  • Page 2 Vítejte! Výběrem dávkovače integral 4PLUS jste se rozhodli pro precizní a plně automatické dávkovací zařízení pro průmyslové myčky. Integralem 4PLUS se dávkuje tekutý vysoce koncentrovaný mycí a lešticí prostředek. Tím splníte požadavky kuchyňského mytí. V návodu k obsluhy je vysvětlena montáž a provoz přístroje. Pro podporu naleznete na stránkách www.hagleitner.com film pro uživatele k montáži, prvnímu zavedení...
  • Page 3 Welcome! With your selection of the integral 4PLUS dispenser, you have chosen a precise and fully automated dosing unit for industrial, commercial dishwashing machines. Integral 4PLUS dispenser is a dosing device for liquid, concentrated dishwashing detergent and rinse- aid. Specially developed to cover the requirements of commercial dishwashing.
  • Page 4: Table Of Contents

    Co potřebujete ................... Rozsah dodávky ..................integral 4PLUS dávkovač .................. integral 4PLUS FLOWMETER ................integral 4PLUS PUMP POWER / BRITE ............integral 4START POWER / BRITE ..............integral 4PLUS powerPACK ex ................ Volba: integral 4WALL ..................Volba: integral 4PLUS DISPLAY ...............
  • Page 5 What you need ................... Scope of delivery ..................integral 4PLUS dispenser ................. integral 4PLUS FLOWMETER ................integral 4PLUS PUMP POWER / BRITE ............integral 4START POWER / BRITE ..............integral 4PLUS powerPACK ex ................ Option: integral 4WALL ..................Option: integral 4PLUS DISPLAY ..............
  • Page 6: Co Potřebujete

    Co potřebujete / What you need Uložte aplikaci HAGLEITNER sem. Download the HAGLEITNER App. + Android Technická data / Technical specifications: Hmotnost / Weight: stěna/wall 3,7 kg, Podlaha/floor 3,37 kg Rozměry / Dimensions: stěna/wall 34,5, Podlaha/floor 27,5 (v) x 17,8 (š) x 22,2 cm (h) Vodní...
  • Page 7: Rozsah Dodávky

    Rozsah dodávky / Scope of delivery Integral 4PLUS dávkovač / integral 4PLUS dispenser  integral 4PLUS - dávkovač  integral 4PLUS - Dispenser  Boční panel vlevo  side part left  Boční panel vpravo  side part right  Montážní deska nahoru ...
  • Page 8: Integral 4Plus Flowmeter

    Integral 4PLUS FLOW METER / integral 4 PLUS FLOW METER  Vodoměr  flow meter  Propojovací kabel 3 m  bus cabel 3 m  Těsnění  seal integral 4PLUS FLOW METER 1 Stück/piece    integral 4PLUS PUMP POWER / integral 4PLUS PUMP POWER integral 4PLUS PUMP POWER 1 Stück/piece...
  • Page 9: Integral 4Start Power / Brite

     Hadice k lešticímu prostředku 6 m - Ø 6 mm  hose for rinse-aid 6m - Ø 6 mm  Kabelová spojka  cable ties  Lepicí sokl  adhesive mounts  Čisticí hadřík  cleaning cloth     integral 4START BRITE PIPE 1 Stück/piece integral 4PLUS |...
  • Page 10: Volba: Integral 4Wall

     Šroub krátký  integral 4WALL 1 Stück/piece   Volba: integral 4PLUS DISPLAY / Option: integral 4PLUS DISPLAY  integral 4PLUS DISPLAY  integral 4PLUS DISPLAY  2 screw, 2 dowel, 2 washer  2 šrouby, 2 hmoždinky, 2 podložky ...
  • Page 11: Montážní Možnosti

    Montážní možnosti / mounting options Montáž pod stůl / undertable mounting min. 410 mm Montáž na stěnu / wall mounting integral 4PLUS |...
  • Page 12 DIN VDE 100 DIN VDE 100 Zone 3 Zone 2 230V max. 3 m  max. 3 m max. 6 m 3/4 coulu  | integral 4PLUS...
  • Page 13: Nasadit Čerpadlo

