Structural Layout - Taski Hauser clean vento 8S Translation Of The Original Instructions Of Use

Structural layout

7 6 5
8
9
1 Opening shackle
2 Socket (max. 150 W) – Only recommended accessories may be
used with this socket!
3 Automatic cable rewind
4 Transport handle
5 Vacuum lid
6 On/Off switch
7 Cable holder bracket
8 Socket for power cord
9 Accessories holder (only vento 15S)
10 Tank
11 Intake
12 Unlocking for suction hose
13 Roller nozzle with bristles (for vento 15S)
14 Roller nozzle with bristles (for vento 8S)
15 Dusting nozzle (standard accessories: for vento 15S)
16 Crevice nozzle (standard accessories: for vento 15S)
17 Admission pipe
18 Hose tube
19 Suction hose
