DOMINATOR 150 / 140 / 130
Operator's Manual

Advertisement

Table of Contents
loading

Related Manuals for Claas DOMINATOR 150

Summary of Contents for Claas DOMINATOR 150

  • Page 1 DOMINATOR 150 / 140 / 130 Operator’s Manual...
  • Page 2 67075...
  • Page 3 (Title and/or number and date of issue of standard(s) and/or technical specification(s)) Technical Management Quality Management (J.H. Mohr) (U. Krieg) (Name, function and signature of the authorized person) Harsewinkel, (Place and date of issue) 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 4 For the relevant implementation of the safety and health requirements mentioned in the Directives, the following standard(s) and/or technical specification(s) has (have) been respected: EN 632 - August 1995 The person responsible for documentation in the European Community is: J.H. Mohr, CLAAS Selbstfahrende Erntemaschinen GmbH, Postfach 11 63, D-33416 Harsewinkel...

  • Page 5: Table Of Contents

    3.1.19 Accumulators ............. . 41 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 6 4.1 DOMINATOR 150 / 140 / 130 ........
  • Page 7 Multifunction handle (DOMINATOR 150 / 140) ........
  • Page 8 Starting the diesel engine (DOMINATOR 150 / 140) ....... 143...
  • Page 9 Foot brake ............. . . 156 9.4.4 Braking / stopping the machine (DOMINATOR 150 / 140) ......157 9.4.5 Braking / stopping the machine (DOMINATOR 130) .
  • Page 10 10.7 Grain delivery ..............191 10.7.1 Adjusting the grain tank full indicator DOMINATOR 150 ......191 11 Fieldwork 11.1 General Information .
  • Page 11 11.10.2 Opening / closing the grain tank cover ......... . 231 11.10.3 Swinging the grain tank unloading tube out / in (DOMINATOR 150 / 140) ....232 11.10.4 Swinging the grain tank unloading tube out / in (DOMINATOR 130) .
  • Page 12 13.5.31Cleaning the air filter intake screen ..........303 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 13 13.6.3 Cleaning the surroundings of the drive axle manual gearbox ......308 13.6.4 Checking the final drive oil level DOMINATOR 150 / 140 ......308 13.6.5 Draining the final drive oil DOMINATOR 150 / 140 .
  • Page 14 14.1.9 Lubrication points - 100 h on the right ......... . 377 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 15 14.1.11 Lubrication points - 500 h on the right ......... . 379 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 16: Introduction

    Formatting Meaning Description Description Text Further information on the subject. – Instructions Operation Operations which must be carried out one after the other. Result Result Consequence of operations carried out. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 17 Both terms designate possible variants. Standard scopes and equipment variants may differ in other countries. Your CLAAS Service Department 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 18: Validity Of Instructions

    4 t. CLAAS self-propelled working machines are usually equipped with 1 rigid or 2 folding wheel chocks. These may be used on the front wheels only. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 19 § 19 of the German Regulations Authorising the Use of Vehicles for Road Traffic. If you are in any doubt as to whether this situation applies in your case, please contact CLAAS as the manufacturers. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 20 Always switch off the work lights when driving on pub- lic roads and lanes. Folding front attachments The subsequent fitting of folding front attachments will void the individual operating permit of the machine and its special approval. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 21: Note On Electronic Engine Management

    Fiddling with the electronic engine management may result in an increased risk from an insurance law point of view, and consequently in loss of insurance cover in comprehensive and liability insurance. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 22 If sales partners participate in such interventions, they may be liable for damage to the machine and any con- sequential damage. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 23: Various Components / Machine Body

    The identification no. / nos. of the software can be found in the respective menu. 71370 1.2.2 Machine identification plate The identification plate is affixed to the right machine side above the drive wheel. 14519 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 24 Maximum admissible load on front axle Year of construction Rated capacity of engine (kW) Maximum admissible load on rear axle Approval no. according to ECE-R 24 Absorption coefficient according to ECE-R 24 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 25: Identification Plate Of Caterpillar 3056 E Engine

    The identification plate is located next to the injection pump. 14521 71383 1.2.4 Identification plate of PERKINS 1006-6T engine The identification plate is located next to the injection pump. 24696 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 26: Identification Plate Of Caterpillar C6.6 Engine

    1.2.6 Drive axle identification plate The identification plate is affixed to the front side of the axle. 24558 71544 1.2.7 Rear axle identification plate The identification plate is fixed to the axle. 24551 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 27: Trailer Hitch Identification Plate

    The identification plate is punched into the trailer hitch. Trailer hitch type AK 64/1 B ... 24699 The identification plate is fixed to the trailer hitch. Trailer hitch type 841 ... 36440 Trailer hitch type 810 ... 40022 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 28: Hitch Block Identification Plate

    AK 64/1 B ... 24699 The type number is punched on the hitch block. on trailer hitch type 841 ... 36440 on trailer hitch type 810 ... 40022 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 29: Cab Identification Plate

    The identification plate with the identification number is fitted on the left machine side. 14524 71388 1.2.11 Straw chopper identification plate The identification plate with the identification number is fitted on the left machine side. 14523 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 30: Sectional View Of Machine

    Reel tines Reel intermediate drive Reel variable speed drive Reel cylinder Crop lifter Intake auger Feed rake conveyor Feed rake Cutterbar cylinder Stone trap Concave Threshing drum Impeller Deflector curtain 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 31 Grain tank unloading auger Grain tank Returns auger Returns elevator Returns delivery auger Engine air filter air filter intake screen Operator's platform Final drive gearbox Manual gearbox Traction wheels Rear wheels 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 32: Access To The Workplace And Maintenance Areas

    / safety measures before they are entered. – Enter the workplace in the cab via the front ladder (2) and via the maintenance area at the left-hand operator's platform (3). 39618 39615 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 33 – Enter the maintenance area at the engine platform (3) via the engine platform maintenance area (2) to perform maintenance on the diesel engine. 39620 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 34: Safety

    (acci- dent prevention). CLAAS is in no way liable for any damage or personal injury caused through the use of other than original or approved CLAAS parts, accessories and ancillary equipment.

  • Page 35: Reasonable Foreseeable Misuse

    • Nonobservance of warning signs on the machine and in the operator's manual • Performance of servicing and repair work by untrained personnel • Unauthorised modifications to the machine 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 36: Safety And Accident Prevention Regulations

    Do not smoke during refuelling. • Always stop the diesel engine and remove the ignition key before refuelling. Fill the fuel tank out- doors. Clean up any spilled fuel immediately! 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 37: General Safety And Accident Prevention Regulations For Combine Harvesters

    • Before driving off, always check the front and rear wheels for the correct tyre pressures! 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 38: Additional Weights

    • When travelling on public roads swing in the grain tank unloading tube all the way. • When travelling on public roads close the grain tank cover. • Existing traffic regulations must be observed. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 39: Driving Operations On Slopes

    • When attaching front attachments always make sure that the load on the existing rear axle is suffi- cient to maintain the forage harvester's steering and braking capabilities. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 40: Crop Receptacle / Straw Receptacle

    • Always turn off the battery isolating switch before carrying out any electrical repairs on the machine. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 41: Accumulators

    • Irritation of the respiratory tract • Headache • Giddiness Effects on the central nervous system in case of high doses: • Difficulty in breathing • Unconsciousness Swallowing: • Sickness • Vomiting • Liver damage 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 42: First Aid Measures

    CLAAS dealer or the CLAAS service department. – Do not dispose of products marked with the symbol (1) in your domestic waste at the end of their service life. 39207 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 43: Applying The Feeder Housing Safety Lock

    3.1.24 Moving out the feed rake conveyor safety lock While the combine-harvester is in operation, the cutter- bar cylinder safety lock (1) must be moved up and arrested by locking pin (2). 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 44: Secure The Machine With Wheel Chocks So It Will Not Roll Away

    – Place the wheel chock (1) in front of or behind the front wheel, depending on the slope. – Place the wheel chocks (1) close to the drive wheels. Now the machine is protected against rolling away. 2732 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 45: Securing The Straw Guide Apron In Raised Position

    Country variant for Sweden: The machine is delivered 14530 ex works with a second fire extinguisher (1). – Before commissioning the machine, mount the second fire extinguisher (1) at position on the machine provided for this purpose. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 46: Battery Isolating Switch

    Death or serious injury. Even a pinhole can result in severe injuries. – If hydraulic fluid gets in the skin or eyes, have the injury treated by a medical spe- cialist immediately. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 47: Loading And Tying Down The Machine

    – Suspend the machine into the devices intended for this purpose and marked with hazard warning signs (1). – Tie down the machine with the devices intended for this purpose and marked with safety decals (1). 9602 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 48 CLAAS dealer. – Use only flawless and sufficiently dimen- sioned lifting devices for lifting the machine. 30867 – Protect your lifting devices against sharp corners and edges, e.g. by protectors. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 49: Removing The Lift Eyes

    – Remove the lift eyes and keep them for future transport. WARNING: Improper transport! Material damage to the machine. – Lift eyes removed during the initial machine delivery must be kept for future transport. 24680 27269 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 50: Safety Rules

    – Countermeasures Note! Nature and source of information Consequences: enhanced machine economy or easy assembly – Measures Environment! Nature and source of danger Consequences: damage to the environment – Countermeasures 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 51: Safety Decals

    – When parts that have hazard warning signs / safety decals are replaced, always make sure to attach the relevant new haz- ard warning signs / safety decals to each new part. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 52: Engine

    00 0516 034 0 (17) 14569 Do not open or remove safety shields while engine is running. 00 0516 064 0 (22) Do not open or remove safety shields while engine is 14578 running. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 53 3 Safety 3.3 Safety decals 67079 00 0516 045 0 (35) 14577 Keep sufficient distance away from electrical power lines. 00 0516 046 0 (39) 14577 Stay clear of hot surfaces. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 54: Chassis

