- Page 1 QUANTUM INVERTER HEAT PUMP DUCTLESS SPLIT SYSTEM USER MANUAL WIN09H1V51 WIN12HV51 WIN09H2V51 WIN12H2V51 WIN18H2V51 WIN24H2V51 WARNING • The information contained in the manual is intended for use by a qualified service technician familiar with safety procedures and equipped with the proper tools and test instruments •...
-
Page 3: Table Of Contents
INNOVAIR DC INVERTER QUANTUM SERVICE MANUAL Contents Safety Precaution ................Safety Instructions ................Preparation ..................Front Panel Maintenance ..............Model Reference ................System Diagram ................. Display Introduction ................Protection .................... Installation Guide ................Wiring Diagram .................. Air Purging ..................Start-Up .................... -
Page 4: Safety Precaution
When lifting or transporting the unit, it is • recommended that two or more people are used for work. For more information, contact your dealer, this task. seller, or an authorized Innovair service center. • When the unit is not to be used for an extended time,... - Page 5 INNOVAIR QUANTUM INVERTER SAFETY PRECAUTION Safety Precaution Symbols in this Use and Care Manual are interpreted as shown below. Grounding is essential. Be sure not to do. Warning: Incorrect handling could ºPay attention to such a situation. cause a serious hazard,...
-
Page 6: Safety Instructions
SAFETY INSTRUCTIONS INNOVAIR QUANTUM INVERTER Safety Instructions To guarantee the unit work normally, please read the manual carefully before installation, and try to install strictly according to this manual. Do not let air enter the refrigeration system or discharge refrigerant when moving the air conditioner. -
Page 7: Preparation
INNOVAIR QUANTUM INVERTER PREPARATION Preparation before use Note • When charging refrigerant into the system, make sure to charge in liquid state,if the refrigerant of the appliance is R410A.Otherwise, chemical composition of refrigerant (R410A) inside the system may change and thus affect performance of the air conditioner. -
Page 8: Front Panel Maintenance
FRONT PANEL MAINTENANCE INNOVAIR QUANTUM INVERTER Front panel maintenance Cut off the power supply Grasp position "a" and Turn off the appliance first before disconnecting pull outward to remove the from power supply. front panel. Never use volatile substance such as... -
Page 9: Model Reference
INNOVAIR QUANTUM INVERTER MODEL REFERENCE Model Reference Indoor Unit Model Outdoor Unit Model Capacity (Btu/h) Power Supply WIN09H1V51(I) WIN09H1V51(O) 115V~, 60Hz, 1Phase WIN12H1V51(I) WIN12H1V51(O) WIN09H2V51(I) WIN12H2V51(O) WIN12H2V51(I) WIN12H2V51(O) 208/230V~, 60Hz, 1Phase WIN18H2V51(I) WIN18H2V51(O) WIN24H2V51(I) WIN24H2V51(O) Nomenclature W IN 12 H 2 V 5 1 1—... -
Page 10: System Diagram
SYSTEM DIAGRAM INNOVAIR QUANTUM INVERTER System Diagram Indoor unit Part Name 1. Remote Controller 2. Air Filter 3. Horizontal Louvers 4. Front Panel 5. Pipes and Power Connection Cord Outdoor unit 6. Drain Hose The figures in this manual are based on the external view of a standard model. -
Page 11: Display Introduction
INNOVAIR QUANTUM INVERTER DISPLAY INTRODUCTION Display introduction optional optional Temperature indicator Display set temperature. It shows FC after 200 hours of usage as reminder to clean the filter. After filter cleaning press the filter reset button located on the indoor unit behind the front panel in order to reset the display.(optional) -
Page 12: Protection
PROTECTION INNOVAIR QUANTUM INVERTER Protection Noise pollution Operating condition The protective device maybe trip and stop Install the air conditioner at a place that the appliance in the cases listed below. can bear its weight in order to operate more quietly. -
Page 13: Installation Guide
INNOVAIR QUANTUM INVERTER INSTALLATION Installation Diagram Distance from ceiling should be over 200 mm/7.9in Distance from wall should be over 50mm/2in Distance from the wall should be over 50mm/2in Distance from floor should be over 2.4m/8ft. Air intake distance from the wall... - Page 14 INSTALLATION INNOVAIR QUANTUM INVERTER Location Installation Site Site for Installing Indoor Unit Where there is no obstacle near the air outlet and air can be easily blown to every corner. Indoor unit Where piping and wall hole can be easily arranged.
- Page 15 INSTALLATION INNOVAIR QUANTUM INVERTER Indoor Installation 1. Installing the Mounting Plate • Decide an installing location for the mounting plate according to the indoor unit location and piping direction. • Keep the mounting plate horizontal with a horizontal ruler or dropping line.
- Page 16 INSTALLATION INNOVAIR QUANTUM INVERTER Indoor Installation • Piping Joints Thermal Insulation: Wrap the piping joints with thermal insulation materials and then wrap with a vinyl tape. wrapped with vinyl type Thermal insulation • Piping Thermal Insulation: a. Place the drain hose under the piping.
