction for buttons on remote controller SLEEP button Under COOL, HEAT or DRY mode, press this button to start up sleep function. " " icon is displayed on remote controller. Press this button again to cancel sleep function and "... -
Page 16: Operation Guide
MULTI-MAX HIGH WALLS OWNERS MANUAL Energy-saving function Under cooling mode, press "TEMP" and "CLOCK" buttons simultaneously to start up or turn off ener-gy-saving function. When energy-saving function is started up, "SE" will be shown on remote con-troller, and air conditioner will adjust the set tem-perature automatically according to ex-factory setting to reach to the best energy-saving effect. -
Page 17: Emergency Operation
MULTI-MAX HIGH WALLS OWNERS MANUAL Emergency operation If remote controller is lost or damaged, please use auxiliary button to turn on or turn off the air conditioner. The operation in details are as below: air conditioner. When the air conditioner is turned on, it will operate under auto mode. - Page 18 MULTI-MAX HIGH WALLS OWNERS MANUAL Clean and maintenance Open panel Pull out the panel to a certain ● Use dust catcher or water to the water (below 45℃ ) to clean it, and then put it in a shady and cool place to dry. panel cover tightly.
- Page 19 MULTI-MAX HIGH WALLS OWNERS MANUAL Clean and maintenance NOTICE: Checking before use-season 1. Check whether air inlets and air outlets are blocked. 2. Check whether air switch, plug and socket are in good condition. 4. Check whether mounting bracket for outdoor unit is damaged or corroded. If yes, please contact dealer.
-
Page 20: Malfunction Analysis
MULTI-MAX HIGH WALLS OWNERS MANUAL Malfunction analysis General phenomenon analysis Please check below items before asking for maintenance. If the malfunction still Phenomenon Check items Solution ● Whether it's interfered severely ● Pull out the plug. Reinsert (such as static electricity,stable the plug after about 3min, and voltage)? then turn on the unit again. - Page 21 MULTI-MAX HIGH WALLS OWNERS MANUAL Malfunction analysis ● Air inlet or air outlet of indoor ● Eliminate obstacles. unit is blocked? ● Under heating mode, indoor ● After reaching to set temper- No air temperature is reached to set ature, indoor unit will stop bl- emitted temperature? owing out air.
- Page 22 MULTI-MAX HIGH WALLS OWNERS MANUAL Malfunction analysis ● Temperature can’t be adju- sted under auto mode. ● Unit is operating under auto Please switch the operation mode? Set temper- mode if you need to adjust ature can’t temperature. be adjusted ●...
- Page 23 MULTI-MAX HIGH WALLS OWNERS MANUAL Malfunction analysis ● The noise is the sound of “Water ● Air conditioner is turned on or turned off just now? the unit, which is a normal noise phenomenon. ● This is the sound of friction ●...
- Page 24 MULTI-MAX HIGH WALLS OWNERS MANUAL Malfunction analysis Error Code ● When air conditioner status is abnormal, temperature indicator on indoor unit will ation of error code. Above indicator diagram is only for reference. Please refer to Indoor actual product for the actual display indicator and position.
-
Page 25: Installation Dimension Diagram
MULTI-MAX HIGH WALLS OWNERS MANUAL Installation dimension diagram Space to the wall At least 15cm At least 15cm Space to the wall... -
Page 26: Selection Of Installation Location
MULTI-MAX HIGH WALLS OWNERS MANUAL Tools for installation 1 Level meter 2 Screw driver 3 Impact drill 4 Drill head 5 Pipe expander 6 Torque wrench 7 Open-end wrench 8 Pipe cutter 9 Leakage detector 10 Vacuum pump 11 Pressure meter 12 Universal meter 13 Inner hexagon spanner 14 Measuring tape... -
Page 27: Requirements For Electric Connection
MULTI-MAX HIGH WALLS OWNERS MANUAL Requirements for electric connection Safety precaution 1. Must follow the electric safety regulations when installing the unit. circuit break. 3. Make sure the power supply matches with the requirement of air conditioner. Unstable power supply or incorrect wiring or malfunction. Please install proper power supply cables before using the air conditioner. -
Page 28: Installation Of Indoor Unit
MULTI-MAX HIGH WALLS OWNERS MANUAL Installation of indoor unit Step one: choosing installation location rm it with the client. Step two: install wall-mounting frame 1. Hang the wall-mounting frame on the wall; adjust it in horizontal position with the plastic expansion particles in the holes. 3. - Page 29 MULTI-MAX HIGH WALLS OWNERS MANUAL Installation of indoor unit Indoor outdoor Note: ● Pay attention to dust prevention and take relevant safety measures when opening the hole. ● The plastic expansion particles are Φ55 5-10 not provided and should be bought locally.
