Bryant Legacy 547K Service And Maintenance Instructions

Single package rooftop heat pump with puron refrigerant
Hide thumbs Also See for Legacy 547K:
Table of Contents

Advertisement

Quick Links

Legacy™ Line
547K 04-07
Single Package Rooftop Heat Pump
with Puron
(R-410A) Refrigerant
®
Service and Maintenance Instructions
CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . . 2
UNIT ARRANGEMENT AND ACCESS . . . . . . . . . . . . . . 3
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SUPPLY FAN (BLOWER) SECTION . . . . . . . . . . . . . . . . 4
Supply Fan (Direct-Drive) . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Staged Air Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
COOLING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Condenser Coil (Outdoor) . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Evaporator Coil (Indoor) . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Recommendation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Evaporator Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Refrigeration System Components . . . . . . . . . . . . . . . . . . 11
Evaporator Coil Metering Devices . . . . . . . . . . . . . . . . . . 12
TXV Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Replacing TXV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Refrigerant System Pressure Access Ports . . . . . . . . . . . . 13
PURON (R-410A) REFRIGERANT . . . . . . . . . . . . . . . . . 13
Refrigerant Charge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
COOLING CHARGING CHARTS . . . . . . . . . . . . . . . . . 14
COMPRESSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Replacing Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Compressor Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Filter Drier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Condenser-Fan Adjustment . . . . . . . . . . . . . . . . . . . . . . . . 16
Troubleshooting Cooling System . . . . . . . . . . . . . . . . . . . . 17
CONVENIENCE OUTLETS . . . . . . . . . . . . . . . . . . . . . . 18
Convenience Outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Installing Weatherproof Cover . . . . . . . . . . . . . . . . . . . . . 18
Non-Powered Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Unit-Powered Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Duty Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Fuse on Powered Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
COMMERICAL DEFROST CONTROL . . . . . . . . . . . . 19
Reversing Valve Control . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Compressor Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Auxiliary (Electric) Heat control . . . . . . . . . . . . . . . . . . . . 20
Defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
ELECTRIC HEATERS . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Safety Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Completing Heater Installation . . . . . . . . . . . . . . . . . . . . . 22
SMOKE DETECTORS . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Smoke Detector Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Smoke Detector Locations . . . . . . . . . . . . . . . . . . . . . . . . . 23
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53547004-01
Page
Printed in U.S.A.
Form 547K-4-7-01
Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
SENSOR AND CONTROLLER TESTS . . . . . . . . . . . . . 25
Sensor Alarm Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Controller Alarm Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Dirty Controller Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Dirty Sensor Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Changing the Dirt Sensor Test . . . . . . . . . . . . . . . . . . . . . 26
Remote Station Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
SD-TRM4 Remote Alarm Test Procedure . . . . . . . . . . . . 26
Dirty Sensor Test Using an SD-TRM4 . . . . . . . . . . . . . . . 26
Detector Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
PROTECTIVE DEVICES . . . . . . . . . . . . . . . . . . . . . . . . . 28
Compressor Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Relief Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Control Circuit, 24-V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
RTU OPEN CONTROL SYSTEM . . . . . . . . . . . . . . . . . . 29
Sensory/Accessory Installation . . . . . . . . . . . . . . . . . . . . . 29
and Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
ECONOMIZER SYSTEMS . . . . . . . . . . . . . . . . . . . . . . . 30
EconoMi$er2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
EconoMi$er X (Factory Option) . . . . . . . . . . . . . . . . . . . . 39
PRE-START-UP/START-UP . . . . . . . . . . . . . . . . . . . . . . 52
START-UP, GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Unit Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Additional Installation/Inspection . . . . . . . . . . . . . . . . . . 52
Return-Air Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Outdoor-Air Inlet Screens . . . . . . . . . . . . . . . . . . . . . . . . . 53
Compressor Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Internal Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Refrigerant Service Ports . . . . . . . . . . . . . . . . . . . . . . . . . 53
Compressor Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Refrigerant Service Ports . . . . . . . . . . . . . . . . . . . . . . . . . 53
Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Ventilation (Continuous Fan) . . . . . . . . . . . . . . . . . . . . . . 53
FASTENER TORQUE VALUES . . . . . . . . . . . . . . . . . . . 53
START-UP, RTU OPEN CONTROLS . . . . . . . . . . . . . . 53
APPENDIX A - MODEL NUMBER
NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
APPENDIX B - PHYSICAL DATA . . . . . . . . . . . . . . . . 55
APPENDIX C - FAN PERFORMANCE . . . . . . . . . . . . 57
APPENDIX D - WIRING DIAGRAMS . . . . . . . . . . . . . 86
APPENDIX E - LOW AMBIENT CONTROL SENSOR
LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
START-UP CHECKLIST . . . . . . . . . . . . . . . . . . . . . . . CL-1
Pg 1
12-2020
Replaces: New

Advertisement

Table of Contents
loading

Related Manuals for Bryant Legacy 547K

Summary of Contents for Bryant Legacy 547K

  • Page 1: Table Of Contents

    Legacy™ Line 547K 04-07 Single Package Rooftop Heat Pump with Puron (R-410A) Refrigerant ® Service and Maintenance Instructions CONTENTS Page Completing Installation of Return Air Smoke Detector ........24 SAFETY CONSIDERATIONS .
