Next 877740 Assembly Instructions Manual

Gloss turned table

Advertisement

Quick Links

IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.

Tools Needed

Helpline

If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found
to be faulty. Should you need to return the unassembled product, please repack in the original packaging.

IMPORTANT

• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of
2
persons is required to assemble this product.
• Do not use this item if any structual part is broken or missing.
• All assembly fittings should always be tightened properly.

PRODUCT INFORMATION

• Made fro
m
metal base, MDF and solid wood with a painted finish.
• Made in China.

CARE INSTRUCTIONS

• For general cleaning, periodically dust with a soft clean lint-free cloth or a soft micro fibre cloth. Please note soft
cloths (including yellow dusters) contain abrasive fibres which can lightly scratch the surface, if in doubt please try
your cloth in an inconspicuous area of the furniture first to assess its suitability.
• Do not rub or scrub the surface when cleaning.
• Always use a non-silicone based furniture polish. Silicone in furniture polishes can break down the lacquer finish.
• Do not use abrasive cleaning products or those containing silicone.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent scratching
or damage.
• Do not put hot dished directly on the surfaces of the item.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Gloss finishes are prone to light surface scratch and it is therefore very important that you care for this item
correctly.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.
• Please remove the plastic protection film on the table top before use.
877740 GLOSS TURNED TABLE
ASSEMBLY INSTRUCTIONS.
Page 1 of 8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 877740 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Next 877740

  • Page 1 877740 GLOSS TURNED TABLE ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 FITTINGS ( M6x29mm) (M8x93mm) A x 4 (M6x39mm) C x 3 (M10x90mm) ( 12.5) ( 16.5) Ø1 Ø (Pre-assembled (Pre-assembled with base B x 4 D x 1 E x 3 F x 1 with table top ( 16) ( 17) ( 20) (M4) (M6)
  • Page 3 STEP ONE 1. Remove 3 nuts and paper board from 3 x bolts (C) which attached on base (2), However please do not pull out bolt (C) because bolt (C) also aim as position locator. N.B. : Please do not pull out bolts (C) Page 3 of 8...
  • Page 4 STEP TWO 1. Attach base support (3) and base (2) to pillar (5) by fasten 3 x bolts (C). 2. Attach 1 x bolt (D) ,1 x spring washer (F) and 1 x washer (I) to the assembled unit and tighten by using allen key (L). Page 4 of 8...
  • Page 5 STEP THREE . 1 . Place the table top (4) upside down onto the foam. 2. Screw out 4 x bolts (A) from table top (4) and pull out 4 x washers (G) from table top (4) by the use of allen key (J) N.B: Keep all 4 x bolts (A) &...
  • Page 6 STEP FOUR 1. Attach table top support (1) to the assembled unit with 4 x bolts (B) & 4 x washers (G) and tighten by using allen key (J). Page 6 of 8...
  • Page 7 STEP FIVE 1. Attach table top (4) to the assembled unit with 4 x bolts (A) & 4 x washers (G) and tighten by using allen key (J). N.B.:Please place the foam under the table top for protection purpose. Foam Page 7 of 8...
  • Page 8 STEP SIX 1. Upside down the table to correct position and remove the plastic protection film on top. Next Retail Ltd, Desford Road, Leicester, LE 19 4 AT Page 8 of 8...