- Page 30 MULTI-MAX HIGH WALLS OWNERS MANUAL Installation of indoor unit Hex nut diameter Tightening torque (N open-end wrench Φ 6 15~20 Φ 9.52 30~40 union nut Φ 12 45~55 pipe Φ 16 60~65 torque wrench Φ 19 70~75 indoor pipe 4. Wrap the indoor pipe and joint of con- nection pipe with insulating pipe, and then wrap it with tape.
- Page 31 MULTI-MAX HIGH WALLS OWNERS MANUAL Installation of indoor unit 2. Make the power connection cord go cable-cross through the cable-cross hole at the back hole of indoor unit and then pull it out from the front side. power connection cord i l c according to the color ;tighten the screws and then fix the power connection cord with wire clip.
- Page 32 MULTI-MAX HIGH WALLS OWNERS MANUAL Installation of indoor unit Step eight: bind up pipe 1. Bind up the connection pipe, power drain hose connection pipe band cord and drain hose with the band. indoor and outdoor power cord indoor unit pipe indoor power cord liquid pipe...
-
Page 33: Check After Installation
MULTI-MAX HIGH WALLS OWNERS MANUAL Check after installation Items to be checked Possible malfunction The unit may drop, shake or emit noise. Have you done the refrigerant leakage test? (heating) capacity. It may cause condensation and water dripping. It may cause condensation and water Is water drained well? dripping. -
Page 34: Test Operation
MULTI-MAX HIGH WALLS OWNERS MANUAL Test operation 1. Preparation of test operation ● The client approves the air conditioner. ● Specify the important notes for air conditioner to the client. 2. Method of test operation ● Put through the power, press ON/OFF button on the remote controller to start operation. -
Page 35: Configuration Of Connection Pipe
MULTI-MAX HIGH WALLS OWNERS MANUAL Configuration of connection pipe 1. Standard length of connection pipe ● 5m, 7.5m, 8m. 2.Min. length of connection pipe is 3m. 3.Max. length of connection pipe and max. high difference. Max length Max length Cooling Max height Cooling Max height... - Page 36 MULTI-MAX HIGH WALLS OWNERS MANUAL Additional refrigerant charging amount for R22, R407C, R410A and R134a Diameter of connection pipe Outdoor unit throttle Liquid pipe(mm) Gas pipe(mm) Cooling only(g/m) Cooling and heating(g/m) Φ6 Φ9.52 or Φ12 Φ6 or Φ9.52 Φ16 or Φ19 Φ12 Φ19 or Φ22.2 Φ16...
-
Page 37: Pipe Expanding Method
MULTI-MAX HIGH WALLS OWNERS MANUAL Pipe expanding method Note: Improper pipe expanding is the main cause of refrigerant leakage. Please expand the pipe according to the following steps: A: Cut the pipe E: Expand the port the distance of indoor unit and hard outdoor unit. - Page 38 MULTI-MAX HIGH WALLS OWNERS MANUAL Notes...
- Page 39 MULTI-MAX HIGH WALLS OWNERS MANUAL w w w . i n n o v a i r . c o m...
- Page 40 The design and speci cations are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details.
