Power Step Cat D10R Dozer Manual page 32

FOLDING LADDER
Caterpillar D10R Dozer
Section 5-6 Drive Unit Assembly
See Drawing Page 31
Item Part No.
1 PS-63014
2 PS-21974
3 PS-21959
4 PS-21984
5 PS-21954
6 PS-21991-02
6A PS-21991-01
7 PS-61006-2
8 PS-21940-03
9 PS-21959-09
10 PS-21959-08
11 PS-21959-05
12 PS-21959-06
13 PS-M24X120ZP
14 CPS-M20X65ZP
15 CPS-M12X70ZP
16 CPS-M12X25ZP
17 CPS-M10X30ZP
18 CPS-M10X15ZP
19 CPS-M5X15ZP
20 PS-M24NN
21 PS-M20NZP
22 CPS-M12NZP
23 CPS-M12NN
24 CPS-M5NN
25 CPS-M24WH
26 CPS-M20WH
27 CPS-M12WH
28 CPS-M10WH
29 CPS-M5WH
PSA-D10R FL+RHW 31-3-14
Part Name
HYDRAULIC CYLINDER (Refer Page 22)
DRIVE MOUNTING FRAME
SECTOR GEAR
DRIVE GUARD
ACTUATOR CYL. MOUNTING ASSEMBLY
MOUNTING BAR-PROXIMITY SWITCH
STRIKER
GREASE NIPPLE M6 STR.
PIVOT PIN KEEPER PLATE
SECTOR GEAR BUSH
SECTOR GEAR HUB
CLAMP RING
SPACER RING
BOLT-M24 x 120
BOLT-M20 x 65
BOLT-M12 x 70
BOLT-M12 x 25
BOLT-M10 x 30
BOLT-M10 x 15
BOLT-M5 x 15
NUT-NYLOC-M24
NUT-M20
NUT-M12
NUT-NYLOC-M12
NUT-NYLOC-M5
WASHER-HARDENED-M24
WASHER-HARDENED-M20
WASHER-HARDENED-M12
WASHER-HARDENED-M10
WASHER-HARDENED-M5
Qty
1
1
1
1
1
1
1
4
1
2
1
1
1
2
4
8
10
4
4
6
2
4
14
3
6
4
8
20
12
12
Pg32
