Owners Manual

Multi-Pipe VRF High Walls

Thank you for choosing our product.

For proper operation, please read and keep this manual carefully.

If you have lost the Owner's Manual, please contact the local agent or visit

www.innovair.com or sent email to info@innovair.com for electronic version.

VWM10H25

VWM13H25

VWM18H25

VWM24H25

www.innovair.com

Table of Contents

Need help?

Do you have a question about the VWM10H25 and is the answer not in the manual?

Questions and answers

Summary of Contents for innovair VWM10H25

Page 1 For proper operation, please read and keep this manual carefully. If you have lost the Owner’s Manual, please contact the local agent or visit www.innovair.com or sent email to info@innovair.com for electronic version. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 2: Table Of Contents
Children should be supervised to ensure that they do not play with the appliance. R410A(R32/125: 50/50): 1975 ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 3 Indicates a hazardous situation that, if not avoided, may result in minor or moderate injury. Indicates important but not hazard-related information, used to indicate risk of property damage. Indicates a hazard that would be assigned a signal word WARNING or CAUTION. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 4: Precautions
Do not spray water on indoor unit. It may cause electric shock or malfunction. After removing the filter, do not touch fins to avoid injury. Do not use fire or hair dryer to dry the filter to avoid deformation or fire hazard. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 6 Properly connect the live wire, neutral wire and grounding wire of power socket. Be sure to cut off the power supply before proceeding any work related to electricity and safety. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 7 All wires of indoor unit and outdoor unit should be connected by a professional. If the length of power connection wire is insufficient, please contact the supplier for a new one. Avoid extending the wire by yourself. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 8 Outdoor side DB/WB(℃ ) Maximum cooling 26.7/19.4 46.1/23.9 Maximum heating 26.7/- 23.9/18.3 NOTICE: ● The temperature range for operating the unit with electric heating: -20℃~46.1℃; the temperature range for operating the unit without electric heating: -18℃~46.1℃ ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 9: Parts Name
(Display content or position may be different from above remote controller graphics, please refer to actual products) NOTICE: Actual product may be different from above graphics, please refer to actual products. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 10: Buttons On Remote Controller
Fan mode Turbo mode Heat mode Set time TIMER ON / TIMER OFF Clock Child lock Sleep mode Light Up & down swing Temp. display type :Set temp. :Indoor ambient temp. :Outdoor ambient temp. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 11: Introduction For Buttons On Remote Controller
● For preventing cold air, after starting up heating mode, indoor unit will delay 1~5 minutes to blow air (actual delay time is depend on indoor ambient temperature). ● Set temperature range from remote controller: 16~30℃ ; Fan speed: auto, low speed, medium speed, high speed. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 12 " button above 2s to set your required swing angle. When reaching your required angle, release the button. Note: ● " 、、 " may not be available. When air conditioner receives this signal, the air conditioner will blow fan automatically. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 13 After that, air conditioner will be turned on or turned off according to setting time. ON/OFF button has no effect on setting. If you don’t need this function, please use remote controller to cancel it. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 14 Under COOL or HEAT mode, press this button to turn to quick COOL or quick HEAT mode. " " icon is displayed on remote controller. Press this button again to exit turbo function and " " icon will disappear. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 15: Function Introduction For Combination Buttons
" icon will blink three times without sending signal to the unit. Temperature display switchover function Under OFF status, press "-" and "MODE" buttons simultaneously to switch temp- erature display between ℃ and ℉ . ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 16: Operation Guide
● Replace new batteries of the same model when replacement is required. ● When you don’t use remote controller for a long time, please take out the batteries. ● If the display on remote controller is fuzzy or there’s no display, please replace batteries. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 17: Emergency Operation
