DIESEL 1500
ZERO-TURN MOWER
OWNER'S, SERVICE & PARTS MANUAL
For additional information, please see us at
www.badboymowers.com
cc
MODEL
Bad Boy, Inc.
102 Industrial Drive
Batesville, Arkansas 72501
©2017 12-6