    00 0516 525 0 (39) Stay clear of hot surfaces. 14578 71830 3.3.3 Chassis 00 0516 047 0 (40) 14675 Use wheel chock before machine is uncoupled or parked. 14674 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 55: Cab / Operator's Platform

    14537 machine. Observe instructions and safety rules when operating. 00 0514 946 1 (2) 14538 Carefully read operator’s manual before handling the machine. Observe instructions and safety rules when operating. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 56 00 0514 895 1 (33) 14538 Shut off engine and remove key before performing maintenance or repair work. 00 0516 044 0 (34) 14575 Do not ride on platform or ladder. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 57: Feeder Unit

    Do not operate machine unless an approved fire extin- guisher is installed. 71915 3.3.5 Feeder unit 00 0516 042 0 (4) 24611 Never stand in the hazard area between the front attachment and the machine. 14540 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 58 Secure lifting cylinder with locking device before get- ting in hazardous area. 14540 00 0514 923 1 (15) Do not open or remove safety shields while engine is 14560 running. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 59 00 0516 039 0 (22) 24611 Do not open or remove safety shields while engine is running. 00 0516 043 0 (36) 14540 Avoid fluid escaping under pressure. Consult technical manual for service procedures. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 60: Threshing Mechanism

    3 Safety 3.3 Safety decals 67079 71916 3.3.6 Threshing mechanism 00 0514 896 1 (5) Touch machine parts only after they have come to a 14541 complete halt. 14542 14543 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 61 Do not open or remove safety shields while engine is running. 14675 14674 00 0516 064 0 (22) Do not open or remove safety shields while engine is 14679 running. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 62: Separation

    3 Safety 3.3 Safety decals 67079 71917 3.3.7 Separation 00 0516 039 0 (22) 14676 Do not open or remove safety shields while engine is running. 14677 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 63 3 Safety 3.3 Safety decals 67079 00 0516 054 0 (27) 14571 Do not open or remove safety shields while engine is running. 14680 14681 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 64: Crop Receptacle / Straw Receptacle

    3.3 Safety decals 67079 71918 3.3.8 Crop receptacle / straw receptacle 00 0514 896 1 (5) Touch machine parts only after they have come to a 14557 complete halt. 14558 14532 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 65 Touch machine parts only after they have come to a complete standstill. 14549 00 0516 064 0 (22) Do not open or remove safety shields while engine is 14678 running. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 66 3 Safety 3.3 Safety decals 67079 00 0514 897 1 (32) Danger - flying objects; keep safe distance from the 14557 machine as long as the engine is running. 14558 14532 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 67: Grain Delivery

    14549 71938 3.3.9 Grain delivery 00 0514 923 1 (15) Do not open or remove safety shields while engine is 14561 running. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 68 00 0514 901 1 (15) 14561 Do not open or remove safety shields while engine is running. 00 0516 033 0 (16) 14563 Never move your hands into the rotating auger. 10456 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 69 3 Safety 3.3 Safety decals 67079 00 0516 063 0 (16) Never reach into rotating auger. 14564 14565 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 70 3 Safety 3.3 Safety decals 67079 00 0516 063 0 (16) Never reach into rotating auger. 14566 14567 14568 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 71 00 0516 041 0 (24) 14538 Never reach or climb into grain tank while engine is running. 00 0516 045 0 (35) 14538 Keep sufficient distance away from electrical power lines. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 72: Various Components / Machine Body

    14536 00 0516 753 0 (1) 24680 Use only the marked points for raising the machine. Never stand in the hazard area below the suspended machine. 24681 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 73 3 Safety 3.3 Safety decals 67079 00 0516 044 0 (34) 14576 Do not ride on platform or ladder. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 74: Safety Decals

    / wheel bolt tightening torque. Drive axle 9617 00 0514 234 0 Observe instructions provided on the decal (1). Check wheel nut / wheel bolt tightening torque. Rear axle 30792 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 75: Specifications

    91 (124), kW (hp) • 94 (128), kW (hp) • Alternator 100 A / 12 V • • • Fuel tank capacity 280 litres • • • 200 litres • 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 76: Caterpillar 3056E Engine

    Exhaust gas category 0 • Cubic capacity 6 litres • +10/-40 Maximum no-load speed 2290 • Rated speed 2200 ± 10 rpm • Minimum no-load speed 1200 ± 20 rpm • 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 77: Chassis

    Reverse gear from 3.6 to 9.9 km/h • Differences in ground speed for different tyre ± 10%. • • • sizes. Front wheel drive Final drives running in oil • • • 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 78: Tyre Pressures

    4 Specifications 4.1 DOMINATOR 150 / 140 / 130 67080 72211 4.1.6 Tyre pressures 24769 24770 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 79 4 Specifications 4.1 DOMINATOR 150 / 140 / 130 67080 24771 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 80: Chassis Track Width

    LA-P (mm) (mm) (mm) (mm) Rear axle 11.5/80-15.3 IMP 2040 1790 2080 2370 • • • 00 0637 630 2 12.5/80-18 IMP (320/80-18) 2040 1790 2110 2430 • • • 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 81: Brake

    • • • brakes Parking brake mechanical, independent of foot brake • • • 72237 4.1.9 Steering Designation DOMINATOR Steering, type hydrostatic • • • 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 82: Electric System / Electronics

    3.05 m, 3.66 m, 3.96 m, 4.27 m, • • • 4.57 m • • 5.18 m (country-specific) • 6.09 m (country-specific) • • • Feed rake conveyor Feeder chain 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 83: Threshing Mechanism

    220 ± 5 rpm • • • Straw walker area 4.13 m • • • Straw walker separating area 4.80 m • • • Intensive separators (number) • • • 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 84: Cleaning Unit

    • wheat) 72313 4.1.17 Attachment parts / machine body dimensions Designation DOMINATOR Width of the body (machine width with 3000 mm • • • tyres – see chassis wheel track) 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 85 Left turning circle diameter DIN 70020 15150 mm • • • Right turning circle diameter DIN 70020 15250 mm • • • ** (Height of bottom edge of feed rake conveyor 500 mm) 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 86: Attachment Parts / Machine Body Weights

    • Straw spreader + 97 kg • • • Straw collector + 235 kg • • • * Empty weight without cutterbar, chopper and chaff spreader, with full fuel tank 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 87: Prior To Initial Operation

    Engine – Check the correct seat of air filter. – Check the diesel engine oil level. – Check the radiator coolant level. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 88 Grain delivery – Close the service aperture on the grain tank unloading tube. – Install the grain tank safety device. – Putting the air conditioner into operation (with Sanden compressor) 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 89: Chassis

    Either one or several different types of rear axles are available. The part number for identifying the rear axle is pro- vided on the identification plate of the axle. Rear axle 00 0770 350 1 27215 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 90: Converting The Rear Axle From Transport To Working Position

    • • 2491 • • • 2691 • • • 14.5/75-20 IMP(360/80-20) 2291 • • • 2491 • • • Rear axle 9.5-24 R1 2391 • 00 0770 350 1 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 91: Rear Axle 00 0649 950 1 - Adjusting The Track Width

    – Adjust track width to the tyres used. The track width depends on the flange width (F) to be set and on the tyres. The axle can be set to three different flange widths. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 92 Secure the track rod. Use new self- locking nuts. Tightening torque = 140 Nm 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 93: Hitch

    – If required, bolt down the bracket for the cutterbar trailer brake system tear-off cord to bolt (4). Trailer hitch type 841 ... 36440 Trailer hitch type 810 ... 40022 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 94: Electrical / Electronic Equipment

    The fan / air conditioner fuse is enclosed as a pack joint (cab) on machines with an air conditioner in order to prevent compressor damage. – Install fan / air conditioner fuse. – Put the air conditioner into operation. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 95: Feeder Unit

    – If necessary, put down the front attachment. – Slacken off coupling pins (1) and raise or lower the pins so that the finger bar is parallel with the ground on a flat and level surface. 19525 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 96: Checking The Front Attachment Cylinders

    / adapted. 19598 Number of cutterbar cylinders Dominator 130 / 140 / 150 Cutterbar 3.05 m – 4.57 m Cutterbar 5.18 m – 6.09 m 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 97: Checking The Cutterbar Float Springs

    – Now turn the bolts in or out by 3 revolutions each (5 mm) max., one after the other. Adjusting the bolts (2): Increasing the distance Turn bolts in Reducing the distance Turn bolts out 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 98 5 Prior to initial operation 5.5 Feeder unit 67081 – Check adjustment after changing the front attach- ment and readjust if required. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 99: Grain Delivery

    – Open the grain tank cover and fold it open to the 10456 rear as far as possible. – Install safety device (1) into the rails (2). 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 100 – Fit safety devices before putting the machine into operation. – Check function of safety devices at regu- lar intervals. – Replace worn or damaged safety devices by new ones. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 101: Prior To Each Operation

    – When changing the tyres, adjust the permitted rear axle track width if necessary. – Check tyre pressure according to the front attach- ment and adjust according to the tyre pressure table if required. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 102 – Check the tension of the belt (40). – Check the free run of the belt (40). – Adjust the chopper speed to the crop. – Adjust the chopper equipment to the crop. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 103: Overview Of Controls

    Danger! The front attachment, reel and feeder unit may drop uncontrolled. Death or serious injuries! – Apply safety locks. – Keep a safe distance from the hazard area. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 104: Cab / Operator's Platform

    Grain tank unloading tube swing out / in Combined instrument gauge Hazard warning flasher switch Turn flasher and horn switch Tachometer, gearbox input shaft speed and threshing drum speed switch 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 105 Gear shift gate with control lever for hydraulic control unit (lift hydraulics) Cutterbar height indicator Cutterbar spring pressure indicator Fore and aft reel adjustment Cutterbar reverser On/Off locking rocker switch 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 106: Overview Of Operator's Platform (Dominator 150/140)

