Directed FORD6 Firmware Manual page 13

Vehicle
Function
MS CAN High
MS CAN Low
HS CAN High
HS CAN Low
Driver Door Trigger
Trunk/Hatch Release
Power Liftgate
Lock
Unlock
"Ford Expedition
SA Key
Start
2011-2014"
Ignition
Accessory
Keysense
Headlight Switch
Ground
Parking Light
RX
TX
(+)12V
13
Wire Information
Color Pin Polarity
Gray/Orange 3 Data
Violet/Orange 11 Data
White/Blue 6 Data
14 Data
White
Green/Violet 14 Open to N.C.
Brown 7 Negative
Gray/Yellow 7 Negative
White/Brown 17 Negative
4 Negative
Blue/Brown
Blue/White 10 Positive
White/Orange 1 Positive
Brown/Yellow 7 Positive
Blue/Gray 3 Positive
Black/White 7 Negative
Blue/Gray 5 Negative
Blue/Gray 4 Data
Violet/Brown 3 Data
Blue/Red 9 Positive
Connector Information
Location
OBDII diagnostic connector.
OBDII diagnostic connector.
OBDII diagnostic connector.
OBDII diagnostic connector.
BCM/SJB in passenger kick panel.
BCM/SJB in passenger kick panel.
Power liftgate switch.
BCM/SJB in passenger kick panel.
BCM/SJB in passenger kick panel.
Ignition switch
Ignition switch
Ignition switch
Ignition switch
Headlight switch
Headlight switch
P.A.T.S. connector at ignition switch.
P.A.T.S. connector at ignition switch.
Ignition switch
Color No. Pin
Black 16-pin
Black 16-pin
Black 16-pin
16-pin
Black
Gray 26-pin
Gray 26-pin
Black 8-pin
Gray 26-pin
26-pin
Gray
Gray 10-pin
Gray 10-pin
Gray 10-pin
Gray 10-pin
Gray 10-pin
Gray 10-pin
Black 4-pin
Black 4-pin
Gray 10-pin
