Operation – Maintenance
Dispensit Cartridge Retainer
For feeding material to a low volume dispense device or applicator. For professional use only.
Not approved to European explosive atmosphere requirements.
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
See page 2 for model information,
including maximum pressure ratings.
Model 24H686 shown
1
3A1452D
EN
Advertisement
Table of Contents
Related Manuals for Graco 24H685
Summary of Contents for Graco 24H685
- Page 1 Operation – Maintenance 3A1452D Dispensit Cartridge Retainer For feeding material to a low volume dispense device or applicator. For professional use only. Not approved to European explosive atmosphere requirements. Important Safety Instructions Read all warnings and instructions in this manual. Save these instructions.
-
Page 2: Table Of Contents
Setup Procedure ..........3 Cartridge Replacement ........4 Cleanup .............. 4 Troubleshooting ..........5 24H686 Parts ............. 6 24H683, 24H685 Parts ........8 24U892, 24U893 Parts ........10 24U894, 24U895 Parts ........12 Hall Sensor Information ........14 Graco Standard Warranty ........15 Graco Information .......... -
Page 3: Setup Procedure
Setup Procedure Warning: Do not exceed the maximum air pressure to the reservoir extend side of the ram, or the maximum air pressure on the retract side of the ram. See page 2 for maximum pressure rating. Warning: Do not the material outlet pressure. See page 2 for maximum pressure rating. Caution: Raise the slide valve towards the regulator;... -
Page 4: Cartridge Replacement
Cartridge Replacement Warning: Do not exceed 100 psi (6.9 bar) air pressure to the reservoir extend side of the ram, or 100 psi (6.9 bar) air pressure on the retract side of the ram. Caution: Raise the slide valve towards the regulator; this will release the air pressure from the extend side of the ram. -
Page 5: Troubleshooting
Troubleshooting If you encounter operating difficulties, review the symptoms below. With each problem there are one or more possible causes, which should be investigated to resolve the situation. Warning: Contents may be under pressure. NOTHING HAPPENS - If absolutely nothing happens when trying to dispense material, check the air supply lines to make sure there is pressure to the regulator. -
Page 6: 24H686 Parts
24H686 Parts 10, 11 Front View Side View... - Page 7 24H686 Parts continued Part Description Quantity A4000047 RETAINER, cartridge A4000168 PLUNGER, drive cylinder SCREW, socket head, 8-32 x 0.63, cup B3500034 point, stainless steel 16H239 CYLINDER, base 96/0197/99 NUT, jam, 1-1/4-12, mild steel SCREW, socket head cap, 10-32 x 1.00, B4000016 stainless steel J3000006...
-
Page 8: 24H683, 24H685 Parts
24H683, 24H685 Parts 117, 118 Side View Front View... - Page 9 24H683, 24H685 Parts continued Quantity 24H683, 24H685, CARTRIDGE, CARTRIDGE, Part Description 20 oz retainer 32 oz retainer 110341 REGULATOR, air 108190 GAUGE, pressure, air J6300012 FITTING, nipple, hex, 1/8 npt J0000018 COUPLING, 1/8 npt, stainless steel, open/close valve J6500011 ADAPTER, hex, ¼ npt x 1/8 npt,...
-
Page 10: 24U892, 24U893 Parts
24U892, 24U893 Parts 215, 216 Front View Side View... - Page 11 24U892, 24U893 Parts continued Quantity 24U892, 24U893, CARTRIDGE, CARTRIDGE, Part Description 6 oz retainer 12 oz retainer 110341 REGULATOR, air 108190 GAUGE, pressure, air J6300012 FITTING, nipple, hex, 1/8npt COUPLING, 1/8npt, stainless steel, J0000018 open close valve ADAPTER, hex, 1/4 npt x 1/8 npt, male J6500011 x male 24S013...
-
Page 12: 24U894, 24U895 Parts
24U894, 24U895 Parts 317, 324, Front View Side View... - Page 13 24U894, 24U895 Parts continued Quantity 24U894, 24U895, CARTRIDGE, CARTRIDGE, 6 oz retainer with 12 oz retainer with Part Description drive cylinder drive cylinder C04069 RETAINER, cartridge, 12 oz C04091 RETAINER, cartridge, 6 oz E3000044 CARTRIDGE, 12 oz, hdpe E3000041 CARTRIDGE, 6 oz, hdpe A4000123 PLUNGER, drive cylinder B3500049...
-
Page 14: Hall Sensor Information
Hall Sensor Information... - Page 15 Hall Sensor Information continued...
-
Page 16: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