    Switches threshing mechanism on and off Engaging / disengaging the grain tank unloading Combined instrument gauge Hazard warning flasher switch Turn flasher and horn switch Steering wheel Steering column locking pedal 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 107: Hydraulic System Control Unit (Dominator 130 Lift Hydraulic System)

    During road travel, the front attachment gate (1 / 2) must be blocked with lock (X). Danger! Unexpected machine movements. Death or serious injuries! – During road travel, the front attachment gate must be blocked. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 108: Multifunction Handle (Dominator 150 / 140)

    Warning light - See function of warning lights 7 and 8 (DOMINATOR 130) Diesel engine speed adjustment rotary switch (CATERPILLAR C6.6, 3056E) Hour meter Combine performance monitor* * = Accessory 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 109: Diesel Engine Speed Adjustment Rotary Switch (Dominator 130, Caterpillar C-6.6, 3056 E)

    7.2.7 Diesel engine speed lever (DOMINATOR 130, Perkins 1006-T6) Function of lever (1): Designation (STOP) without function (hidden) Stopping the diesel engine (DOMINATOR 130) START Slow idle speed FULL Max. no-load speed 29771 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 110: Function Of Warning Lights 7 And 8 (Dominator 130)

    Active electronics fault and engine shutdown due to insufficient oil pressure flashing Warning: Oil pressure, Coolant temperature, Air intake temperature, Fuel temperature, Engine power limiting active 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 111: Switch Console (Dominator 150 / 140)

    - See function of warning lights 15 and 18 (DOMINATOR 150 / 140) not used not used Warning light - See function of warning lights 15 and 18 (DOMINATOR 150 / 140) Hour meter 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 112: Diesel Engine Speed Rotary Switch (Dominator 150 / 140)

    7.2 Cab / Operator's platform 67083 54979 7.2.10 Diesel engine speed rotary switch (DOMINATOR 150 / 140) Function of rotary switch (7): Designation Slow idle speed Max. no-load speed 19418 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 113: Function Of Warning Lights 15 And 18 (Dominator 150 / 140)

    7 Overview of controls 7.2 Cab / Operator's platform 67083 54900 7.2.11 Function of warning lights 15 and 18 (DOMINATOR 150 / 140) Engine operating Red warning light Red warning light Status status (15) (18) Cold start Engine preheating Stop engine...

  • Page 114: Overview Of Steering Column

    – Should a second attempt be necessary to start the engine, then turn the key back to the “0” position and wait for a short moment. – Then repeat the starting procedure. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 115 Feed rake conveyor speed control Clean grain elevator speed-loss monitor Returns elevator speed-loss monitor Intensive separation system speed-loss monitor Display of gearbox input shaft speed or of threshing drum speed 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 116 Failure to do this may lead to injuries or death. Pressing pedal (P) with your foot releases the lock of the steering column for moving it to the desired position. 19369 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 117: Cab Roof Controls

    Adjustable air louvres, can be closed Adjustable air louvres Storage compartment or space for CB radio Storage compartment or space for broadcast radio Pressuriser fans Press here to open cab roof Sun visor 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 118: Cab With Fan

    – Do not weld any components of the refrig- erant circuit and in the immediate vicinity of any parts of the refrigerant circuit. – Danger of poisoning! – Maximum ambient temperature for refrig- erant is 80°C. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 119 The air conditioner can only work properly if the door and the windows are closed. The air conditioner is shut down automatically if a mal- function occurs: The air conditioner was shut down via the high-pres- sure switch. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 120: Cab With Air Conditioner (With Sanden Compressor)

    (8) and (7). The adjustable air 19303 louvres (8) and (7) allow the operator to control the direction of air flow. Air louvres (7) can be closed, if required. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 121: Cab With Fan And Heater

    (7) and (8) allow the operator to control the direction of air flow (heated air and fresh air). Clean the filters in the cab roof at regular intervals – see cleaning the filters. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 122: Control Levers

    (S) located on the right-hand side of the opera- tor's seat goes on and off intermittently. Designation DOMINATOR 130 19428 Buzzer Brake fluid reservoir DOMINATOR 150 / 140 19430 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 123 The shaft speed-loss monitors are switched on and off by means of a switch that is activated by the cutterbar drive control mechanism. 19431 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 124: Attachment Parts / Machine Body

    • Cab with fan, heater, and air conditioner These variants make operation of the combine far more comfortable for the operator even under the most unfavourable weather conditions (dust, heat or cold). 19433 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 125: Sun Roof

    The tool box with on-board tools can be found behind the doors on the left machine side. The tool box is secured by a wire rope. The lock is located at position (1). 28347 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 126: Mounting/Removing Front Attachment

    – Advise everyone to leave the hazard area. Danger! The front attachment, reel and feeder unit may drop uncontrolled. Death or serious injuries! – Apply safety locks. – Keep a safe distance from the hazard area. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 127: Installing The Front Attachment

    Fitting / removing the front attachment chapter. DANGER! The front attachment is not sufficiently secured. Death or serious injury. – Comply precisely with procedure instructions. – Check the safe locking of the front attachment. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 128: Installing Universal Drive Shaft

    – Repeat this procedure on the other side of the machine. 70765 8.2.3 Installing universal drive shaft – Observe the general warnings at the beginning of the Fitting / removing the front attachment chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 129 (1) does not wrap around the universal drive shaft more than 90°. If necessary, cut off excess length of the chain (1) or hang chain (1) so that it is shorter. 24170 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 130: Connecting The Hydraulic System

    (1) to the corresponding female couplings (A/B/C). 19528 70791 8.2.5 Connecting the electric equipment (accessory) – Observe the general warnings at the beginning of the Fitting / removing the front attachment chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 131: Removing The Stands

    Fitting / removing the front attachment chapter. – Loosen spring at (1). – Remove stand (2) from the base frame. – Repeat this process on the other side of the front attachment. 17304 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 132 8 Mounting/removing front attachment 8.2 Installing the front attachment 67084 – Fit stands (1) to the brackets. 24170 24512 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 133: Removing The Front Attachment

    – Suspend the stand (1) at the base frame. – Secure stand (1) to bolt (2) by means of the spring. – Repeat this process on the other side of the front attachment. 17304 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 134: Disconnecting The Hydraulic System

    – Hang in male coupling (1) at (A). 19528 14540 71314 8.3.3 Disconnecting the electric equipment (accessory) – Observe the general warnings at the beginning of the Fitting / removing the front attachment chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 135: Removing Universal Drive Shaft

    – Push in the locking pin (2). Pull universal drive shaft off of drive pin. – Pull out or fold down protective guard (1), depend- ing on the version. DOMINATOR 19527 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 136: Unlocking The Front Attachment

    – Repeat this procedure on the other side of the machine. 71375 8.3.6 Unhitching front attachment – Observe the general warnings at the beginning of the Fitting / removing the front attachment chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 137 – Lower feed rake conveyor of the machine all the way down until coupling pin (1) is positioned out- side of coupling receptacle (2). – Carefully back-up the machine. 19522 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 138: Driving And Transportation

    – Keep a safe distance from the hazard area. 81876 9.1.2 Preparing road travel Danger! Insufficient knowledge about machine functions. Death or serious injury. – Before putting the machine into operation, make yourself familiar with the controls. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 139 – Couple the foot brake pedals (1). 27491 – Disengage parking brake. Danger! Unexpected machine movements. Death or serious injuries! – Do not drive in 3rd gear on gradients of more than 7%. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 140 (X). DOMINATOR 130 28327 – Adjust the diesel engine speed. – Switch on the warning beacon. – If necessary, switch on the drive lights. – Switch off the work lights. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 141: Preparing Fieldwork

    – Use the independent brakes exclusively during work in the field. – If necessary, uncouple the foot brake pedals (1). 19469 – Disengage parking brake. – Shift machine to desired gear. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 142 – Prepare machine for fieldwork. – Adjust the diesel engine speed. – Switch off warning beacon. – If necessary, switch on the drive lights. – Switch on the work lights. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 143: Engine

    – Sit on the operator’s seat. – Adjust the operator’s seat. – Adjust the steering column. – Disengage the front attachment. – Stop the threshing mechanism. – Switch off the grain tank unloading mechanism. 19419 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 144 – Release the ignition key. The ignition key engages and the diesel engine is started. At low outside temperatures, let diesel engine run at min. no-load speed for some minutes after starting. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 145: Stopping The Diesel Engine (Dominator 150 / 140)

    – Before turning off, first let the diesel engine run a short time at slow idling speed. 19459 – Disengage all drives previously engaged. – Turn the ignition key to position 0. The diesel engine stops. 19363 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 146: Adjusting The Diesel Engine Speed (Dominator 130)

    29771 • Road travel • Fieldwork 80069 9.2.5 Starting the diesel engine (DOMINATOR 130) – Sit on the operator’s seat. – Adjust the operator’s seat. – Adjust the steering column. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 147 (1) to the min. no-load speed. CATERPILLAR C6.6, 3056E 19412 Perkins 1006-T6 – Set the diesel engine speed lever (1) to the START position. Perkins 1006-T6 29771 – Sound the horn. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 148: Stopping The Diesel Engine (Dominator 130)

    CATERPILLAR C-6.6, 3056E – Set the diesel engine speed rotary control switch (1) to the min. no-load speed. CATERPILLAR C6.6, 3056E 19412 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 149 – Set the diesel engine speed lever (1) to the START position. Perkins 1006-T6 29771 – Disengage all drives previously engaged. – Turn the ignition key to position 0. The diesel engine stops. 19363 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 150: Chassis

    – Never shift gears while driving on slopes. – Do not let the machine roll. – Stop the machine. – Move the ground speed control lever to neutral. – In addition, depress the foot brake pedals downwards. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 151: Ground Speed Control Lever (Dominator 130)

