This manual contains important safety information.
!
Do not destroy this manual.
This manual must be available to the personnel who operate and maintain this machine.
Portable Air Compressor Division
P.O. Box 868 -- 501 Sanford Ave
Mocksville, N.C. 27028
Revised (10-12)
Book 54722160 (8/02)
OPERATING, MAINTENANCE,
PARTS MANUAL
COMPRESSOR MODEL
HP375WJD
XP375WJD
Code:
( )
Doosan purchased Bobcat Company from Ingersoll-Rand Company in
2007. Any reference to Ingersoll-Rand Company or use of trademarks,
service marks, logos, or other proprietary identifying marks belonging
to Ingersoll-Rand Company in this manual is historical or nominative
in nature, and is not meant to suggest a current affiliation between
Ingersoll-Rand Company and Doosan Company or the products of
either.
