JBL Performance Series Technical Manual page 2

Technical Manual
IS6DT
Performance
EXPLODED VIEW
7
8
9
Item Part No.
1 316-PC-05201-1TAE
2 329-060-00780-0WAE GRILLE ASS'Y
3 352-BM04050D386-E
4 301-ABS-00373-0WBE BAFFLE ASSEMBLY
5 325-ABS-00446-0BAE DOG EAR
6 CS60RDT-BK-P
7 352-FM04010D462-E
Harman Consumer Group, Inc., 250 Crossways Park Drive, Woodbury, New York 11797
™
5
6
Description
JBL LOGO
SCREW, DOG EAR
WOOFER/TWEETER ASS'Y
SCREW, WOOFER T4*10
IS6DT ROUGH-IN FRAME part # RIF6C
Series
3
4
Qty. Item Part No.
1 8 013-7600-05196-E
1 9 352-CM04008D144-E
4 10 402-000-05532-E
1 11 403-000-05006-E
4 12 405-000-05008-E
1 13 406-000-05371-E
4 14 431-000-05054-E
1
2
Description
CROSSOVER NETWORK
SCREW, NETWORK T4*10
OUTER CARTON
TEMPLATE
WARRANTY CARD
OWNER'S MANUAL
EPS PACKING MATERAL
Qty.
2
4
1
1
1
1
1
3/07