    See Shifting gears. Reducing the ground speed – Move the ground speed control lever (1) from the neutral position (N) towards (3), thus reducing the 19409 ground speed within the selected gear. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 152: Shifting A Gear (Dominator 130)

    – Never shift gears while driving! – Never shift gears while driving on slopes. – Do not let the machine roll. – Stop the machine. – In addition, depress the foot brake pedals downwards. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 153: Adjusting The Ground Speed Control Lever Actuating Resistance (Dominator 150 / 140)

    – Set shift lever to desired shift position. 80261 9.3.5 Adjusting the ground speed control lever actuating resistance (DOMINATOR 150 / 140) – Observe the general warnings at the beginning of the "Driving and transportation" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 154: Driving Behaviour

    – Adapt your driving style to the load carried. – Be especially careful when working on slopes! 40736 9.3.7 Towing the machine The machine should be towed only if this is absolutely necessary. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 155: Forward Towing

    9.3.9 Reverse towing Caution Towing backwards. Machine damage. – Do not tow machine backwards. – Do not attach any tow rope / tow chain to the drawbar hitch / axle body. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 156: Brake

    The parking brake is released. The symbol in the onboard information system disappears. 80316 9.4.3 Foot brake The foot brake can be used both as a conventional brake and as an independent brake. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 157: Braking / Stopping The Machine (Dominator 150 / 140)

    The machine can also be braked using the foot brake. Danger! Use of the independent brake. Death or serious injuries! – Couple the foot brake pedals. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 158: Braking / Stopping The Machine (Dominator 130)

    – Couple the foot brake pedals. Brakes: – Move the ground speed control lever (1) from the neutral position (N) towards (3), thus reducing the ground speed within the selected gear. 19409 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 159: Parking The Machine

    (1). – Stop the diesel engine. – Remove the ignition key. – When parking the machine on a slope, secure the machine against rolling away with a wheel chock. 19428 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 160: Steering

    Move the steering column to the desired position 19369 by hand. – Press lever (1) with the foot at the rear, thus arresting the steering column. The steering column is now arrested in the desired position. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 161: Hitch

    – Never remain standing between the trailer hitch and the trailer. – Observe the regulations of the German employers' liability insurance association or its equivalent. Trailer hitch type 841 ... 36440 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 162 Trailer hitch type 810 ... 20717 trailer hitch. – Clean the trailer hitch with a suitable agent. – Back up tractor slowly until the hitch eye makes contact with the trailer hitch. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 163 – Push the hand lever (1) up until it clicks. – Clean the trailer drawbar with a suitable agent. – Slowly back up the vehicle until the hitch eye has tripped the trailer hitch lock. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 164: Unhitching The Trailer

    (5) into the trailer hitch up to the stop (6). Trailer hitch type AK 64/1 B ... 30204 – Release the pawl (4) and ensure that lock (7) has engaged at the trailer hitch. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 165 (type 841). Danger! Non-locking of trailer hitch. The locking pin socket fills up with dirt. Malfunction of locking. – Lock trailer hitch when not in use. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 166: Cab / Operator's Platform

    In the top position, the seat can be removed upwards. - Release lever (1). A click is heard and lever (1) engages. 19421 19422 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 167: Adjusting The Driver's Seat With Mechanical Suspension (Standard Version)

    – Never adjust the driver's seat while driving! Warning! Driver's seat misadjusted. Health damage. – Before putting the machine into operation, adapt the driver's seat ergonomically and individually to the driver. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 168 – Adjust the back rest inclination. - Turn the turn lock (1) in the desired direction until the desired inclination has been reached. The back rest cannot be adjusted any more. 28340 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 169: Adjusting The Mechanically Suspended Driver's Seat (Option)

    19424 – Adjust the driver's weight. - Fold out lever (1) and turn it in the desired direction. - Fold in lever (1). 19424 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 170 – Adjusting the back rest inclination - Lift lever (1). - Adjust back rest as desired. - Release lever (1). The back rest cannot be adjusted any more. 19424 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 171: Various Components / Machine Body

    – Fold ladder down before climbing up and down. 27339 79705 9.8.2 Adjusting the rear ladder – Observe the general warnings at the beginning of the "Driving and transportation" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 172 – Pull the ladder down before climbing up. - Pull ladder out of the brackets (2). - Pull ladder downwards until ladder engages safety at position (1). - Lock ladder in brackets (2). 19426 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 173: Fieldwork Settings

    Danger! The front attachment, reel and feeder unit may drop uncontrolled. Death or serious injuries! – Apply safety locks. – Keep a safe distance from the hazard area. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 174: Feeder Unit

    – If required, turn scraper profile (1) at the feeder unit and bolt down hand-tight. – Fit front attachment to the machine. – Adjust scraper profile (1) according to the front attachment scraper profile and bolt it down. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 175: Adjusting The Height Of The Feeder Chain

    – Twist supports by 90° until the dowel pin fits the bore. Designation Grain Maize The supports in the feed rake conveyor have adjusted the feeder chain height. 23851 – Bolt down bolts (1). 19596 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 176: Adjusting The Front Attachment Drop Rate (Dominator 150)

    5 to 6 seconds. Drop rate Faster turn in the knurled screw Slower turn out the knurled screw 25066 25065 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 177: Threshing Mechanism

    10.3.2 Adjusting the basic concave adjustment – Observe the general warnings at the beginning of the "Fieldwork settings" chapter. The clearance of the threshing concave on the right and left sides must be parallel. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 178 - Loosen the nuts of the turnbuckles (1). - Adjust the turnbuckles until you obtain the threshing concave basic adjustment. - Check the distances (A and B) again. - Lock the nuts of the turnbuckles (1). 19607 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 179 20 * 33 * 17 * ** = Basic concave adjustment, ** = Continuous concave, *** = Multicrop concave with 3 concave segments A = Concave entrance, B = Concave exit 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 180: Separation

    (4). The sensors react more / less sensitively, depending on the pre-set grain size. Sensitivity of sensors Position Grain sizes for lightweight grains for medium-weight grains for heavy grains 19650 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 181: Cleaning Unit

    (4). 19648 The sensitivity setting of the display is carried out while fieldwork is in progress. See Adjusting the cleaning performance monitor display. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 182: Removing The Sieves

    – Remove bolts (2). – Pull out the upper sieve to the rear. 19638 Removing the lower sieves (machines with performance monitor) – Unscrew bolts (1). – Fold sensor (2) down. 19638 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 183: Installing The Sieves

    – Clean guide rails. – Install lower sieve. – Install linkage and secure with cotter pin (5). – Arrest lower sieves with clamps and bolt down hand-tight with bolts (6). 19641 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 184 Tightening torque = 48.5 Nm 19638 When installation of sieves is complete, the straw chopper must be moved back to its initial position at the front (putting the straw chopper out of operation). 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 185: Crop Receptacle / Straw Receptacle

    The straw chopper is in the front position (putting the straw chopper out of operation). – Unscrew the turn lock (13). 28748 – Unhinge connecting rod at position (A). – Swivel standard spreader (9) downwards. 28802 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 186: Installing The Straw Guide Plate (Straw Chopper With Standard Spreader)

    28806 (1 persons are required) – Swivel straw guide plate (15) upwards. – Fit connecting rod at position (A). – Swivel the standard spreader (9) to the desired position. 28802 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 187: Unscrewing The Free-Swinging Knives

    – Consequential damage! – Operate the cutting cylinder only with the complete number of knives. – Unscrew the free-swinging knives. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 188: Bolting Down The Free-Swinging Knives

    Bushing D 30 x 10 Free-swinging knife (grain) Bushing D 30 x 11 Self-locking nut ISO 7042 VM 10 -10 Mounting plate Machine centre – Install the straw guide plate. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 189: Straw Chopper Sieves Installation Position

    – Unscrew guard (19) and remove belt. 28748 – Unhinge connecting rod at position (A). – Disconnect speed monitoring cable at position (B). – Fold up panel (20) and support it. 28800 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 190 – Check belt (5). The belt (5) must make contact with all pulleys, jockey pulleys and guide rollers. Provide contact of belt if required. – Close the right side cover. 28748 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 191: Grain Delivery

    – Unscrew grain tank fill indicator. – Set height of grain tank fill indicator. – Bolt on grain tank fill indicator. Designation 70 % grain tank filling 100 % grain tank filling 19662 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 192 10 Fieldwork settings 10.7 Grain delivery 67086 – Fit guard (1). – Remove additional safety precautions. 30205 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 193: Fieldwork

    Danger! The front attachment, reel and feeder unit may drop uncontrolled. Death or serious injuries! – Apply safety locks. – Keep a safe distance from the hazard area. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 194: Description And Function

    The stone trap collects solid objects brought up by the feed rake, thus preventing damage to the threshing parts. Designation Grain Grain, chaff, broken straw Grain Returns Straw Chaff 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 195: Threshing Mechanism

    When combining grain which is unusually hard to dis- awn or in which it is hard to separate the seeds from the heads or husks, additional disawning plates can be installed in the concave. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 196: Considerations Before Combining

    220-5 rpm. – Correct cleaning of the air filter as well as clean fuel and regular oil changes are essential for high performance and long life of the engine. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 197: Front Attachment

    – Tension the chain. To this end, pull chain down at position (A) as far as possible and fit the spring clip (1) into the rear hole. The spring-loaded cylinder now keeps the chain under constant tension. 28386 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 198: Adjusting The Reel Horizontally (Hydraulically)

    19554 82058 11.4.3 Adjusting the reel circumferential speed The reel circumferential speed must be adapted to the ground speed. The reel speed should be slightly higher than the ground speed. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 199 – Increasing the reel circumferential speed = Turn crank in + direction – Reducing the reel circumferential speed = Turn crank in – direction Vary the reel circumferential speed only when the cut- terbar is operating. 19530 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 200: Feeder Unit

