Power Step Cat D10R Dozer Manual page 30

FOLDING LADDER
Caterpillar D10R Dozer
Section 5-5 Spreader Assembly
See Drawing Page 29
Item Part No.
1 PS-22287
2 PS-21931 98
2A PS-21931-97
3 PS-21931-99
4 PS-21930A
5 PS-21933
6 PS-22281-04
7 PS-22281-03
7A PS-22281-02
8 PS-22281-01
9 PS-22018-03
10 PS-22018-01
11 PS-M20X50ZP
12 CPS-M12X25ZP
13 CPS-1/2"NN
14 PS-M20WH
15 CPS-M12WH
16 CPS-1/2"WH
PSA-D10R FL+RHW 31-3-14
PS-22287A- D10R
Part Name
SPREADER
ISOLATOR PIN BRACKET-OUTER LHS
ISOLATOR PIN BRACKET-OUTER RHS
ISOLATOR PIN BRACKET-INNER
ISOLATOR MOUNTINGS
ISOLATOR BUSH PIN
WASHER PLATE - (1 Hole)
WASHER PLATE - (2 Holes)
WASHER PLATE - (3 Holes)
WASHER PLATE - (4 Holes)
MOUNT BLOCK REAR OUTER
MOUNT BLOCK REAR INNER
BOLT-M20 x 50
BOLT-M12 x 25
NUT-NYLOC-1/2" UNC
WASHER-HARDENED-M20
WASHER-HARDENED-M12
WASHER-HARDENED-1/2"
Qty
1
1
1
2
12
4
3
2
1
1
2
2
14
40
8
14
40
8
Pg30
