- Page 1 CRCS2DRW Creeper Seat with 2 Drawers - Blue OPERATING MANUAL WARNING INFORMATION PARTS LIST • • SPECIFICATIONS Maximum Seat Capacity ..300 Lbs. each Drawer Capacity ..... 22 Lbs. each Copyright © Professional Tool Products, 2020 All rights reserved CRCS2DRW 03/27/2020...
- Page 2 CRCS2DRW Creeper Seat with 2 Drawers - Blue WARNING INFORMATION This is the safety alert symbol. It is used to alert you WARNING: Indicates a hazardous situation WARNING to potential personal injury hazards. Obey all safety which, if not avoided, could result in death messages that follow this symbol to avoid possible or serious injury.
- Page 3 CRCS2DRW Creeper Seat with 2 Drawers - Blue TOOLS NEEDED FOR ASSEMBLY: Hex Key (included) Phillips® Screwdriver ASSEMBLY INSTRUCTIONS: Attach all (4) casters (#8) to the bottom of the creeper seat frame (#1). Insert the threaded stem of each caster (#8) through the hole, add washers (#3) and tighten nut (#2) onto stem with hex key provided.
- Page 4 CRCS2DRW Creeper Seat with 2 Drawers - Blue PARTS LIST Item Part Description Qty. Seat Frame Nut (incl. w/#8) Spring Washer (incl. w/#8) RSSEAT Seat Cushion-Blue w/Cornwell Logo RSHAND Handle w/Hardware (incl. #6 & 7) Screw (incl. w/#4) Screw (incl. w/#5) CRCSTR 2.5"...
- Page 5 CRCS2DRW Creeper Seat with 2 Drawers - Blue WARRANTY COVERAGE Cornwell Quality Tools Company (“Cornwell”) warrants against defects on this product for a period of ONE (1) YEAR from the date of original retail purchase. Subject to the conditions and limitations set forth below, Cornwell will, at its option, either repair or replace any part of the product(s) that proves defective by reason of improper workmanship or materials.