    – The further the pointer on gauge (B) falls towards "0“, the higher the front attach- ment ground pressure. – Do not set the ground pressure unneces- sarily high. Raise the front attachment if required. 19601 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 201: Reading The Cutting Height

    – Disengage the front attachment. Caution! Machine components may run on although the drive has been shut down. Machine damage. – Wait for all machine components to come to complete stop. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 202 – If necessary, lower the reel if grain wraps around the intake auger during reversing. – If necessary, raise the reel if the reel tines mesh into the intake auger when the reel is tilted back. DOMINATOR 130 19554 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 203: Switching On The Front Attachment

    The lever (1) remains in the bottom position after engaging. Warning! Incorrect diesel engine speed when driving in the crop. Machine damage. – Set the diesel engine to max. no-load speed before driving into the crop. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 204: Disengaging The Front Attachment

    Machine components may run on although the drive has been shut down. Death or serious injury. 19605 – Never touch any machine parts that are running on. – Wait until all machine parts have stopped moving. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 205: Threshing Mechanism

    (1) remains in the bottom position after engaging. Warning! Incorrect diesel engine speed when driving in the crop. Machine damage. – Set the diesel engine to max. no-load speed before driving into the crop. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 206: Disengaging The Threshing Mechanism

    – Lever (H) down = increases concave distance. – Lever (H) up = decreases concave distance. 19428 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 207: Installing / Removing The Disawner Bars (Accessory)

    A = Concave entrance, B = Concave exit 82336 11.6.4 Installing / removing the disawner bars (accessory) – Observe the general warnings at the beginning of the "Fieldwork" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 208 - Bolt on the left-ribbed disawner bar (L) between the 1st and 2nd concave bars. - Bolt on the right-ribbed disawner bar (R) between the 2nd and 3rd concave bars. 16380 – Install the threshing concave segments. 16379 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 209: Unslugging The Threshing Drum

    Machine damage. – Make sure that the chisel does not dam- age the lubricating line and the speed sensor. – Set the threshing concave downwards. – Remove safety device. 19612 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 210: Adjusting The Threshing Drum Speed

    The speed must be set depending on the crop. See threshing chart. 19610 – Engage the threshing mechanism. – Set the diesel engine speed to fast idling speed. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 211 Adjusting the threshing drum speed DOMINATOR 150 / 140 – Actuate switch (3) and reduce or increase thresh- ing drum speed. Blocking the speed adjustment – Lock switch (4). DOMINATOR 150 / 140 19415 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 212: Threshing Drum Two-Step Variable-Speed Drive (Chain Drive)

    (1) on the impeller shaft. Sprocket Teeth Speed of 300 rpm 19611 430 rpm 550 rpm Additional stage: 265 rpm For a speed of 550 rpm, the standard length of chain is 72 rollers. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 213 (4) with the clamping bolt (3) slackened off. After ten- sioning, tighten clamping bolt again. Whatever drive is used, drum speed read out is pro- vided by the tachometer in the combined instrument gauge on the operator's platform. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 214: Separation

    (1) is actuated and the horn on the opera- tor's platform produces a horn tone. WARNING: Straw plug. Machine damage. – Immediately stop the machine and remove straw plug. 19625 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 215: Adjusting The Separation Performance Monitor Display

    If the loss rate, indicated by the fourth or fifth light in the meters, is acceptable, the capacity of the combine is fully utilised at this forward speed. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 216 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 217: Installing / Removing The Straw Walker Fishback

    – Install risers at a safe distance from the agitator tines of the intensive separation system. – Check free wheel. – Observe the general warnings at the beginning of the "Fieldwork" chapter. 28793 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 218 The risers can also be installed in combination to achieve an even better tumbling action. If required, parallel risers (3) can also be fitted to the follow-up steps of the straw walkers. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 219: Cleaning Unit

    Basic rule: Set the fan speed as high as possible, depending on crop conditions. 82936 11.8.2 Adjusting the wind board – Observe the general warnings at the beginning of the "Fieldwork" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 220: Adjusting The Sieves Manually

    Move wind boards to the desired positions. Screw in bolt (2). 19637 82949 11.8.3 Adjusting the sieves manually – Observe the general warnings at the beginning of the "Fieldwork" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 221: Adjusting The Cleaning Performance Monitor Display

    (3). The sensitivity of the cleaning system display can be adjusted depending on the properties of the crop (grain moisture, grain shape, green part). 19648 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 222 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 223: Crop Receptacle / Straw Receptacle

    – Check belt (5). The belt (5) must make contact with all pulleys, jockey pulleys and guide rollers. Provide contact of belt if required. – Unhinge belt (1) from bracket of jockey pulley (4). 19672 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 224 – Loosen turn lock (13) on the right side. – Move the straw chopper to the rear, using crank (14). At the same time the straw guide plate (15) is swung backwards. 19664 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 225: Putting The Straw Chopper Out Of Operation (Swinging The Standard Spreader To Swathing Position)

    (swinging the standard spreader to chopping position). 83284 11.9.2 Putting the straw chopper out of operation (swinging the standard spreader to swathing position) – Observe the general warnings at the beginning of the "Fieldwork" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 226 (14). At the same time the straw guide plate (15) is swung forward. – Bolt down turn locks (12) on both sides. – Tighten the turn lock (13). 28748 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 227 (4). 19672 – Check belt (5). The belt (5) must make contact with all pulleys, jockey pulleys and guide rollers. Provide contact of belt if required. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 228: Swinging The Standard Distributor Into The Transport Trolley Transport Position

    Swing the standard distributor (9) all the way up until the sheet metal plates on both sides snap into the notches (A). – Bolt down toggles (7) on both sides. The transport trolley can now be hitched. 19696 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 229: Adjusting The Stationary Knives (Standard Straw Chopper)

    – Unlock and pull out spring clip of rod (3). – Pull out rod (3). – Remove the stationary knives. – Push in rod (3) and secure with spring clips. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 230 Note! Uneconomic use of machine. Increased fuel consumption. – Turn around or replace worn stationary knives. – Remove the stationary knives. – Install stationary knives (new, sharp). 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 231: Grain Delivery

    – Ensure that when driving on public roads and lanes, the grain tank cover is com- pletely closed. – Stop the machine. – Apply parking brake. – Disengage the front attachment. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 232: Swinging The Grain Tank Unloading Tube Out / In (Dominator 150 / 140)

    – Make sure that the grain tank unloading tube is swivelled in all the way in and rests on the support (1) when travelling on public roads and paths. 28639 – Prepare fieldwork. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 233: Swinging The Grain Tank Unloading Tube Out / In (Dominator 130)

    – Make sure that the grain tank unloading tube is swivelled in all the way in and rests on the support (1) when travelling on public roads and paths. 28639 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 234: Engaging / Disengaging The Grain Tank Unloading

    – Switch off grain tank unloading and wait for components to stand still, then swing the grain tank unloading tube. – Swing the grain tank unloading tube to the maximum, then engage grain tank unloading. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 235 - Push lever (1) slowly in direction (B) up to the stop. The grain tank unloading is engaged softly. The lever (1) remains in the bottom position after engaging. DOMINATOR 150 / 140 19655 DOMINATOR 130 19419 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 236: Removing / Installing The Grain Tank Auger Cover Plates

    – Areas originally without railings must be protected by additional railings. – Open the grain tank cover and fold it open to the rear as far as possible. – Remove guard (1). 30205 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 237: Clean Machine For Bulk Seed Change

    – Observe the general warnings at the beginning of the "Fieldwork" chapter. – Clean the stone trap. – Clean the auger troughs. – Clean the grain tank. – Adjust the machine settings to the crop. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 238: Sieve Charts / Threshing Charts

    Lower flat sieve, Ø 16 mm Sunflowers / maize / broad beans / peas Lower flat sieve, Ø 18 mm Broad beans / maize Lower flat sieve, Ø 20 mm Broad beans / maize 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 239: Threshing Table

    1200 Common meadow 1100 grass Ryegrass 1000 Meadow fescue 1000 Cocksfoot 1000 - = use is not possible This information represents guideline values and may deviate in differing harvesting conditions. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 240 3270 Common meadow 3270 grass Ryegrass 3270 Meadow fescue 3270 Cocksfoot 3270 - = use is not possible This information represents guideline values and may deviate in differing harvesting conditions. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 241 Linseed Clover / Lucerne Common meadow grass Ryegrass Meadow fescue Cocksfoot - = use is not possible This information represents guideline values and may deviate in differing har- vesting conditions. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 242: Disawning

    Disawner bars The entire Lower husk removed separating removal and area is used, disawning level higher residual grain separation 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 243: Faults And Remedies

    Danger! The front attachment, reel and feeder unit may drop uncontrolled. Death or serious injuries! – Apply safety locks. – Keep a safe distance from the hazard area. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 244: Cab / Operator's Platform

    – Do not weld any components of the refrig- erant circuit and or in the immediate vicinity of any parts of the refrigerant circuit. – Maximum ambient temperature for refrig- erant is 80 °C. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 245 …: The filter receiver drier is saturated when the orange ball has lost its colour. - Have filter-receiver replaced. (Discharge and then recharge air conditioner.) 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 246 • Water drain hoses clogged or not properly routed. Water dripping from air louvres. - Check water drain hoses for free passage. If necessary, blow out hoses with com- pressed air. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 247: Front Attachment

    • Slightly raise the reel. • Incline the reel tine a little more to the front. • Adjust reel speed to match ground speed. • Cover up reel tine tubes. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 248 • Bleed hydraulic cylinders. Too many stones being picked up • Reduce number of crop lifters. • Do not cut unnecessarily low (lodged crops should be lifted with crop lifters). 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 249: Feeder Unit

