C
B
B
A
A
Assembly Instructions
POD Shelf Unit
A
8 x cam bolt
C
3 x castor
3 x castor
E
bush(pre-
inserted)
- 1 -
COMPONENTS;
2 x Sides (Left & right)
1 x Bottom Shelf
1 x middle shelf
1 x grooved top rail
2 x back panel
1 x box fittings
(Contents as below)
Tools required
8 x cam (pre-
inserted)
12 x 8mm Dowel
(pre-inserted)
1 x"H" profile rear
panel connector
1.
Lay side down on a clean
even surface. Insert cam bolt A
into 5mm holes.
2
. Insert cam B to 15mm holes
on bottom & middle shelf
3
. Fix in position and lock by
turning Cam B in clockwise
direction
B
D
F
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Scallywag Kids POD Shelf Unit
Summary of Contents for Scallywag Kids POD Shelf Unit
- Page 1 Assembly Instructions POD Shelf Unit COMPONENTS; 2 x Sides (Left & right) 1 x Bottom Shelf 1 x middle shelf 1 x grooved top rail 2 x back panel 1 x box fittings (Contents as below) Tools required 8 x cam (pre-...
- Page 2 Firmly locate Grooved cross rail into position . Join the 2 rear panel pieces together with “H” section rear panel connector F Slide the rear panel into position within the grooves .Attach other side and secure turning cams B clockwise as in 2. .Firmly press the castors into the castor bush located on the underside of the bottom shelf...
