Item
AP Isolation
BSSID
Maximum Clients
Management Frame
Protection
Tx/Rx
Operation frequency
Country Code
Band
Band / Channel
bandwidth
Channel / Frequency
Submit
Description
Click the drop-down menu to enable or disable the AP Isolation
function.The function is only enabled when Operation Mode is set
to Access Point.
Display the MAC address of the device.
Enter the value (1 to 128) designating the maximum number of
clients per wireless device.
Click the radio button to enable, disable, or set the function to
optional. The wireless feature increases the security of the
management frames, standard: IEEE 802.11W-2009.
Click to select the transmission signal stream, single or dual
stream.
Click the drop-down menu to select the country code to specify
different selectable channels. Some specific channels and/or
operational frequency bands are country dependent.
Click the drop-down menu to select the band channel.
Click the drop-down menu to select the band and channel
bandwidth: 11b/g - Non-HT (Legacy), 11n - HT20, 11n - HT40, or
11ac - VHT 80 (5GHz only).
Click the drop-down menu to select a wireless channel/frequency:
–
AutoSelect
–
Channel 1: 2.412 GHz
–
Channel 2: 2.417 GHz
–
Channel 3: 2.422 GHz
–
Channel 4: 2.427 GHz
–
Channel 5: 2.432 GHz
–
Channel 6: 2.437 GHz
–
Channel 7: 2.442 GHz
–
Channel 8: 2.447 GHz
–
Channel 9: 2.452 GHz
–
Channel 10: 2.457 GHz
–
Channel 11: 2.462 GHz
–
Channel 12: 2.467 GHz
–
Channel 13: 2.472 GHz
–
Channel 14: 2.484 GHz (802.11b)
Click Submit to save the values and update the screen.
