OPERATION AND MAINTENANCE MANUAL
This manual contains important safety information and must be made
available to personnel who operate and maintain this machine.
Doosan purchased Bobcat Company from Ingersoll-Rand Company in
2007. Any reference to Ingersoll-Rand Company or use of trademarks,
service marks, logos, or other proprietary identifying marks belonging
to Ingersoll-Rand Company in this manual is historical or nominative
in nature, and is not meant to suggest a current affiliation between
Ingersoll-Rand Company and Doosan Company or the products of
either.
Portable Compressor 7/20
SERIAL No. :
C.P .N.:
DATE :
120001 ®
22311203 GB
September 2003
Revised (10-12)
