Summary of Contents for QTech QT290C Carry
- Page 1 USER MANUAL QT290C Carry Aristospray Ltd 2b Stephenstown Industrial Park Balbriggan Airless Sprayer County Dublin Ireland K32 KV26 Email sales@aristospray.com www.QTechSpray.com Phone UK 01895 276751 ROI 0 1690 3162 International +353 1690 3162 www.QTechSpray.com @QTechSpray...
-
Page 2: Quick Check
Quick check QTech QT290C Carry Electric Airless Sprayer The information on this page is intended only as a quick guide. It is no way intended as a substitute to the information on the pages following, which the user should be fully acquainted with before using an electric airless sprayer. - Page 3 QTech QT290C Carry For some general advice on using QTech airless spray machines including the answer to many common FAQs take a look at www.qtechspray.com/spray-faqs/ USE TO SPRAY Emulsion, interior and exterior Top coats Wood preservatives Most other low-medium Filter cap...
-
Page 4: General Safety
Damaged or entangled cords increase the risk of electric shock. When operating an airless sprayer outdoors, use an outdoor extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. QTechSpray.com QTech QT290C Carry Airless Sprayer... -
Page 5: Personal Safety
5 Re-engage gun safety latch and close Priming Valve. If the SPRAY TIP OR Tetrachloroethane HOSE IS CLOGGED, follow Step 1 through 5 above. Expect paint splashing into the bucket while relieving pressure during Step 4. QTechSpray.com QTech QT290C Carry Airless Sprayer... - Page 6 + NEVER wipe off build up around the spray tip. ALWAYS wear a spray mask, gloves and protective eye wear while spraying. ALWAYS ensure fire extinguishing equipment is readily available and properly maintained. QTechSpray.com QTech QT290C Carry Airless Sprayer...
- Page 7 4 Never use high pressure in the cleaning process. USE MINIMUM PRESSURE. 5 Do not smoke in spraying/cleaning area. NEVER use cleaning solvents with flash points below 60°C/140°F. Some of these are: acetone, benzene, ether, gasoline, naphtha. Consult your supplier if in doubt. QTechSpray.com QTech QT290C Carry Airless Sprayer...
-
Page 8: Operation
Allow the unit to operate until clean solvent comes from the gun. 7 Release the trigger and engage the gun safety latch. 8 Whenever you shut off the sprayer, follow the PRESSURE RELIEF PROCEDURE. QTechSpray.com QTech QT290C Carry Airless Sprayer... - Page 9 While spraying, hold the gun perpendicular, about 25-30cm (10-12 inches) away from the surface. Spray back and forth. Trigger the gun before moving and release the trigger after each stroke. Overlap by 50%. QTechSpray.com QTech QT290C Carry Airless Sprayer...
- Page 10 If when using 5 Engage gun safety latch and return handle to the spray position. maximum capacity tip size the pump cannot keep up, then you know that the tip is worn beyond capacity. QTechSpray.com QTech QT290C Carry Airless Sprayer...
-
Page 11: Cleanup Procedure
7 Thread the packing nut loosely. Push the piston up through the pump fluid section. Tighten the packing nut until resistance from the disc springs is felt. Tighten a further 3/4 turn but be careful. Do not over tighten. QTechSpray.com QTech QT290C Carry Airless Sprayer... -
Page 12: Fluid Pump
DISPLACEMENT PISTON COMPLETE 12-290-022 INCLUDES ITEMS 13, 14, 15, 16, 17 FLUID PUMP COMPLETE, 12-290C-500 INCLUDES ITEMS 03, 07, 08, 09, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22 QTechSpray.com QTech QT290C Carry Airless Sprayer... - Page 13 POWER SUPPLY CABLE (AU-220V 10A AU PLUG) 12-290-111 WIRE LEAD (23CM) 12-290-110 WIRE LEAD (17CM) 12-290-116 CABLE GLAND 12-062 PUSH BUTTON SWITCH 12-290C-097 WIRE LEAD (BLUE) 12-290C-098 WIRE LEAD (BROWN) 12-290C-099 WIRE LEAD (EARTH) QTechSpray.com QTech QT290C Carry Airless Sprayer...
- Page 14 TOUGHFLOW HOSE 1/4" x 15M 12-290-085 HIGH PRESSURE HOSE (1/4"-18UNF) NOT SHOWN IN DIAGRAM 12-003 OUTPUT NIPPLE 100045R SPRAY GUN / HOSE WRENCH 12-290-075 PRIMING VALVE 503-150 SPRAY GUN c/w GUARD & 517 TIP QTechSpray.com QTech QT290C Carry Airless Sprayer...
-
Page 15: Wiring Diagram
Wiring Diagram QTechSpray.com QTech QT290C Carry Airless Sprayer... - Page 16 QTechSpray.com QTech QT290C Carry Airless Sprayer...
