- Page 1 Instruction Manual ® IEC Centra CL5 and CL5R Centrifuges CL5: VENTILATED Cat. No.6464K: 120 VAC, 60Hz Cat. No.6465K: 220/240 VAC, 50/60Hz CL5R: REFRIGERATED Cat. No.6466K: 120 VAC, 60Hz Cat. No.6467K: 220/240 VAC, 50/60Hz OM6464K Rev. 4 11 January 2004 Analyze Detect Measure Control ™...
-
Page 3: Table Of Contents
Contents 1. Introduction............3 1.1 Product Description ............5 1.2 About This Manual ............5 2. Installation ............5 2.1 Receive the Unit ............5 2.2 Prepare the Installation Site ..........5 2.3 Verify Power Configuration..........6 3. Operation............6 3.1 Rotor and Accessories ..........6 3.2 Starting and Stopping a Run .........7 3.3 Stored Programs ............8 3.4 Rotor Recognition System ..........8... - Page 4 OM6464K Rev. 4 11 January 2004 Page 4 of 24...
-
Page 5: Product Description
1. OPTIONAL: • Program Mode: to define and save a maximum of 99 The IEC Centra CL5 (ventilated model) can be placed in specific sets of run parameters, to recall and reuse a cold room (no colder than 4°C), for processing Timing Modes temperature-sensitive samples. -
Page 6: Verify Power Configuration
5. When the unit is in its new location, ensure that the WARNING WARNING suction cups adhere correctly to the work surface International Electrotechnical Commission standard 1010 part 2-20 limits the permitted movement of a laboratory centrifuge to 12” (300 mm) in the unlikely 3. -
Page 7: Starting And Stopping A Run
1. Load two tubes at positions: 9 and 2. Load four tubes at positions: 1, 5 and 10, 14 7, 3 and 16, 12 3. Load six tubes at positions: 1, 9, 5 and 14, 18, D R IV E P IN 7, 9, 3 and 12, 18, 4. -
Page 8: Stored Programs
3.3 Stored Programs keypad. 2. Press the SAVE key three times. The IEC Centra CL5 Series has an internal memory capable of holding 99 sets of run parameters. Programs are retained When you scroll to a locked program, the letter L will in memory even if the power is turned off. -
Page 9: Front Panel
CAUTION Control/ Function If the rotor chamber is not at the specified Indicator temperature, it will NOT abort a spin. Press the Switches the display from Actual to Set mode. Select STOP key if you need to stop a run. the desired speed using the numeric keypad then press SPEED At the beginning of a spin, if the chamber... -
Page 10: Diagnostic Messages And Error Codes
3.7 Diagnostic Messages and Error Codes Numeric keypad allows inputs to change the Set parameters for Speed/Force, Time, Temperature The beeper sounds in these situations: (refrigerated only), Rotor/Radius, or Program. When any • Two times on power up. mode key is pressed (SPEED, TIME, TEMP or PROGRAM), the numeric display switches from Actual •... -
Page 11: Applications
45°C, at any time during the run. Force Tables indicate the maximum speed and RCF that the No Refrigeration Temp. Sensor (Refrigerated only) IEC Centra CL5(R) can achieve, with various rotor/ norEF The unit displays this code, if the microprocessor is not detecting a temperature measurement from the temperature accessory combinations. -
Page 12: Speed And Force Tables
Maximum Sealed Adapter** Radius No. x Vol. (ml) Description RPM / RCF Qty. x Cat. No. 4 x 250 ml sealed Thermo Electron 2502 4500 3760 16.6 2 pr x 6558E 4 x 250 ml unsealed Corning 1260-250, 1280-250 4500 3760 16.6... - Page 13 Rotor 7851C 24 X 24 Place (1.5 ml X 0.5ml) Microtube Rotor Complete with wind resistant lid and rotor recognition disk Tube Maximum Tube Adapter* Radius No. x Vol. (ml) Description RPM / RCF Quantity x Cat. No. 24 x 1.5-2.0 mL 11x54 mm microtube 15000 21000...
-
Page 14: Derating Tables For Dense Samples
4.3 Derating Tables for Dense Samples The Speed and Force Tables list the maximum speed for each rotor/adapter combination for the IEC Centra CL5 Series cetrifuges. These speeds are specified for samples whose specific gravity is not greater than 1.2 for swinging bucket rotors. -
Page 15: Chemical Resistance Table
Microplate Rotor The Microplate Rotor is designed for centrifugation of multi-well microplates. The weight of the loaded microplates must be equally distributed between the rotor’s two carriers. The maximum rated speed for the rotor when each of the carriers is loaded with 320 grams (total load of 640 grams) is 3650 rpm. CAUTION Loads greater than 320 grams (weight of the microplate and sample) must have maximum speed derated (according to the following table) to avoid rotor failure. -
Page 16: Decontamination Table
4.5 Decontamination Table Compatible Processes For Decontamination Sterilization Methods Plastic Metal Other Mechanical Autoclave* Ethylene Oxide Gas Dry Heat (2Hrs. @ 160°C) Chemical Ethanol 40% Formalin Methanol 2-Propanol .5% Sodium Hypochlorite** 3% Hydrogen Peroxide 100% Hydrogen Peroxide 5% Phenol Solution *For Oxidizing Acids, see "Oxidizing Agents, strong"... -
Page 17: Rcf Nomograph
4.6 RCF Nomograph OM6464K Rev. 4 11 January 2004 Page 17 of 24... -
Page 18: Maintenance
5.3 Storage: Keep the Unit Dry 5. Maintenance Store parts on a soft surface to avoid damage. Rotors and other parts should be clean and dry. Store them 5.1 Care and Cleaning open to the air, not in a plastic bag, so any residual •... -
Page 19: Specifications
5.6 Fuses 6. Specifications The following fuses are located internally within the IEC CentraCL5 IEC Centra CL5R centrifuge. They should only be replaced by qualified Maximum Speed: 15,000 RPM service personnel. Maximum G Force: 21,200 xg Power Supply PCB (44486) F1 2.5A - Fast Blow, 250V Maximum Rotating Radius: 17.6 cm Power Amplifier PCB (44488)F1 5A - Fast Blow, 250V... - Page 20 OM6464K Rev. 4 11 January 2004 Page 20 of 24...
- Page 21 Thermo Electron Corporation. Printed in the United States of America. www.thermo.com OM6464K Rev. 4...
- Page 22 Notes OM6464K Rev. 4 11 January 2004 Page 22 of 24...
- Page 23 OM6464K Rev. 4 11 January 2004 Page 23 of 24...
- Page 24 +81 45 453 9122 Saint-Petersburg Fax: +81 45 453 9222 +7 812 325 8045 Fax: +7 812 186 1194 © 2003-2004 Thermo Electron Corporation. All rights reserved. Thermo Electron Corporation, and Analyze, Detect, Measure, Control are trademarks of Thermo Electron Corporation.
