QTech QT290C Carry User Manual page 13

24
Motor & Gearbox
ITEM PRODUCT CODE DESCRIPTION
36 12-290-051 SOCKET CAP SCREW (M5 x 35)
37 12-290-050B GEAR HOUSING
38 12-290-053 BALL BEARING
39 12-137 MACHINE SCREW (M5 x 8)
40 12-290-055 CONNECTING ROD
41 12-290-056 NEEDLE BEARING
42 12-290-057 CRANK GEAR (6.9 STROKE)
43 12-290-060 BALL BEARING
44-1 12-290C-062-1 MOTOR UNIT (110V)
44-2 12-290C-062-2 MOTOR UNIT (220V)
45 12-290-065 CARBON BRUSH (8x16)
46 12-290-064 BRUSH CAP (8x16)
47 12-290C-020 FRONT HANDLE
48 12-139 SOCKET CAP SCREW (M8 x 16)
49 12-290-050B HOUSING COVER
50 12-290-069 SOCKET CAP SCREW (M5 x 55)
51 12-290-061 SOCKET CAP SCREW (M5 x 12)
QTechSpray.com
Control
Box
ITEM PRODUCT CODE DESCRIPTION
65 12-290-092
66 12-290C-094
67 12-290-093
68 12-290C-090
69 12-290-096
QTY
70 12-290-097
6
71 12-017
1
72-1 12-290-091-1
1
72-2 12-290-091-2
2
73 12-290-100
1
74 12-290-120
1
75 12-135
1
76 12-064
1
77 12-290-108
1
78 12-290C-091
1
79 12-290-106
2
80 12-290-105
2
81 12-290-115
1
82 12-290C-092
2
83 12-290C-093
1
84-1 12-290C-095-1
4
84-2 12-290C-095-2
4
84-3 12-290C-095-3
85 12-290-111
86 12-290-110
87 12-290-116
88 12-062
89 12-290C-097
90 12-290C-098
91 12-290C-099
HEX NUT (M4)
U-BRACKET
SOCKET CAP SCREW (M4 x 12)
CONTROL BOX
PANHEAD MACHINE SCREW (M4 x 10)
EARTHING MARKING
PANHEAD TAPPING SCREW (M4x12)
ELECTRONICS UNIT (110V)
ELECTRONICS UNIT (220V)
CURRENT PROTECTOR
SPEED CONTROL (110V&220V)
SOCKET SET SCREW (M4 x 8)
SUCTION POWER CONTROL DIAL
HEX NUT (M3)
LCD DISPLAY (110V&220V)
WINDOW
MACHINE SCREW (M3 x 12)
POWER SWITCH (110V&220V)
INTEGRATED SWITCHING SOCKET (110V&220V)
POWER SOCKET HOUSING
POWER SUPPLY CABLE (UK-110V YELLOW 3 PIN)
POWER SUPPLY CABLE (UK-240V 13A BS 3PIN)
POWER SUPPLY CABLE (AU-220V 10A AU PLUG)
WIRE LEAD (23CM)
WIRE LEAD (17CM)
CABLE GLAND
PUSH BUTTON SWITCH
WIRE LEAD (BLUE)
WIRE LEAD (BROWN)
WIRE LEAD (EARTH)
QTech QT290C Carry Airless Sprayer
25
QTY
6
2
6
1
1
1
4
1
1
1
1
1
1
4
1
1
4
1
1
1
1
1
1
2
1
1
1
1
1
1