    Nasadit čerpadlo / insert pump Nasadit čerpadlo / insert pump Skenovat dávkovač / scan dispenser 01-01-0001-413110036600 TTMMJJMM-XXXX AA:BB:CC:DD:EE:FF Skenovat čerpadlo / scan pump integral 4PLUS |...
  • Page 14 Skenovat vodoměr / scan flow meter 01-01-0001-413110036600 TTMMJJMM-XXXX AA:BB:CC:DD:EE:FF | integral 4PLUS...
  • Page 15 4PLUS |...
  • Page 16 Kliknout | integral 4PLUS...
  • Page 17 Tlačit nahoru / upside Posunout nahoru Ujistěte se, že spojení chemie je správně uzamčeno a pevně usazeno. Make sure that the chemistry coupling is cor- rectly locked and fixed. integral 4PLUS |...
  • Page 18: Nalepit Etiketu

    Nasadit etiketu / insert label Pokračujte v aplikaci / follow the APP | integral 4PLUS...
  • Page 19: Montáž Jednotlivého Čerpadla

    Montáž jednotlivého čerpadla / Installation individual dispenser Montáž pod stůl - jednotlivé čerpadlo / under table installation individual dispenser min. 10 mm 400 mm integral 4PLUS |...
  • Page 20 Rigips | integral 4PLUS...
  • Page 21 4PLUS |...
  • Page 22: Montáž Na Stěnu - Jednotlivé Čerpadlo

    Montáž na stěnu - jednotlivé čerpadlo / wall installation individual dispenser Nálepka / template Volba integral 4PLUS 230 V (EU); 110 V (USA) max. 3 m 24 V-DC max. 1,5 A Volba | integral 4PLUS...
  • Page 23 Volba Hadice / hose Kliknout Kliknout integral 4PLUS |...
  • Page 24: Montáž Do Řady

    Montáž do řady / Row installation Montáž do řady pod stůl / row installation under table min. 10 mm 400 mm | integral 4PLUS...
  • Page 25 2 x 4 integral 4PLUS |...
  • Page 26 2 x 4 | integral 4PLUS...
  • Page 27 2 x 4 max. 3 dávkovače / dispenser integral 4PLUS |...
  • Page 28: Montáž Do Řady Na Stěnu

    4PLUS 4PLUS 230 V (EU); 110 V (USA) 230 V (EU); 110 V (USA) max. 3 m max. 3 m 24 V-DC Volba Volba 24 V-DC max. 1,5 A max. 1,5 A Nálepka / template Volba Volba | integral 4PLUS...
  • Page 29 Volba Hadice / hose Kliknout Kliknout integral 4PLUS |...
  • Page 30 Kliknout | integral 4PLUS...
  • Page 31 Kliknout max. 3 dávkovače / dispenser integral 4PLUS |...
  • Page 32: Montáž Integral 4Plus Flowmeter

    Montáž integral 4PLUS FLOWMETER / installation integral 4PLUS FLOWMETER max. 5-60° C Water stop coulu Připojení vody - myčka / water supply dish washer | integral 4PLUS...
  • Page 33 Voda zapnutá integral 4PLUS |...
  • Page 34: Položení Hadic A Kabelů - Jednotlivé Čerpadlo

    Položení hadic a kabelů - jednotlivé čerpadlo / hose and cable installation individual dispenser Položení hadic / hose installation ca. 10 cm Hadice / hose Položení kabelů / cable installation IN: 100~240VAC 50/60Hz OUT: 24VDC, max. 1,5A | integral 4PLUS...
  • Page 35 4PLUS |...
  • Page 36: Připojit Boční Panely

    Připojit boční panely / side part mounting vpravo vlevo right left Kliknout Klikn- | integral 4PLUS...
  • Page 37: Nasadit Dávkovač

    Nasadit dávkovač / dispenser mounting PUSH integral 4PLUS |...
  • Page 38 Zavřít | integral 4PLUS...
  • Page 39: Připojit Rohový Díl

    Připojit rohový díl / connecting L-part integral 4PLUS |...
  • Page 40 Pro snazší nasazení: navhlčit hadici/ For easy mounting: moisten the hose | integral 4PLUS...
  • Page 41: Připojit Kabel

    Připojit kabel / connecting cable integral 4PLUS |...
  • Page 42 Kliknout Kliknout | integral 4PLUS...
  • Page 43: Položení Hadic A Kabelů - Montáž Do Řady