    Feeder chains stop too easily • Adjust the front attachment drive belt. • Have the feeder chain slip clutch adjusted. Uneven material flow • Adjust feed rake chains to correct tension. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 250: Threshing Mechanism

    • Install disawner bars. • Wait for crop to ripen for some more time. • Correct basic adjustment of concave. • Check concave and threshing drum bars for wear and damage. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 251: Threshing Drum

    – After this, rebalance the threshing drum. The rasp bars must fit tightly into the drum plates. – Threshing drum repairs should only be carried out by trained expert personnel. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 252: Separation

    The separation performance monitor displays insuf- • Clean sensor trough. ficient performance. • Check tight seat of sensor trough and sensor. Loose sensor trough - Tighten sensor trough. Loose sensor - Replace sensor trough. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 253: Cleaning Unit

    Loose sensor trough - Tighten sensor trough. Loose sensor - Replace sensor trough. Slip reported from different units • If necessary, check tight seat and correct position of cam wheels. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 254: Crop Receptacle / Straw Receptacle

    • Stationary knives are dull. Replace stationary knives. Chopper standstill / slip fault message when • Readjust the straw guide plate limit switch. discharging straw. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 255: Grain Delivery

    • When working in crops with hanging ears, install a crop lifter on every second finger. • Adjust dividers to avoid build-up of material. • Adjust intake auger height to suit crop conditions. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 256 • Adjust frogmouth sieve gaps wider open and increase air blast. • Avoid excessive returns. • Clean upper sieve, lower sieve and preparation floor. • Reduce ground travel speed. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 257: Installing The Grain Tank Unloading Shear Bolt

    Hex. bolt ISO 4014 M8 x 35 -8.8 Self-locking nut ISO 7042 VM 8 -8 – Eliminate cause of the problem. – If required install new shear bolt. 19661 Tightening torque = 24.5 Nm 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 258: Maintenance

    Danger! The front attachment, reel and feeder unit may drop uncontrolled. Death or serious injuries! – Apply safety locks. – Keep a safe distance from the hazard area. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 259: General Information

    – Observe the specified oil change intervals and oil grades in the hydraulic system and in the gearboxes. – Use only the specified grease for greasing the machine. – Before greasing, remove the dirt on the grease nipple. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 260: Cleanliness Of Lubricants

    – Use suitable and clean tools. – Use permitted lubricants. – Lubricants must be free of pollution. Warning! Operation of the machine with contaminated lubricants. Machine damage. – Make sure surroundings are clean. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 261: Brakes

    – Never stand in the vicinity of the tyre while it is being inflated. Always stand clear! – Regularly check the pressure of the tyres. – The specified tyre pressure must be respected. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 262: 10Hydraulic System

    Danger! Pre-loaded energy accumulators (spring, accumulator, hydraulic cylinder). Death or serious injury. – Only have authorised and qualified work- shops carry out work on energy accumulators. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 263: Electrical System

    – Remove the covers (vent caps) when recharging the battery to prevent the accumulation of highly explosive gases. – Be careful when handling battery acids, they are caustic. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 264: 12Air Conditioner

    – Do not weld any components of the refrig- erant circuit and or in the immediate vicinity of any parts of the refrigerant circuit. – Maximum ambient temperature for refrig- erant is 80 °C. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 265: 13Protective Guards

    Death or serious injury. – Spare parts must at least comply with the technical standards required by the man- ufacturer of the implement! – We recommend using genuine CLAAS spare parts. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 266: 15Unbalance

    – Wait for machine parts which run on have come to a complete halt. – Secure machine by wheel chocks. – Ensure that the machine cannot be started by any third persons. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 267: 18Cleaning Of Surfaces With Decals Applied

    – Clean the exterior of all bearings thoroughly of grease and dust. – Preserve the machine including the grease points to be greased at annual intervals after the harvest by pressing in brand-name grease. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 268: 20Coolant

    The coolant consists of 50% corrosion / frost protection and 50% water. This ensures frost protection down to approx. -37 °C. Also refer to the specifications of the engine manufacturer. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 269: Maintenance Schedule

    Every 5 years Coolant mixing ratio check • • Rotary chaff screen clean • • Cooling unit clean • • Coolant hoses change • Diesel engine air filter clean • • 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 270 Foot brake adjust (only through authorised • workshop) Brake pads check • • • Output / drives Belts (all) adjust • • • Chains (all) adjust • • • 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 271 Performance monitor sensors clean • • Cleaning unit Performance monitor sensors clean • • clean • Setting the fan speed gauge • Stepped preparation floors clean • Sieves clean • 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 272 Grain tank clean • Grain tank unloading tube support adjust • transport position Attachment parts / machine components Fire extinguisher check • • Miscellaneous Maintenance operations on front Note • attachments 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 273: Lubricants Chart

    CAT EC-1. ** Mixing with commercially available coolant is not allowed. ** Use only specified coolant for refilling. * Check the necessary filling quantity by checking the oil level! 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 274 /s (DIN 51 562) Viscosity index 154 (DIN ISO 2909) Pourpoint -36 °C (DIN ISO 3016) The oil must have detergent properties! * Check the necessary filling quantity by checking the oil level! 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 275 0.01 litres in case of replacement Refrigerant loss 0.02 litres suddenly drained system 0.04 litres Refrigerant 1390 g R 134a * Check the necessary filling quantity by checking the oil level! 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 276 Lubrication points See lubri- CLAAS special chain oil Spray can cation 500 ml chart Part no.: 00 0177 353 3 * Check the necessary filling quantity by checking the oil level! 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 277: Engine

    13.5.2 Overview of engine CATERPILLAR 3056 E Designation Alternator Oil filter Engine number Starter Charge air blower Turbocharger – Observe the information provided in the operator's 29342 manual of the engine manufacturer. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 278: Overview Of Engine Perkins 1006-6T

    13.5.4 Overview of cooling units Danger! Insufficient specialist knowledge for repair and maintenance work. Death or serious injury. – Only have authorised and qualified work- shops carry out work on this component. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 279: Cleaning The Diesel Engine Surroundings

    – Reduce the fuel tank capacity to a minimum. – Park the machine on level ground. – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 280 – Unscrew bolt (1, size 10). – Collect fuel in a suitable container. – Screw in bolt (1, size 10). Tightening torque = 4 Nm 29515 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 281: Fill Up The Machine's Fuel Tank

    Damage to diesel engine. – Use only permitted fuels. – Do not use polluted fuels. – Ensure that no water will get into the fuel tank when filling up. 14571 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 282: Cleaning The Fuel Tank Filler Screen

    When work is complete, open the shut-off tap (1) again. – Close shut-off tap (1). - To do this, turn in the shut-off tap (1). – Open shut-off tap (1). 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 283: 10Bleed Fuel System

    13.5.11 Cleaning the fuel sediment bowl filter The fuel sediment bowl cleans the fuel before it enters the fuel feed pump. – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 284: 12Draining Condensation At The Fuel Prefilter (Standard Equipment)

    – As soon as the drain plug (2) has been loosened, drain the accumulated amount of water and col- lect it in a container. – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 285: 13Changing The Fuel Prefilter (Standard Equipment)

    – Lubricants and fuels must be collected and stored in suitable containers and dis- posed of in a way that is harmless to the environment and in accordance with existing anti-pollution regulations. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 286: 14Draining Condensation At The Fuel Prefilter (Additional Equipment)

    13.5.14 Draining condensation at the fuel pre- filter (additional equipment) The fuel pre-filter is accessible after opening the right- hand side panel. Any water contained in the fuel is collected in the sight glass. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 287: 15Changing The Fuel Pre-Filter (Accessory)

    – Lubricants and fuels must be collected and stored in suitable containers and dis- posed of in a way that is harmless to the environment and in accordance with existing anti-pollution regulations. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 288 Press straps of the filter into the housing! – Tighten toggle bolt (11). – Replace damaged seal (3). – Tighten bolt (2). – Open the shut-off tap of the fuel system. – Bleed fuel system. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 289: 16Changing The Fuel Filter Caterpillar C-6.6 / 3056 E

    – Bleed fuel system. – Start the diesel engine. Let diesel engine run at min. no-load speed for about 10 seconds. – Check tightness of fuel filter. CATERPILLAR 3056 E 29340 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 290: 17Changing The Fuel Filter Perkins 1006-6T

    – Apply some oil to the new seal and screw new filter (1) with sight glass (4) to the filter head at right angles and centred. – Open the shut-off tap of the fuel system. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 291: 18Checking The Diesel Engine Oil Level

    Machine operation with unpermitted or pol- luted lubricants. Machine damage. – Ensure a clean environment. – Use suitable and clean tools. – Use permitted lubricants. – Lubricants must be free of pollution. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 292 SAFE mark (minimum) on the oil dipstick. – If necessary, top up oil at (2). CATERPILLAR C-6.6 27295 CATERPILLAR 3056 E 29340 PERKINS 1006-6T 29344 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 293: 19Changing The Diesel Engine Oil / Oil Filter

    – Unscrew the cover (1). PERKINS 1006-6T 29344 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 294 29543 – Unscrew engine oil drain plug (1). – Collect the used oil in a sufficiently large container. – Tighten drain plug (11). right machine side 23415 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 295: 20Adjusting The Diesel Engine Valves

    – Observe the general warnings at the beginning of the "Maintenance" chapter. – Let diesel engine cool down. – Ensure that the drain cock of the cooling system is closed. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 296: 22Checking The Coolant Mixing Ratio

    – Do not use more than 55 % anti-corrosion agent/antifreeze when mixing. This reduces both frost protection and heat dissipation. – Operation without anti-corrosion agent/antifreeze is not permitted. Coolant mixing ratio: 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 297: 23Changing The Radiator Coolant

