Step 5: Connect the remote sensor and infrared (IR) emitter
cable
To change channels using the HP Media Remote Control, the remote sensor must be connected to your
computer.
To connect the remote sensor and IR emitter cable, follow these steps:
1.
Connect the remote sensor to a USB port on the computer.
NOTE:
NOTE:
on page
2.
Connect the infrared (IR) emitter cable from the IR receiver to the receiver:
a.
b.
c.
After the IR emitter is connected to the receiver, you can use the HP Media Remote Control to
change the channels.
12
Chapter 3 TV tuner setup
Antenna House XSL Formatter (Evaluation) http://www.antennahouse.com/
You can connect the remote sensor to any USB port on your computer.
If you did not include a receiver in your setup, proceed to
14, later in this chapter.
Connect the IR emitter cable to the remote sensor (1).
NOTE:
Be sure that you connect the IR emitter cable to the connector marked with a "1" on
the remote sensor.
Remove the backing paper from the IR emitter to expose the adhesive tape (2).
Press the adhesive side of the IR emitter onto the infrared (IR) lens on the front of the receiver
(3).
NOTE:
To help locate the IR lens, shine a flashlight on the front of the receiver. The IR lens
is usually a small, dark-red window.
NOTE:
If you cannot place the emitter directly over the IR lens, place it as close to the IR
lens as possible.