    Dávkovač na lešticí prostředek / dispenser cleaner dispenser rinse aid ca. 10 cm Hadice k čisticímu prostředku Ø 8 mm hose for cleaner Volba Hadice k lešticímu prostředku / hose for rinse aid Ø 6 mm Volba ca. 10 cm Volba integral 4PLUS |...
  • Page 44 Položení kabelů / cable installation 100~240VAC 50/60Hz Volba vpravo / right | integral 4PLUS...
  • Page 45: Připojit Boční Panely

    Připojit boční panely / side part mounting vpravo vlevo right left Klikn- Kliknout integral 4PLUS |...
  • Page 46: Nasadit Dávkovač

    Nasadit dávkovač / dispenser mounting PUSH Dávkovač na čisticí prostředek / Dávkovač na lešticí prostředek / dispenser rinse aid dispenser cleaner | integral 4PLUS...
  • Page 47 Zavřít integral 4PLUS |...
  • Page 48: Připojit Rohový Díl

    Připojit rohový díl / connecting L-parts Použijte zde rohový díl „integral 4START POWER“ Use here the L-Part „integral 4START POWER“ | integral 4PLUS...
  • Page 49 Pro snazší nasazení: navhlčit hadici/ For easy mounting: moisten the hose integral 4PLUS |...
  • Page 50 Použijte zde rohový díl „integral 4START BRITE“ Use here the L-part „integral 4START BRITE“ Opakujte kroky 1-4 při upevnění rohového dílu v dávkovači na lešticí prostředek. Repeat steps 1-4 to fix the L-part in the rinse-aid dispenser. | integral 4PLUS...
  • Page 51: Připojit Kabel

    Připojit kabel / connecting cable integral 4PLUS |...
  • Page 52: Montáž Připojení K Čisticímu Přípravku

    5. Lehce přístupné a viditelné (otevřený stroj) Position tank inlet: 1. In the washing tank of the machine 2. Below the basket guide rail 3. Above water level 4. Not directly above motors or boards 5. Easy to access and visible (open machine) | integral 4PLUS...
  • Page 53 Ø 13,5- 14 mm 14 mm OPTION 17 mm integral 4PLUS |...
  • Page 54: Montáž Připojení K Lešticímu Přípravku

    Montáž připojení k lešticímu přípravku / installation rinse-aid connection Montáž zpětného ventilu / installation check valve Kabel a hadice ochránit před zatížením Make sure that all cables and hoses are relieved of strain. | integral 4PLUS...
  • Page 55: Připojení K Elektřině

    Připojení k elektřině / power connection 100~240VAC 50/60Hz 24VDC Kabel a hadice ochránit před zatížením Make sure that all cables and hoses are relieved of strain. integral 4PLUS |...
  • Page 56: Aplikace: Aktivace Dávkovače

    Aplikace: aktivace dávkovače / App: activation dispenser Přezkoušejte po zprovoznění dle aplikace / Check after installation according to the app Údržbové díly / wearing parts integral 4PLUS FLOW METER integral 4START POWER PIPE integral 4PLUS PUMP POWER integral 4START POWER PIPE integral 4PLUS PUMP BRITE Intervaly údržby údržbových dílů...
  • Page 57: Obsluha

    Obsluha / operation Výměna patron / cartridge exchange Kliknout Tlačit integral 4PLUS |...
  • Page 58: Piktogramy

    / pictograms Piktogramy integral 4PLUS dávkovač / integral 4PLUS dispenser Piktogram Barva Signal pictogram colour signal zelená Dávkovač je připraven k provozu green dispenser is ready to use Dávkovač běží, vyskytl se problém - de- oranžová taily v aplikaci orange dispenser is working, maintenance requi- red –...
  • Page 59 4PLUS Display / integral 4PLUS display Piktogram Barva Signal pictogram colour signal zelená Dávkovač je připraven k provozu green dispenser is ready to use Dávkovač běží, vyskytl se problém - de- oranžová taily v aplikaci orange dispenser is working, maintenance requi- red –...
  • Page 60 EC-DECLARATION of CONFORMITY The distributor: Company Hagleitner Hygiene International GmbH Lunastraße 5 5700 Zell am See declares under our sole responsibility that the entire system Integral 4PLUS Type: Dosing System Mach. Nr.: P0343 Year of manufacture: 2018 Corresponds to the following regulations and standards:...