- Page 17 INSTALLATION INNOVAIR QUANTUM INVERTER Outdoor Installation 1. Install Condensate Drain for Outdoor Unit The condensate drains from the outdoor unit when the unit operates in heating mode. In order not to disturb your neighbor and protect the environment, install a drain port and a drain hose to direct the condensate water.
- Page 18 INSTALLATION INNOVAIR QUANTUM INVERTER Outdoor Installation 3. Piping Connections to Outdoor Unit Remove service valve cover( if provided) to access the service valves and refrigerant ports. Carefully bend and adjust length of refrigerant pipes to meet outdoor unit service valves connection with proper tools to avoid kinks.
- Page 19 INSTALLATION INNOVAIR QUANTUM INVERTER Outdoor Installation 4. Connecting of the Cable Front panel Indoor Unit • Terminal (inside) Connect the power cord to the indoor unit by connecting the wires to the terminals on the control board individually in accordance with the outdoor unit connection.
-
Page 20: Wiring Diagram
WIRING DIAGRAM INNOVAIR QUANTUM INVERTER Wiring Diagram Warning: Before obtaining access to terminals, all supply circuits must be disconnected. Make sure that the color of the wires in the outdoor unit and terminal No. are the same as those of the indoor unit. - Page 21 INNOVAIR QUANTUM INVERTER WIRING DIAGRAM Wiring Diagram To power the Indoor unit, connect the power cord to the indoor unit by connecting the wires to the terminals on the control board individually in accordance with the outdoor unit connection. 2) ) 115V...
- Page 22 WIRING DIAGRAM INNOVAIR QUANTUM INVERTER Wiring Diagram INDOOR UNIT WIN09H1V51(I) ,, WIN12H1V51(I))
- Page 23 INNOVAIR QUANTUM INVERTER WIRING DIAGRAM Wiring Diagram INDOOR UNIT WIN09H2V51(I),)WIN12H2V51(I),)WIN18H2V51(I)) w w w . i n n o v a i r . c o m...
- Page 24 WIRING DIAGRAM INNOVAIR QUANTUM INVERTER Wiring Diagram INDOOR UNIT WIN24H2V51(I))
- Page 25 INNOVAIR QUANTUM INVERTER WIRING DIAGRAM Wiring Diagram OUTDOOR UNIT WIN09H1V51(O) , WIN12H1V51(O)) w w w . i n n o v a i r . c o m...
- Page 26 WIRING DIAGRAM INNOVAIR QUANTUM INVERTER Wiring Diagram OUTDOOR UNIT WIN09HV51(O) ,)WIN12H2V51(O) , )WIN18H2V51(O) , WIN24H2V51(O))
-
Page 27: Air Purging
AIR PURGING INNOVAIR QUANTUM INVERTER Air Purging The air which contains moisture remaining in the refrigeration cycle may cause a malfunction on the compressor. After connecting the indoor and outdoor units, release air and moisture from the refrigerant cycle using a vacuum pump, as shown below. -
Page 28: Start-Up
000022 START-UP INNOVAIR QUANTUM INVERTER Installation Check List Start-up Test Operation Perform test operation after completing gas leak and electrical safety check. 1.Turn on electrical disconnect to outdoor unit. 2.Push the “ON/OFF” button on Remote Controller to begin testing. 3.Push MODE button, select COOLING, HEATING, FAN mode to confirm all functions. -
Page 29: Troubleshooting
000009 TROUBLESHOOTING INNOVAIR QUANTUM INVERTER Troubleshooting The following cases may not always be a malfunction, please check it before asking for service. Trouble Analysis If the protector trip or fuse is blown,please wait 3 minutes and start again.The protector device Does not run may be preventing unit from working. - Page 30 TROUBLESHOOTING INNOVAIR QUANTUM INVERTER Error Code Indicators 1. Indication on the outdoor unit: When the unit has the following trouble and the compressor stops running, the LED of outdoor control board will show the error sequence automatically: NOTE: FLASH ×...
- Page 31 INNOVAIR QUANTUM INVERTER TROUBLESHOOTING Error Code Indicators a. the EEPROM chip is loose; Outdoor EEPROM b. the EEPROM chip is inserted with opposite direction; ★ ★ ★ in trouble c. the EEPROM chip fails Compressor exhaust a. the compressor exhaust temperature sensor fails;...
- Page 32 TROUBLESHOOTING INNOVAIR QUANTUM INVERTER Error Code Indicators a. The IPM board fails; b. The outdoor fan is broken; c. The outdoor fan motor fails; IPM module d. The outdoor fan has been blocked ; × × protection e. The condenser is dirty;...
- Page 33 INNOVAIR QUANTUM INVERTER TROUBLESHOOTING Error Code Indicators Frequency decreasing or prohibition of × ★ ★ frequency rising caused by anti-freezing of refrigeration or anti-overload in heating Frequency decreasing or prohibition of × ★ ★ frequency rising caused by too high compressor...
