JBL Performance Series Technical Manual

Technical Manual
IS6C
Performance
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
• Crossover Frequency
SYSTEM COMPONENTS:
• Grille, Gray
• Low-Frequency Transducer
DC Resistance
• High-Frequency Transducer
DC Resistance
• Crossover Network
PACKAGING
11
Harman Consumer Group, Inc., 250 Crossways Park Drive, Woodbury, New York 11797
™ Series
8 Ohms
80 Watts*
40Hz – 20kHz (–10dB)
88dB (2.83V @ 1 meter)
2,600Hz
590-0271
6-1/2" (165mm) Titanium-
laminate cone w/rubber
surround (590-0285)
6.2 Ohms, ±10%
1" (25mm) Titanium-laminate
dome, w/swivel mount
(590-0287)
7.6 Ohms, ±10%
590-0286
Legend on Page 2
12
10
9
AURAL SWEEP TEST SPECIFICATIONS:
• System Aural Sweep Test
• L.F. Aural Sweep Test
• H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS:
• Plate Size (Diameter)
• Mounting Cutout
Size (Diameter)
• Mounting Depth
• Weight
WARRANTY:
• Refer to Warranty Statement packed with each product.
* The maximum recommended amplifier power rating will ensure
proper system headroom to allow for occasional peaks. We do not
recommend sustained operation at these maximum power levels.
WIRING DIAGRAM
CROSSOVER
NETWORK
590-0286
L1
1.4mH
3.9 ohms
C2
5µf
250V
0.5mH
6.0V Input 40Hz to 20kHz
5.0V Input 40Hz to 4kHz
2.83V Input 2kHz to 20kHz
9-3/16" (233mm)
7-7/8" (200mm)
4-1/4" (108mm)
8 lb/3.7kg (sold in pairs)
LOW-
FREQUENCY
TRANSDUCER
590-0285
GRN +
BLK –
HIGH-
FREQUENCY
TRANSDUCER
590-0287
YEL
+
BLK
–
GRN
.250
C1
13µf
100V
BLK
.205
R1
5 watts
YEL
.110
R2
L2
3.9 ohms
5 watts
BLK
.110
1/07
