MODEL #
CM-DK913
Questions?
GIVE US A CALL: 1-888-980-5122
MON – FRI 8:30AM – 5:30PM (PST)
TOOLS REQUIRED
2 - People
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM-DK913
Summary of Contents for Furniture of America CM-DK913
- Page 1 MODEL # CM-DK913 Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED 2 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 11...
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Note : Every cam lock bolt must have a cam lock connector in order to fasten the cam bolt cam lock parts together. screwdriver Screw the cam Insert the cam bolt into the bolt into panel. bolt hole of joint panel.
- Page 6 WRITING DESK WITH 1PC DRAWER&USB PLUG CM-DK913 Please keep instructions for future reference. Check the quantity and irregularity of parts and hardware before you start. PARTS 2pcs 2pcs Desk Top Support Panel Desk Top #6 1pc #5 1pc #4 1pc...
- Page 7 HARDWARE #A 1Set #B 1pc #C 2pcs #E 4pcs #D 2pcs Screw Cam-Lock Cam-Botl Socket Sliding Rail #J 2pcs #G 8pcs #H 4pcs #I 4pcs #F 6pcs Bolt Bolt Screw 1/4" X 2" 1/4" X 2-1/2" 1/4" X3/8" Short Screw #N 1pc #K 4pcs #L 4pcs...
- Page 8 Align top supports (#2) to the top (#1), then secure by using bolts (#H). #H x 4pcs #Q x 1pc Align legs (#3) to the top, then secure by using bolts (#F,G). Attach plugs (#K) and levelers (#L) to legs (#3). #3 x 2pcs #A x 1Set Align sliding rails (#A) to the top...
- Page 9 #4 x 1pc #C x 2pcs #5 x 1pc #D x 2pcs #6 x 1pc #E x 4pcs #7 x 1pc #8 x 1pc 2) Slide bottom panel (#8) to the drawer, then align drawer rear (#5) to the drawer. Secure by using screws (#E). 1) Attach cam bolts (#C) to drawer front (#4), then align drawer side panels (#6,7) to drawer front (#4).
- Page 10 #M x 1pc #N x 1pc #O x 1pc #P x 1pc wall 10 / 11...
- Page 11 11 / 11...