- Page 34 TROUBLESHOOTING INNOVAIR QUANTUM INVERTER Error Code Indicators 2.2. When the unit has the following trouble and the compressor stops running, press the sleep button on the remote controller 4 times in ten seconds and the 7-segment tube of the display board will show the error code as the following.
- Page 35 INNOVAIR QUANTUM INVERTER TROUBLESHOOTING Error Code Indicators a. the communication cable Ο × ★ ★ connection is loose; b. the communication cable fails; c. the connection between the filter Communication board and the outdoor control board failure between is incorrect or loose;...
- Page 36 TROUBLESHOOTING INNOVAIR QUANTUM INVERTER Error Code Indicators Compressor × Ο × ★ a. the compressor exhaust exhaust temperature sensor fails; temperature b. the refrigerant of the unit is not too high enough protection Outdoor a. the outdoor ambient temperature ×...
- Page 37 INNOVAIR QUANTUM INVERTER TROUBLESHOOTING Error Code Indicators Chip in outdoor a. Using the wrong drive board; board in trouble b. Using the wrong compressor. a. Radiator sensor fails Overheated b. Detection circuit of the sensor outdoor radiator on the control panel fails a.
-
Page 38: Spare Parts List
SPARE PARTS LIST INNOVAIR QUANTUM INVERTER WIN09H1V51(I)) PART CODE DESCRIPTION 1465666 baffle 1906605 installation plate assy 1856104 base holder part 1465662 Vertical Level Vane 1831008 level vane 1466013 cross-flow fan blade 1223739 bearing 1465670 baffle 1826755 Refrigeration system 1849430 ornamental part... - Page 39 SPARE PARTS LIST INNOVAIR QUANTUM INVERTER WIN09H1V51(O) PART CODE DESCRIPTION 1832902 panel parts 1405123 propeller fan blade 1457759 fan motor 1824869 motor supporter 1824871 mounting plate 1824865 upper board 1824902 back guard 1855257 Condenser assembly 1854218 base holder part 1895382...
- Page 40 SPARE PARTS LIST INNOVAIR QUANTUM INVERTER WIN12H1V51(I) PART CODE DESCRIPTION 1906600 installation plate assy 1465666 baffle 1854463 base holder part 1465662 Vertical Level Vane 1555374 level vane 1466014 cross-flow fan blade 1223739 bearing 1465670 baffle 1512275 Refrigeration system 1465756 motor guard...
- Page 41 SPARE PARTS LIST INNOVAIR QUANTUM INVERTER WIN12H1V51(O)) PART CODE DESCRIPTION 1832902 panel parts 1405123 propeller fan blade 1457759 fan motor 1824869 motor supporter 1824871 mounting plate 1824865 upper board 1824902 back guard 1824903 back guard 1854202 Condenser assembly 1832900 base holder part...
- Page 42 SPARE PARTS LIST IINNOVAIR QUANTUM INVERTER WIN12H2V51(I) PART CODE DESCRIPTION 1465666 baffle 1854463 base holder part 1465662 Vertical Level Vane 1555374 level vane 1466014 cross-flow fan blade 1223739 bearing 1465670 baffle 1823341 Refrigeration system 1465756 motor guard 1857574 fan motor motor cover 1465757 4062911...
- Page 43 SPARE PARTS LIST INNOVAIR QUANTUM INVERTER WIN12H2V51(O) PART CODE DESCRIPTION 1832902 panel parts 1405123 propeller fan blade 1820938 fan motor 1824869 motor supporter 1824871 mounting plate 1824865 upper board 1824902 back guard 1824903 back guard 1854202 Condenser assembly 1832900 base holder part...
- Page 44 SPARE PARTS LIST INNOVAIR QUANTUM INVERTER WIN18H2V51(I) PART CODE DESCRIPTION 1541379 wiring distribution cover assy 1840141 Over clamp 1541500 elec joint box plate 1870720 electric box 1855041 Indoor Main Control Board Component 1541507 electric box cover 1837043 electric box cover...
- Page 45 SPARE PARTS LIST INNOVAIR QUANTUM INVERTER WIN18H2V51(O) PART CODE DESCRIPTION 1847919 panel parts 1556766 propeller fan blade 1854829 fan motor 1849292 motor supporter assy 1846086 mounting plate 1846082 upper board 1854579 back guard 1854580 back guard 1854847 Condenser assembly 1850352...
- Page 46 SPARE PARTS LIST INNOVAIR QUANTUM INVERTER WIN24H2V51(I) PART CODE DESCRIPTION 1907022 installation plate assy 1918024 base holder part 1541457 level vane 1550294 Vertical Level Vane 1541363 level vane 1222824 axis sheath 1541633 cross-flow fan blade 1223738 bearing 1465670 baffle 1556041...
- Page 47 SPARE PARTS LIST INNOVAIR QUANTUM INVERTER WIN24H2V51(O) PART CODE DESCRIPTION 1844019 panel parts 1841783 propeller fan blade 1841930 fan motor 1841749 motor supporter 1841772 mounting plate 1841779 upper board 1871792 back guard 1854661 back guard 1854467 Condenser assembly 1844016 base holder part...