    Contact with hot liquids or machine parts. Danger of burns – Wear suitable protective clothing. – Let liquids or machine parts cool down. – Comply with instructions. – Let diesel engine cool down. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 298 Any possible vacuum in the system is relieved, the remaining coolant flows out of the drain tap. – Bolt on cover (1). – Close drain tap. from serial no..29602 up to serial no..23479 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 299: 25Topping Up Coolant

    – Observe the general warnings at the beginning of the "Maintenance" chapter. – Stop the diesel engine. – Let diesel engine cool down. – Check coolant level one more time and top up if required. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 300: 26Cleaning The Rotary Chaff Screen

    – Close the rotary chaff screen (1). – Secure the rotary chaff screen (1) with lock. 23477 38808 13.5.28 Changing the coolant hoses – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 301: 29Cleaning / Changing The Diesel Engine Air Cleaner With Plastic Housing

    The permanent suction effect sucks the major part of the polluted air out of the housing. The polluted air is discharged through the exhaust. – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 302 – The use of genuine CLAAS spare parts and lubricants is recommended. 23488 – Check cartridge (1) for external and internal dam- age and replace if necessary. – Insert cartridge (1) into the housing. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 303: 30Changing The Diesel Engine Air Cleaner Safety Cartridge With Plastic Housing

    85762 13.5.31 Cleaning the air filter intake screen When the engine is running, air is suctioned through the sieve. Coarse dust and dirt particles remain out- side at the sieve. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 304: 32Changing The Air Intake Hoses

    Tightening torque for hose clamp with worm thread = 7 Nm 38817 13.5.33 Retightening the air intake tube clamps – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 305 – Replace damaged or porous hoses. Tightening torque for hose clamp with round pin, with spring = 10 Nm Tightening torque for hose clamp with worm thread = 7 Nm 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 306: Chassis

    – Keep oil and grease away from tyres. – Check tyres for damage regularly on the inside as well. – Do not clean tyres by applying a steam cleaner directly. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 307: Checking The Tightening Torque Of Wheel Nuts / Wheel Bolts

    Designation of thread, type of Wrench size Tightening fastening torque Drive axle M22 x 1.5 - 8.8, nut with spring 520 Nm washer C 18.5 DIN 74361 (Limes type conical spring washer) 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 308: Cleaning The Surroundings Of The Drive Axle Manual Gearbox

    13.6.4 Checking the final drive oil level DOMINATOR 150 / 140 – Park the machine on level ground. – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 309: Draining The Final Drive Oil Dominator 150 / 140

    – Lubricants and fuels must be collected and stored in suitable containers and dis- posed of in a way that is harmless to the environment and in accordance with existing anti-pollution regulations. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 310: Topping Up The Final Drive Oil Dominator 150 / 140

    Machine operation with unpermitted or pol- luted lubricants. Machine damage. – Ensure a clean environment. – Use suitable and clean tools. – Use permitted lubricants. – Lubricants must be free of pollution. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 311: Checking The Final Drive Oil Level Dominator 130

    Right side 23393 86786 13.6.8 Draining the final drive oil DOMINATOR 130 – Park the machine on level ground. – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 312: Topping Up The Final Drive Oil Dominator 130

    – Lubricants and fuels must be collected and stored in suitable containers and dis- posed of in a way that is harmless to the environment and in accordance with existing anti-pollution regulations. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 313: 10Checking The Drive Axle Gearbox Oil Level

    Machine operation with unpermitted or pol- luted lubricants. Machine damage. – Ensure a clean environment. – Use suitable and clean tools. – Use permitted lubricants. – Lubricants must be free of pollution. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 314: Draining The Oil From The Drive Axle Gearbox

    – Remove screw (1). – Collect the used oil in a sufficiently large container. – Clean screw (1). – Turn in screw (1). 23389 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 315: 12Topping Up Oil In The Drive Axle Gearbox

    – Unscrew bolt (1). – Fill in new oil. – Check oil level , top up if necessary. – Remove dirt from bolt (1). – Screw in bolt (1) with sealant. 23390 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 316: 13Adjusting The Chassis Clutch Dominator 130

    – Ensure that the overall clutch path is (B = 20±1 mm). 86746 13.6.14 Adjusting the short-circuit valve DOMINATOR 130 – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 317 67089 – With the clutch pedal in rest position, adjust link- age (2) so that the actuating lever of short-circuit valve (1) is retracted by 3 to 5 mm. 23387 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 318: Brake

    – Have the brake system inspected by an authorised workshop. 23388 86791 13.7.2 Adjusting the parking brake – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 319: Adjusting The Foot Brake

    – Check the braking effect. – Check the brake pads at regular intervals. – Replace the brake pads. 19470 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 320: Drive Belts / Drive Chains

    Machine components may run on although the drive has been shut down. Death or serious injury. – Never touch any machine parts that are running on. – Wait until all machine parts have stopped moving. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 321: Drive Diagram, Left Side Dominator 150 / 140 / 130

    13 Maintenance 13.8 Drive belts / drive chains 67089 87740 13.8.2 Drive diagram, left side DOMINATOR 150 / 140 / 130 30063 Designation Front attachment drive, stage 2 Front attachment drive, stage 1 Threshing mechanism drive Grain tank unloading drive 1st step...

  • Page 322: Drive Diagram, Right Side Dominator 150 / 140 / 130

    13 Maintenance 13.8 Drive belts / drive chains 67089 87248 13.8.3 Drive diagram, right side DOMINATOR 150 / 140 / 130 29863 Designation Straw chopper drive 2nd step Straw chopper drive 1st step Threshing drum variable speed drive Threshing drum chain drive...

  • Page 323: Adjusting Belt (R1)

    – Turn nuts (2) and (3) until the belt is tensioned. – Lock nuts (2) and (3). – Tighten nut (1). Tightening torque = 130 Nm – Carry out a test run and check belt tension. 23846 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 324: Adjusting Belt (R2)

    Dimension (Y) = 5 - 7mm, dimension (Z) = 4 mm - Tighten all the bolts. – Carry out a test run and check belt tension. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 325: Adjusting Belt (R3)

    (Y) = 5 mm results on the entire circumference between belt back and belt guide. - Tighten all the bolts. – Carry out a test run and check belt tension. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 326: Adjusting Belt (R4)

    Dimension (W) = 5 mm on the entire circum- ference, dimension (Z) = 7 mm - Tighten all the bolts. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 327: Adjusting Belt (R5)

    – Jam spring guide tube (1) and nut (2). Ensure that tube (6) makes contact with bracket (4) without play. – Carry out a test run and check belt tension. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 328: Adjusting Belt (R8)

    – Lock nuts (2) and (3). – Tighten the clamping screw of the jockey pulley (1). - Tightening torque = 130 Nm – Carry out a test run and check belt tension. 23842 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 329: 10Adjusting Belt (R9)

    – Lock nuts (2) and (3). – Tighten the clamping screw of the jockey pulley (1). - Tightening torque = 40 Nm – Carry out a test run and check belt tension. 23841 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 330: Adjusting Belt (R10)

    – Lock nuts (2) and (3). – Tighten the clamping screw of the jockey pulley (1). - Tightening torque = 40 Nm – Carry out a test run and check belt tension. 23843 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 331: 12Removing Belt (R7)

    (2) is fully spread. – Remove belt (R7). 23404 23405 87616 13.8.13 Installing belt (R7) – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 332 – Bolt down bracket (3) with bolts (4). – Check / adjust the fan speed display. – Let the variable-speed drive run up and down through its entire range several times, then check belt tension. 23404 23405 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 333: 14Adjusting Belt (R12)

    – Turn nuts (2) and (3) until belt (R12) is tensioned. – Lock nuts (2) and (3). – Carry out a test run and check belt tension. Sanden compressor 19303 York compressor 19297 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 334: 15Adjusting Belt (R13)

    – Adjust the guide so that there is 13 mm clearance (Y) between the back of the belt and the belt guide along its full length. – Carry out a test run and check belt tension. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 335: 16Removing Belt (R14)

    – Screw special tool (4) on the variable-speed pulley. – Push the lever on the hydraulic control unit to the "slow" position and at the same time push the hydraulically operated variable-speed pulley halves apart. 23403 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 336: 17Installing Belt (R14)

    – Keep limbs out of the hazard area. – Use suitable tools. – Adjust belt (R14). – Install belt (R14). – Remove special tool (4). – Install belt (R13). – Screw on hydraulic hose (5). 23403 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 337: 18Adjusting Belt (R14)

    – Keep limbs out of the hazard area. – Use suitable tools. Setting the ground drive variable-speed pulleys: – The distance (X) between the variable-speed pul- leys must be 280 mm. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 338: 19Removing Belt (R42)

    – Screw in bolts (2) until the variable-speed drive is completely spread apart. – Remove belt (R42). 23400 87276 13.8.20 Installing belt (R42) – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 339 – Fit the guards. – Let the variable-speed drive run up and down through its entire range several times, then check belt tension. – Adjust the threshing drum speed. 23399 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 340: Hydraulic System

    DOMINATOR 150 / 140 – Park the machine on level ground. – Lower the feeder as far as possible. – Lower the reel all the way. – Swing in unloading auger tube. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 341 CATERPILLAR 3056 E right machine side left machine side, inside • CATERPILLAR 3056 E right machine side on the steering cylinder • PERKINS 1006-6T right machine side on the steering cylinder • 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 342 – Unscrew fresh air filter element (1). – Fill new hydraulic oil into the oil tank. 23377 Use a filling screen! Fill in hydraulic oil slowly! – Correct oil level. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 343 "Maintenance" chapter. Warning! Contact with hot liquids or machine parts. Danger of burns – Wear suitable protective clothing. – Let liquids or machine parts cool down. – Comply with instructions. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 344 – Turn the steering wheel in the appropriate direc- tion until all the oil has been pumped out of the system. – Connect the hydraulic hose to the steering cylin- der again. 23383 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 345 – Screw on hydraulic lines at position (A). Hydraulic oil filter, exploded view Screen insert Paper filter cartridge / screen insert Filter head Felt ring Felt ring 23382 Washer 13 Compression spring Lock washer Gasket 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 346 - Check the hydraulic tank oil level and top up if necessary. - Repeat this process until topping up is not nec- essary any more following a check. – Screw on a new fresh air filter element (1). 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 347: Electric System / Electronics

