Power Step Cat D10R Dozer Manual page 22

FOLDING LADDER
Caterpillar D10R Dozer
Section 5-2 Landing Assembly LHS PS- 22017A-NG
See Drawing Page 21
Item Part No.
1 PS-22017
2A PS-22010-A-NG
2B PS-22010-B-NG
3A PS-22014-98
3B PS-22014-99
4 PS-21930A
5 PS-21976
6 PS-21941-02
7 PS-21941-06
8 PS-21933
9 PS-21925
10 PS-HRI-C11
11 PS-HRI-A06
12 PS-22018-04
13 CPS-M12X65ZP
14 CPS-M12X35ZP
15 CPS-M12X30ZP
16 CPS-M12X25ZP
17 CPS-M10X75ZP
18 CPS-M8X35ZP
19 CPS-M12NZP
20 CPS-1/2"NN
21 CPS-M10NN
22 CPS-M8NN
23 CPS-M12WH
24 CPS-1/2"WH
25 CPS-M10WH
26 CPS-M8WH
PSA-D10R FL+RHW 31-3-14
Part Name
LANDING ASSEMBLY
HANDRAIL-FRONT LHS- NEW GENERATION
HANDRAIL-REAR LHS- NEW GENERATION
ISOLATOR PIN BRACKET-REAR
ISOLATOR PIN BRACKET-FRONT
ISOLATOR MOUNTINGS ASSY.
FRONT PIVOT PIN BRACKET
ANTI VIBRATION BEARING
RUBBER BUSH
ISOLATOR BUSH PIN
MIDDLE BEARING MOUNTING
RUBBER HOSE Pirtek IRR-032 x 120
HANDRAIL POST - DOUBLE CLAMP ASSY.
SIDE MOUNTING PAD
BOLT-SOCKET HEAD-M12 x 65
BOLT-M12 x 35
BOLT-M12 x 30
BOLT-M12 x 25
BOLT-M10 x 75
BOLT-M8 x 35
NUT-M12
NUT-NYLOC-1/2"UNC
NUT-NYLOC-M10
NUT-NYLOC-M8
WASHER-HARDENED-M12
WASHER-HARDENED-1/2"
WASHER-HARDENED-M10
WASHER-HARDENED-M8
Upgraded Handrails
Qty
1
1
1
2
6
1
2
2
2
1
4
4
2
2
2
32
12
20
4
8
32
4
4
8
88
4
8
16
Pg22
