Summary of Contents for Thermo Savant SpeedVac SPD121P
- Page 1 Instruction Manual Savant SPD121P ® SpeedVac Concentrator ® 197-3002-00 Rev. C...
-
Page 2: Table Of Contents
Contents Section Overview Page Overview of SPD121P Unit Cover Lock Override Installation of the SPD121P How to Hook Up the SPD121P Section Control Panel Page The Control Panel Description of the Control Panel Section Manual Run Page The Manual Run The Auto Run Section Rotor Selection... -
Page 3: Overview Of Spd121P Unit
1.0 Overview of the SPD121P Unit Figure 1 = Front View Figure 2 = Side View Figure 3 = Back View Fig. 1 Top Radiant Cover Control Panel Front Panel Left Side Panel Anti Skid/Vibration Fig. 2 Right Side Panel Chamber View Window Vacuum Port... -
Page 4: Cover Lock Override
1.1 COVER LOCK OVERRIDE To Open The Top Cover During Power Failure: Remove the screw holding the cover lock’s manual release cord and lightly pull it as shown, while lifting the cover. -
Page 5: Installation Of The Spd121P
® Unpack unit from the box and verify that all the parts match packing list. Read instruction manual carefully! If assistance is required, contact Thermo. If the unit is part of a larger system, use the vacuum tubing supplied to hook up unit (See Figure 4). -
Page 6: The Control Panel
2.0 SPD121P Control Panel 2.1 Description of SPD121P Control Panel PRE-HEAT - use to pre-heat chamber to 45 C prior to or between runs. ° Once run is initiated the pre-heat stops. RC ON/OFF - Use to add radiant heat to chamber. Manual activation ON/OFF at any point during run. -
Page 7: The Manual Run
3.0 THE MANUAL RUN SPD121P Connect the unit to its required voltage. Turn the power switch to ON, located on the back of the unit. The cover lock, disengages, allowing the top cover to be opened. The display lights up, showing the following default values: Temperature: C in RED °... -
Page 8: The Auto Run
3.1 THE AUTO RUN TIME OR VACUUM SPD121P TIME Refer to the “MANUAL RUN” section for start up. Place the sample tubes in rotor so load is balanced. Secure rotor with supplied knob (hand tight). Close cover. To execute an AUTO ” TIMED” RUN, execute the following steps: Press “RUN TYPE”... - Page 9 VACUUM Executing an AUTO “VACUUM” RUN type: (GREEN light ON above vacuum). Press “RUN TYPE” to select “VACUUM” RUN. Using “SELECT” button and the up/down keys set “VACUUM” pressure at which the run should end. (Ex. 500 Microns), would be entered as 00.5 torr.
-
Page 10: Rotor Selection Guide
4.0 Rotor Selection Guide Working Rotor Number Description Volume (ml) Model of Tubes 1.5 - 2.0 ml RH40-11 1.2 - 1.6 MICROCENTRIFUGE 1.5 - 2.0 ml 1.2 - 1.6 RH64-11 TUBES 1.5 - 2.0 ml 1.2 - 1.6 RH120-11 0.5ml (8 x 29mm) RH100-8 GLASS AND 0.4ml (6x 50mm) -
Page 11: Guideline For Solvent Choice
• Chloroform • Ethyl Acetate • Hydrochloric Acid • Trifluoroacetic Acid • Dimethyl Sulfoxide (DMSO) Part II All other solvents not listed above Contact a Thermo Application Scientist to see if your solvent can be used with the SPD121P concentrator. -
Page 12: Maintenance/Service
RETURNED UNITS MUST BE DECONTAMINATED AND FREE OF RADIOACTIVITY AND SHOULD BE ACCOMPANIED WITH A DECONTAMINATION FORM. PLEASE CALL THER- MO TO HAVE THIS FORM FAXED TO YOU! Under no circumstances shall Thermo be liable for damages due to the improper handling or use of its products. Thermo... -
Page 13: Appendix 1 - Additional Spd121P System Set-Ups
APPENDIX 1 Additional SPD121P System Set-ups Vacuum Tubing To Pump ANT100 Exhaust recovery post trap Vacuum Tubing to Cold Trap Vacuum Tubing to Cold Trap SpeedVac ® Concentrator UVS400 SPD121P Universal Vacuum Source SEMI-INTEGRATED SYSTEM Vacuum Tubing DVG50 To Cold Trap From Chamber... - Page 14 SPD-SERIES SPEEDVAC FAMILY ® SPD101B SPD111V SPD121P...
- Page 16 +81 45 453 9122 Saint-Petersburg Fax: +81 45 453 9222 +7 812 325 8045 Fax: +7 812 186 1194 © 2001-2004 Thermo Electron Corporation, All rights reserved. Thermo Electron Corporation, SpeedVac, and Analyze, Detect, Measure, Control, are trademarks of Thermo Electron Corporation.
