Cornwell Tools Pro CTBMM500 Series Assembly Instructions

ASSEMBLY INSTRUCTIONS
FIXED CASTER
Mount push handle (Part #5) to the
same side of the cart as the locking
casters using the four stove bolts,
washers, and nuts provided.
Using 13mm socket completely tighten
all nuts.
CTBMM500BKE, BLE, NGE, RDE, RGE
SWIVEL CASTER (LOCKING)
CTBMM500BKE, BLE, NGE, RDE, RGE
5 Drawer Pro Series Service Cart w/ Power Strip
• Read and follow all instructions in User's Manual.
• Do not load carts beyond rated capacity:
Maximum Total Net Load ...................................................... 700 Lbs.
Top 3 Drawers .................................................................75 Lbs. each
Bottom 2 Drawers .........................................................150 Lbs. each
PLEASE NOTE: Loading cart beyond rated capacity may cause
structural damage to the cart as well as personal and/or property
damage. Please educate your customers to the "dangers of
overloading".
• Lock lid and drawers before moving. • Apply brake on locking
casters anytime cart is in place. • Do not pull cart. Push from handle
on end to move. • Units can tip or fall causing damage or personal
injury. • Cart is designed to roll easily on flat surfaces and should not
be used on uneven or inclined surfaces. • Do not open more than one
loaded drawer at a time. • Do not stand on or step in drawers. • Keep
children away from unit. • Wear gloves when lifting edges. • Before
connecting to a power supply, always check to make sure the power
supply corresponds to the voltage required on the product. • Fully
insert plug to reduce the risk of electric shock. • Always unplug when
not in use. • Disconnect power before installing or servicing. • Do
not try to plug in unit or product when hands are wet or damp, or if
standing on a wet or damp surface or in water. • Never attempt to
pick up unit or plugged in product that should fall in standing water.
• This unit is not waterproof and is intended for general use indoors.
Do not use in potentially dangerous locations, such as flammable
or explosive atmospheres. • Do not use in potentially dangerous
locations, such as flammable or explosive atmospheres. • Keep cord
away from heat, oil, sharp edges or moving parts. • Handling the
brass parts of this product will expose you to lead, a chemical known
to the State of California to cause birth defects and other reproductive
harm. Wash hands after handling. • This product may contain one or
more chemicals known to the State of California to cause cancer
and birth defects or other reproductive harm. Wash hands thoroughly
after handling. • Failure to heed these warnings may result in
personal injury and/or property damage.
1
WARNING
Rev. 12/29/16