When the surface of indoor unit is dirty, it is recommended to use a soft dry cloth or wet cloth to wipe it. NOTICE: ● Do not remove the panel when cleaning it. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 18 Pull out the panel to a certain the water (below 45℃ ) to clean it, and then put it in a shady and cool place to dry. panel cover tightly. WARNING operation environment, clean frequency can be increased. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 19 1. Many packing materials are recyclable materials. Please dispose them in appropriate recycling unit. 2. If you want to dispose the air conditioner, please contact local dealer or consultant service center for the correct disposal method. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 20: Malfunction Analysis
● Heating mode is turned on just ● In order to prevent blowing indoor now? out cold air, indoor unit will be unit started after delaying for sev- eral minutes, which is a nor- mal phenomenon. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 21 ● Clean the filter. Cooling (heating) ● Set temperature is in proper ● Adjust temperature to proper effect is range? range. not good. ● Door and window are open? ● Close door and window. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 22 ● This is the sound of friction ● Air conditioner is turned on or caused by expansion and/or Cracking turned off just now? contraction of panel or other noise parts due to the change of temperature. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 23 ● There’s abnormal sound during operation. ● Air switch trips off frequently. ● Air conditioner gives off burning smell. ● Indoor unit is leaking. ■ If the air conditioner operates under abnormal conditions, it may cause ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 24: Installation Dimension Diagram
Installation dimension diagram Space to the wall At least 15cm At least 15cm Space to the wall ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 25: Tools For Installation
7. Don't install the indoor unit right above tances. the electric appliance. 7.The appliance shall not be install- 8. Please try your best to keep way from ed in the laundry fluorescent lamp. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 26: Requirements For Electric Connection
6. Including an circuit break with suitable capacity, please note the following table. Circuit break should be included magnet buckle and heating buckle function, it can protect the circuit-short and overload. (Caution: please do not use the fuse only for protect the circuit) ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 27: Installation Of Indoor Unit
2. Open a piping hole with the diameter of Φ55 on the selected outlet pipe position. In order to drain smoothly, slant the piping hole on the wall slightly downward to the outdoor side with the gradient of 5-10°. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 28 3. Adjust the torque force by referring to the following sheet. Place the open-end wrench on the pipe joint and place the torque wrench on the union nut. Tighten the union nut with torque wrench. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 29 ● The plastic expansion particles are insulating pipe not provided. Step seven: connect wire of indoor unit screw panel 1. Open the panel, remove the screw on the wiring cover and then take down the cover. wiring cover ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 30 ● For the air conditioner without plug, an circuit break must be installed in the line. The air switch should be all-pole parting and the contact parting distance should be more than 3mm. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 31 5. Check if the indoor unit is installed firmly and closed to the wall. upper hook indoor outdoor wall pipe sealing gum lower hook of wall-mounting frame Note: ● Do not bend the drain hose too excessively in order to prevent blocking. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 32: Check After Installation
● Press MODE button to select AUTO, COOL, DRY, FAN and HEAT to check whether the operation is normal or not. ● If the ambient temperature is lower than 16℃ , the air conditioner can’t start cooling. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 33: Configuration Of Connection Pipe
● Basing on the length of standard pipe, add refrigerant according to the requirement as shown in the table. The additional refrigerant charging amount per meter is different according to the diameter of liquid pipe. See the following sheet. ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 34 Diameter of connection pipe Outdoor unit throttle Liquid pipe(mm) Gas pipe(mm) Cooling only(g/m) Cooling and heating(g/m) Φ6 Φ9.52 or Φ12 Φ6 or Φ9.52 Φ16 or Φ19 Φ12 Φ19 or Φ22.2 Φ16 Φ25.4 or Φ31.8 Φ19 Φ22.2 ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 35: Pipe Expanding Method
● Remove the union nut on the indoor smooth surface connection pipe and outdoor valve; install the union nut on the pipe. improper expanding union pipe damaged leaning crack uneven surface thickness pipe the length is equal ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...

This manual is also suitable for:

Vwm13h25 Vwm18h25 Vwm24h25
