Cisco Craft Works Interface Quick Start Manual page 9

Launching CWI Without Using the Device Tree
To launch CWI with SSL either enabled or not enabled, perform the following steps:
Double-click the CWI icon to launch the client desktop. The CWI - Login window appears (see Figure 1).
Step 1
You have the option to add a device or device group and log in to multiple routers. See the "Launching CWI from the
Device Tree" section on page 10 for more information.
Figure 1 CWI - Login Window
Enter the same AAA username and password that you used in Step 4 to access the router that must be configured. See the
Note
"Installing CWI" section on page 7.
Step 2 Enter the same AAA username.
Enter the same AAA password.
Step 3
(Optional) Enter the enable password for IOS.
Step 4
When you connect to an IOS device, you must enter the enable password.
Note
Choose one of the following connection categories from the drop-down menu:
Step 5
• IP
• Console/Aux
• Scripted
Note If you choose the IP-based or Console/Aux connection categories, the scripted login fields are not displayed.
Choose one of the following connection types from the drop-down menu:
Step 6
• XML over CORBA. Choose the node name. Note that XML over CORBA is the default.
• CLI over Telnet/SSH. Choose the server name. Specifying the port is optional. If you specify a port, CWI tries to
connect using only that port. CWI does not automatically try to connect with other ports.
• Terminal Server. Choose the server name and port.
• Serial Port. Choose the Serial Port. You can also set the parameters for the serial port.
9