    The electrolyte level must be about 10 mm above the inside plates. – Top up distilled water if required. – Fit all covers (1). – Fit safety device. – Close the cover. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 348: Cab / Operator's Platform

    – Remove the recirculation air grille (1). – Clean filter surface by vacuum cleaning, knocking on it or blowing off with compressed air. – Replace damaged filters. – Install recirculation air grille (1). 29686 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 349: Cleaning The Cab Roof Units

    – Blow out evaporator (3) and hot-water radiator (4) with compressed air (5 bar max.). – Replace damaged seals (1) beneath the cover. – Bolt down cover from cab. – Close cab roof (1). Designation Evaporator 23854 Radiator 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 350: Putting The Air Conditioner Into Operation

    Note: The blade-type fuse is located between the engine and the grain tank. 19298 86837 13.11.6 Checking the air conditioner refriger- ant moisture saturation – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 351: Changing The Air Conditioner Refrigerant

    – Do not weld any components of the refrig- erant circuit and or in the immediate vicinity of any parts of the refrigerant circuit. – Maximum ambient temperature for refrig- erant is 80 °C. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 352 13.11 Cab / Operator's platform 67089 – Check refrigerant moisture saturation. – Suction refrigerant. – If required, replace filter receiver drier (1). – Top up with specified quantity of refrigerant. 23858 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 353: Feeder Unit

    – Repeat this procedure on the other side of the machine. 23849 86872 13.12.2 Adjusting the feeder chains – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 354: 3Adjusting The Feeder Chain Slip Clutch

    - After tensioning, tighten the nuts (1) and (3) on both sides. - Close flaps. 23850 72926 13.12.3 Adjusting the feeder chain slip clutch – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 355: 4Checking The Rasp Plates On The Feed Rake Conveyor

    - Relocate rasp plates and use second hole pattern. when installed in the first hole pattern. The rasp plates are flush with the feed rake conveyor - Install new rasp plates. when installed in the second hole pattern. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 356: Threshing Mechanism

    A large inspection hole facilitates inspection and clean- ing after the flap (1) is removed. – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 357 Machine damage. – Uniformly clean the rasp bars and cover plates from the inside. – Uniformly clean the rasp bars and cover plates from the inside. 19609 – Close flap (1). 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 358: Separation

    The straw walker house can be accessed through a flap (1) on the machine roof and through a flap (2) in the grain tank. – Open flap. – If necessary, remove dirt with an aid. 19626 19630 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 359: 2Checking The Deflector Curtain

    28513 19623 82752 13.14.3 Cleaning the separation throughput monitor sensor – Observe the general warnings at the beginning of the "Maintenance" chapter. – Clean sensor (1). 19647 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 360: Cleaning Unit

    – Set the diesel engine speed to fast idling speed. – Set fan speed to the lowest value with crank (1). – – Stop the threshing mechanism. – Stop the diesel engine. 19634 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 361: 4Cleaning The Stepped Preparation Floors

    – Observe the general warnings at the beginning of the "Maintenance" chapter. – Loosen the nuts at the brackets (1). – Detach the bracket (1). 19632 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 362: 5Cleaning The Sieves

    – Suspend bracket and bolt on with nuts. – Lock nuts. 19633 82787 13.15.5 Cleaning the sieves – Observe the general warnings at the beginning of the "Maintenance" chapter. – Clean the sieves. 19638 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 363: Grain Delivery

    – If necessary, adjust the grain elevator chain. 28689 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 364: 3Cleaning The Auger Troughs

    - Close the flap. – Fit guard (1). – Remove additional safety precautions. 29583 83208 13.16.3 Cleaning the auger troughs – Observe the general warnings at the beginning of the "Maintenance" chapter. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 365 – Clean the auger troughs. – Close the auger troughs (1). – Open the flaps (2) of the elevators. 19651 – Clean the flaps. – Close the flaps (2) of the elevators. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 366: 4Cleaning The Grain Tank

    In the transport position the grain tank unloading tube rests on the support bracket (1). – Adjust the support height with the two bolts (2) so that the unloading auger tube lies safely on the support. 28639 19659 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 367: Various Components / Machine Body

    The testing intervals may differ in other countries. In such cases, the information on the fire extinguisher is valid for the respective countries. The date of manufacture or the date last checked is shown on the extinguisher. 14530 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 368: Lubrication Chart

    Lubricants used on the machine and on the front attachment are subdivided into grease and chain oil. Grease Only use brand-name grease! CLAAS brand-name grease: AGRIGREASE EP 2 EP 2 Grease DIN 51502: KP2K-25 NLGI2 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 369: Greasing Cycles

    For better grease distribution, actuate the variable • speed drive several times. For better grease distribution, actuate the variable • speed drive several times. • • • • • • Option • • • 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 370 Lubricant symbols in figures The following symbols are used in figures: Lubricate the lubrication point. Lubricate the lubrication point. For grease see the lubricants chart. For chain lubrication oil see the lubricants chart. 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 371: Lubrication Points - 10 H On The Left

    14 Lubrication chart 14.1 Lubrication points 67090 87832 14.1.4 Lubrication points - 10 h on the left 30113 30114 30115 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 372: Lubrication Points - 10 H On The Right

    14 Lubrication chart 14.1 Lubrication points 67090 87833 14.1.5 Lubrication points - 10 h on the right 30112 30116 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 373: Lubrication Points - 50 H On The Left

    14 Lubrication chart 14.1 Lubrication points 67090 87834 14.1.6 Lubrication points - 50 h on the left 30113 30117 30119 30118 30114 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 374: Lubrication Points - 50 H On The Right

    14 Lubrication chart 14.1 Lubrication points 67090 87835 14.1.7 Lubrication points - 50 h on the right 30112 30120 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 375: Lubrication Points - 100 H On The Left

    14 Lubrication chart 14.1 Lubrication points 67090 87841 14.1.8 Lubrication points - 100 h on the left 12 13 14 30113 30132 30123 30125 30122 30124 30118 DOMINATOR 130 30126 30127 30129 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 376 14 Lubrication chart 14.1 Lubrication points 67090 30113 30128 30133 30130 30134 DOMINATOR 150 / 140 30131 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...

  • Page 377: Lubrication Points - 100 H On The Right

    14 Lubrication chart 14.1 Lubrication points 67090 87848 14.1.9 Lubrication points - 100 h on the right 30112 30135 30138 30136 30139 30137 30140 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 378 14 Lubrication chart 14.1 Lubrication points 67090 87851 14.1.10 Lubrication points - 500 h on the left 30113 DOMINATOR 130 30141 30114 30119 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 379 67090 87858 14.1.11 Lubrication points - 500 h on the right 34 35 36 37 38 30112 DOMINATOR 130 30143 30146 30147 DOMINATOR 130 30144 30142 DOMINATOR 130 30145 23386 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 380 ............... 43 Check level ............318 Attachment parts / machine body Checking the level / topping up ......270 Dimensions ............84 Brake pads Weights .............. 86 Check ............... 270 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 381 ......267 Escaping hydraulic liquid ........46 Problem and remedy .........253 Decals Cleaning performance monitor Cleaning ............267 Adjusting the display .........221 Deflector curtain Adjusting the sensors ........181 Adjust ..............214 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 382 Topping up oil ........... 315 Feeder unit Drive axle manual gearbox Problem and remedy ........249 Cleaning the environment ........ 270 Feeder unit/front attachment Cleaning the surroundings ....... 308 Reverse ............201 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 383 Front attachments ............39 Grain tank auger cover plates Front ladder (standard) Installation ............236 Rotation .............171 Removal ............236 Fuel filter Grain tank cover Changing Close ..............231 (CATERPILLAR 3056 E) ......269, 289 Open ..............231 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 384 PERKINS 1006-6T engine ......... 25 Machine serial number ..........18 Rear axle ............26 Maintenance area Straw chopper ............ 29 engine platform ........... 33 Trailer hitch ............27 left-hand operator's platform ......32, 33 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 385 CATERPILLAR 3056 E ........277 Adjustment (electric) .........199 CATERPILLAR C-6.6 ........277 Adjustment (mechanically) ........199 PERKINS 1006-6T ..........278 Refrigerant Air conditioner moisture saturation check ........271, 350 Packaging material disposal ...............42 disposal ...............42 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 386 Draining the coolant ......... 297 (straw chopper with standard spreader) ... 186 Fuel tank ............287 Straw guide plate Sieve table ............. 238 (straw chopper with standard spreader) ....185 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 387 Winter storage instructions for combines ....267 Unhitching ............164 Worklights ..............124 Trailer hitch Workplace Installing ..............93 access ..............32 Trailers ..............39 cab ..............32 Transporting passengers .........38 Tying down ...............47 Tyre pressure ............78 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 388 67075 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09...
  • Page 389 67091 Following the policy of CLAAS KGaA mbH to improve its products as technical developments continue, CLAAS reserves the right to make alterations which must not necessarily correspond to text and illustra- tions contained in this publication, and without incurring obligation to alter any machines previously delivered.
  • Page 390 CLAAS KGaA mbH Postfach 1163 33426 Harsewinkel Tel. +49 (0)5247 12-0 www.claas.com 00 0293 210 2 BA DOMINATOR 150/140/130 EN - 12/09 Printed in Germany...

This manual is also suitable for:

Dominator 140Dominator 130

Table of Contents
